Biostar M7VIG PRO Test Report

Biostar M7VIG PRO Test Report

Engineering validation test report
Hide thumbs Also See for M7VIG PRO:
Table of Contents

Advertisement

Quick Links

See also: User Manual
E
NGINEERING
CHANGE CONTROL
Description of Change
Initial Release
M7VIG Pro
Project:
Date:
2002/10/9
Owner:
Biostar Group
Contact:
TEL: 886-2-2218-0150 FAX: 886-2-2218-1552
Home Page:
1
M7VIG Pro
V
ALIDATION
COVER SHEET
Revision
0.9
1.0
1.2
1.4
http://www.biostar.com.tw
T
R
EST
EPORT
Sections/Pages Affected
Date
2002/10/9
2002/10/29
2002/12/10
2002/12/26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7VIG PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar M7VIG PRO

Summary of Contents for Biostar M7VIG PRO

  • Page 1 M7VIG Pro NGINEERING ALIDATION EPORT COVER SHEET CHANGE CONTROL Description of Change Revision Sections/Pages Affected Date Initial Release 2002/10/9 2002/10/29 2002/12/10 2002/12/26 M7VIG Pro Project: Date: 2002/10/9 Owner: Biostar Group Contact: TEL: 886-2-2218-0150 FAX: 886-2-2218-1552 Home Page: http://www.biostar.com.tw...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT INFORMATION ..............4 Motherboard General Information ..............4 Chipset Details ......................4 BIOS Details ......................4 CPU Supports ......................4 Memory Supports ....................4 On-board Features and Devices ................4 Mechanical ....................... 5 DESIGN REVIEW Ver1.4 ................7 Mainboard Voltage Measurement ..............
  • Page 3 Windows 2000 ...................... 36 Windows XP ......................37 Display Card Performance ..................38 HARDWARE COMPATIBILITY LIST ..........39 ......................... 39 CD-ROM ........................ 40 Camera Device ...................... 40 DVD-ROM ......................40 Display Card ......................41 ......................... 41 ........................42 Joystick ........................43 Keyboard ........................

  • Page 4: Product Information

    PRODUCT INFORMATION Motherboard General Information Vendor Biostar Model Number M7VIG Pro Version Number V0.90/V1.0/V1.2/V1.4 Platform Micro ATX Flex ATX Chipset Details System Chipset Vendor North Bridge Revision KM266 South Bridge Revision VT8235 Super I/O Chip Vendor Winbond Super I/O Revision Number...

  • Page 5: Mechanical

    PC 133 Support DDR 266 Support PCI v2.2 Compliance ATA-3 Compliance ATAPI Compliance Ultra DMA 33 Support Ultra DMA 66 Support ATA-133 Support USB 1.1 Connector Support USB 2.0 Connector Support AGP (2X/4X) Slot Support Support AGP SideBand Addressing Mode Power on by LAN Support Power on by Keyboard Support Power on by Mouse Support...
  • Page 6 Game Port Connectors Line Up in Case None Excellent Fair Poor AGP Slot(Card) Line Up in Case None Excellent Fair Poor PCI Slots(Card) Line Up in Case None Excellent Fair Poor AMR Slot(Card) Line Up in Case None Excellent Fair Poor CNR Slot(Card) Line Up in Case None...

  • Page 7: Design Review Ver1.4

    DESIGN REVIEW Ver1.4 Mainboard Voltage Measurement Voltage List Voltage SPEC Voltage Measured Result Battery Voltage 3.0V 3.03V Pass Battery Current 2.12uA Pass 5.0V+-5% 5.15V Pass +12V 12.0V+-5% 11.69V Pass -5.0V+-5% -5.08V Pass -12V -12.0V+-10% -11.75V Pass +3.3V +3.3V+-5% 3.29V Pass Bus Clock Clock Frequency Spec Value...

  • Page 8: Required Bios Default Settings

    REQUIRED BIOS DEFAULT SETTINGS Lists Specification Result BIOS FEATURES SETUP Virus Warning Disabled Pass Boot Seq/Floppy Setup Press Enter Pass First Boot Device Floppy Pass Second Boot Device HDD-0 Pass Third Boot Device LS120 Pass Boot Other Device Enabled Pass Swap Floppy Drive Disabled Pass...

  • Page 9: Power Management Setup

    AGP Fast Write Disabled Pass AGP Master 1 WS Write Disabled Pass AGP Master 1 WS Read Disabled Pass CPU & PCI Bus Control Press Enter Pass PCI1 Master 0 WS Write Enabled Pass PCI2 Master 0 WS Write Enabled Pass PCI1 Post Write Enabled...

  • Page 10: Integrated Peripherals

    INTEGRATED PERIPHERALS OnChip IDE Control Press Enter Pass OnChip Primary PCI IDE Enabled Pass OnChip Secondary PCI IDE Enabled Pass IDE Prefetch Mode Enabled Pass Primary Master PIO Auto Pass Primary Slave PIO Auto Pass Secondary Master PIO Auto Pass Secondary Slave PIO Auto Pass...
  • Page 11 CPU Vcore 1.68 V +3.3V 3.26 V +5.0V 5.02 V +12V 12.40 V - 12V -12.03 V -5 V -5.09 V Show H/W Monitor in POST Enabled Chassis Open Warning Disabled Shutdown Temperature Disabled Comments:...

  • Page 12: Functionality

    FUNCTIONALITY Setup Installation Test Of Operating System Pass/Fail Windows ME Pass Windows 2000 Professional Pass Windows XP Home Edition Pass Windows XP Professional Pass Linux (Red Hat 8.0) Pass Basic On-board Function Test Test Platform MS-DOS Operating Comment AMD Athlon XP 2400 Memory SAMSUNG 258 M X1 Seagate ST380021A 80G...
  • Page 13 Time Out Function Test Pass Power LED Flash Check Pass Power On Control Power On By RTC Test Pass Power On By LAN Test Pass Power On By Modem Test Pass Boot Management Boot Form CD-ROM Pass Boot From SCSI HDD Pass Boot From ATAPI ZIP/LS120 Drive Pass...
  • Page 14 BIOS ROM Test Pass Parity Test Pass Pattern Test Pass Extended Pattern Test Pass Walking 1’s Test Pass Walking 0’s Test Pass Random Memory Test Pass Address Test Pass Refresh Test Pass Data Bus Test Pass Cache Memory Test Pass Quick Memory Test Pass IDE HDD Test...

  • Page 15: Windows Me Operating

    Serial Port Test Pass Parallel Port Test Pass PS/2 Mouse Test Pass APM Functionality Test Pass Device APM Test Pass ACPI Test Pass I82557 Ethernet chip Pass Comments: Test Platform Windows ME Operating Comment Athlon 2600 Memory SAMSUNG 256M X2 MAXTOR 80G CDROM LITEON 52X...
  • Page 16 COM Port Test Add Serial Mouse PnP Test Pass Add Modem PnP Test Pass Print Port Test Add Printer PnP Test Pass FDD Connector Test Create Windows ME Startup Disk Pass Format 1.44 Floppy Driver Pass IDE Connectors Test CD-ROM Data Read Test Pass DVD-ROM Data Read Test Pass...
  • Page 17 √ √ √ √ 640x480 16 bit Pass √ √ √ √ 640x480 32 bit Pass √ √ √ 800x600 16 bit None Pass √ √ √ 800x600 32 bit None Pass √ √ √ √ 1024x768 16 bit Pass √...

  • Page 18: Windows2000 Operating

    Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass DirectDraw Tests Pass Disk Inspection Tests Pass Disk WinMark Pass GDI/USER Inspection Tests Pass High-End Disk WinMark 99 Pass High-End Graphics WinMark 99 Pass Video Tests Pass 3D Mark 2001 SE 3D Marks Pass Demo Mode...
  • Page 19 Setup installation Microsoft Office 2000 Test Pass Hibernate(S4) Test Standby Button for S4 (Enter) Pass Power Button for S4 (Enter and Wake up) Pass Windows Set RTC Time out for S4 (Enter and Wake up) Pass Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass Wake Up By LAN Test Pass...
  • Page 20 CNR Slots Test Add Modem Card Test Pass VGA Function Test VGA Drivers Setup Installation Test Pass Display Properties Information Review Pass VGA Resolution All Test Pass Screen Saver Test Pass Check Screen Have No Any Shadow Or Garbage Pass Playing MPEG Files Test Pass Playing VCD Test...

  • Page 21: Windows Xp (Home Edition ) Operating

    BurnIn Test CPU-Maths Pass CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winbench 99 (1.2) Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass DirectDraw Tests Pass Disk Inspection Tests...
  • Page 22 Maxtor 6L060L3 60G CDROM SONY DDU-1621 16X Sound Card Onboard Video Card Onboard LAN Card Onboard Test Item Pass/Fail System Comparability Test Windows XP Setup Installation Test Pass Supports Driver Installation Test Pass Standby Mode Test Pass Shut Down Test Pass Restart Test Pass...
  • Page 23 Device Comparability Test PS/2 Connector Test PS/2 Keyboard Test Pass PS/2 Mouse Test Pass COM Port Test Add Serial Mouse PnP Test Pass Add Modem PnP Test Pass Print Port Test Add Printer PnP Test Pass Add ZIP Device Test Pass IrDA Function Test Add IR Printer Test...
  • Page 24 Boot ROM Function Test Pass Login Server Test Pass Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass Wake On LAN Test (Standby Mode) Pass Playing AVI Files By The LAN Pass Setup Installation Winstone 2001 By The LAN Pass Setup Installation Winbench 99 By The LAN Pass...
  • Page 25 Recording a MP3 File From Internet ISP Server Pass FTP Transport Test (Download and Upload Test ) Pass VGA Function Test VGA Drivers Setup Installation Test Pass Display Properties Information Review Pass Run 3D Screen Saver Pass Run 3D Mark2001 Pass Run XL-R8R Pass...
  • Page 26 Voice 8 0.226 Voice 16 0.303 Voice 32 1.44 DirectSound CPU Util , 22 kHz , 8 bits Static Hardware Voice Voice 8 Voice 16 2.38 Voice 32 0.539 DirectSound CPU Util , 22 kHz , 8 bits Steaming Hardware Voice Voice 8 Voice 16 0.0947...
  • Page 27 Floppy Disk Test Pass CD-ROM Test Pass Stress Test –Loop 100 Pass MS Mouse Pass MS Joystick Pass MS ScanDisk Pass BurnIn Test CPU-Maths Pass CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test...

  • Page 28: Windows Xp (Professional ) Operating

    Test Platform Windows XP (Professional ) Operating Comment AMD AthlonXP_ 2.4G Memory SAMSUNG 128M X 2 SEAGATE ST380021A 80G CDROM TEAC (CD-540E) Sound Card Onboard Video Card Onboard LAN Card INTEL SB82558B Test Item Pass/Fail System Comparability Test Windows XP Setup Installation Test Pass Supports Driver Installation Test Pass...

  • Page 29: Linux (Red Hat 8.0) Operating

    PC Mark 2002 CPU Score Pass Memory Score Pass HDD Score Pass 3D Mark 2001 SE BenchMark Pass Demo Mode Pass Comments: Test Platform Linux (Red Hat 8.0) Operating Comment AMD Athlon XP 2.4 G Hz Memory Winbond 512 M * 2 IBM IC35L120AVVA07-0 / 120 G DVD-ROM BENQ DVP1648P...
  • Page 30 Add Sound Card Test Pass Comments:...

  • Page 31: Over Clock Test

    OVER CLOCK TEST Test Platform Windows XP Home Edition (FSB:100 MHz & SDRAM ) DURON 1300 Memory MT 512M X2 (PC-133) MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board CPU Front Side Bus Clock PC Mark 2002 CPU Score 3561 3757...

  • Page 32: Windows Xp Home Edition

    Test Platform Windows XP Home Edition (FSB:100 MHz & DDR ) DURON 1300 Memory INFINEON 512M X2 (PC-2700) MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board CPU Front Side Bus Clock PC Mark 2002 CPU Score 3607 3800 Memory Score...

  • Page 33: Windows Xp Home Edition

    Test Platform Windows XP Home Edition (FSB:133 MHz & SDRAM ) Athlon XP 2600+ Memory MT 512M X2 (PC-133) MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board CPU Front Side Bus Clock PC Mark 2002 CPU Score 5835 6049...

  • Page 34: Windows Xp Home Edition

    Test Platform Windows XP Home Edition (FSB:133 MHz & DDR ) Athlon XP 2600+ Memory INFINEON 512M X2 (PC-333) MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board CPU Front Side Bus Clock PC Mark 2002 CPU Score 5939 6170...

  • Page 35: Performance Test

    PERFORMANCE TEST Test Platform Windows ME Memory JETRAM 128M X2 SDRAM SAMSUNG 128M X2 DDR MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board Athlon Athlon Athlon Athlon 1400MHZ 1400MHZ 1400MHZ 1400MHZ (100X14) (133X10.5) (100X14) (133X10.5) PC Mark 2002 CPU Score 3353...

  • Page 36: Windows 2000

    Test Platform Windows 2000 Memory SAMSUNG 256MX2 SAMSUNG 256MX2 (PC-133) DDR-400 (PC-3200) MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board Duron Athlon XP Duron Athlon XP 1200 2100+ 1200 2100+ PC Mark 2002 CPU Score 3346 4918 3366...

  • Page 37: Windows Xp

    Test Platform Windows XP Memory MT 512M X2 SDRAM INFINEON 512M X2 DDR PC-133 PC-333 MAXTOR 80G CD-ROM LITEON 52X Sound Card On board Video Card On board Duron Athlon XP Duron Athlon XP 1300 2600+ 1300 2600+ PC Mark 2002 CPU Score 3561 5835...

  • Page 38: Display Card Performance

    Display Card Display Card Performance Vendor Model Chips Result ASUS AGP-V 3800M RIVA TNT2 M64 1735 ASUS V9280 Geforce 4 Ti 4200-8X 10483 ALL-IN-WONDER 128 3645 RADEON DDR 32M RADEON DDR 32M 2453 RADEON 8500 ATI RADEON 8500 8455 RADEON 9000 ATI RADEON 9000 7660 TRANSCEND...

  • Page 39: Hardware Compatibility List

    HARDWARE COMPATIBILITY LIST Vendor Model Frequency Type Result Athlon 700 MHz Socket A Pass Athlon 750 MHz Socket A Pass Athlon 800 MHz Socket A Pass Athlon 850 MHz Socket A Pass Athlon 900 MHz Socket A Pass Athlon 950 MHz Socket A Pass Athlon...

  • Page 40: Cd-Rom

    Comments: CD-ROM Vendor Model Transfer Rate Type Result AFREEY CD-2052E ATA-33 Pass BCD F562 ATA-33 Pass TEAC CD-540E ATA-33 Pass TEAC CD-532E ATA-33 Pass YAMAHA BCD F563E ATA-33 Pass YAMAHA KHS 5238E ATA-33 Pass BEN –Q 652A674 ATA-33 Pass A-OPEN CD-952E ATA-33 Pass...

  • Page 41: Display Card

    Comments: Display Card Vendor Model Chips Drivers Result ASUS AGP-V 3800M RIVA TNT2 M64 28.32 Pass ASUS V9280 Geforce 4 Ti 4200-8X 30.82 Pass ALL-IN-WONDER 128 6.13.10.6166 Pass RADEON DDR 32M RADEON DDR 32M 6.13.10.6166 Pass RADEON 8500 ATI RADEON 8500 6.13.10.6166 Pass RADEON 9000...

  • Page 42: Hdd

    MITSUMI D353T6 1.44 Pass MITSUMI D359M3 1.44 Pass MITSUMI D353M3 1.44 Pass FD1231H 1.44 Pass TEAC FD-235HF 1.44 Pass SONY MPF920-E 1.44 Pass Panasonic JU257A606P 1.44 Pass SUMSUNG SFD-321B 1.44 Pass Comments: Vendor Model Size Type Result FUJITSU MPD3108AT 10.8G ATAPI Pass FUJITSU...

  • Page 43: Joystick

    QUANTUM E5100AT 5.1G ATA-33 Pass QUANTUM CR6400AT 6.4G ATA-33 Pass QUANTUM CX6400AT 6.4G ATA-33 Pass QUANTUM 6.4G SCSI 6.4G 6.4G Pass QUANTUM KA9100AT 9.1G ATA-66 Pass QUANTUM KA13600AT ATA-66 Pass QUANTUM KX13600AT ATA-66 Pass QUANTUM LM15000AT ATA-66 Pass QUANTUM LM20500AT ATA-66 Pass QUANTUM...

  • Page 44: Lan Card

    BUS LOGIC BA81C15 Pass K.A.CHEN KB-7000 PS/2 Pass SAMPO F-21BQ PS/2 Pass Logitech Y-SA2 PS/2 Pass ACER 6511-TA PS/2 Pass Logitech (IR) Y-RA1 Pass WIRELESS 5110 Pass Comments: LAN Card Vendor Model Drivers Type Result 3COM 3C905-TX Pass 3COM 3C905C Pass 3COM 3C905B-TX...
  • Page 45 Infineon HYB39S128800CT-7.5 128M PC-133 Pass JetRam J28S3AT-75 128M PC-133 Pass KINGMAX KSV884T4A1A-07 128M PC-133 Pass KINGMAX KSV884T4A1A-06 128M PC-150 Pass 48LC16M8A2-75B 128M PC-133 Pass 48LC16M8A2-75E 256M PC-133 Pass 48LC16M8A2-75B 512M PC-133 Pass MOSEL V54C365804VCT7 128M PC-133 Pass NEC (Japan) D4564841G5-A75-9JF 128M PC-133 Pass...

  • Page 46: Modem Card

    Comments: Modem Card Vendor Model Drivers Type Result AZTECH MDP 3858SP-UE vxd 2.1.2135.7.1 Pass AZTECH MDP 7800U 4.90.3000 Pass 3Com U.S Robotics 0637 vxd v1.00.017 Pass Lectron I56LVP-F1 7.66-9K-03 Pass LEMEL MD-56K Pass MDX-56KRE Pass Lectron PCT303W 2.40.0004 Pass WELL FM-56CNR-HPNA-SL-A vxd v2.84 Pass...

  • Page 47: Monitor

    Monitor Vendor Model Size Type Result GENUINE G585 Pass 14″ ViewSonic View Panel VPD150 Pass 15″ ViewSonic E653 Pass 15″ SAMPO AlphaScan 521a 15” Pass ViewSonic View Panel VG175 Pass 17″ ViewSonic View Panel VE170 Pass 17″ Mozo M7++ Pass 17.4″...

  • Page 48: Scanner

    SAMSUNG SCX-1050 Pass Comments: Scanner Vendor Model Drivers Type Result Scan Jet 4200C Pass Scan Jet 5200C Pass MUSTEK 1200USB Pass UMAX Astra 1220U Pass UMAX Astra 2000U Pass Comments: SCSI Card Vendor Model Drivers Type Result ADAPTEC 2940U Pass ADAPTEC 2940UW PCI-WIDE...

  • Page 49: Usb Hub

    Comments: USB HUB Vendor Model Version Result SIIG UH-144 Pass UH-400 Pass D-Link DU-H4 Pass ATEN UH-204 Pass TEAC CD-W28PU Pass VIOPWER VP-8258 Pass TERASYS YAMAHA CD-RW Pass DATAFAB MD3A-FW11-USB2 Pass Comments: ZIP/LS120 Vendor Model Size Type Result PANASONIC JU-811T012 100M Pass Iomega...

  • Page 50: Software Compatibility List

    SOFTWARE COMPATIBILITY LIST Version Result MS-DOS 6.22 Pass Windows Windows ME 4.90.3000 Pass Windows 2000 Profession Release Pass Windows XP Home Edition 2002 Pass Windows XP Professional 2002 Pass Linux Red hat Pass Comments:...

  • Page 51: Vcore Waveform Measurement-Ver1.4

    VCORE WAVEFORM MEASUREMENT-Ver1.4 Vcore Ripple Test(Dos Mode) Athlon_xp_2500+ M7VIG Pro1.4 STP CLK Vcore Condition Just booting on DOS mode, not running any Program Vcore ripple waveform RESULT PASS...

  • Page 52: Vcore Transient Test(Dos Mode)

    Vcore Transient Test(Dos Mode) Athlon_xp_2500+ M7VIG Pro1.4 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”...

  • Page 53: Vcore Ripple Test(Open Up The Dos Editor)

    Vcore Ripple Test(Open up the DOS Editor) Athlon_xp_2500+ M7VIG Pro1.4 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”...

  • Page 54: Vcore Ripple Test(Standby/Resume Mode)

    Vcore Ripple Test(Standby/Resume Mode) Athlon_xp_2500+ M7VIG Pro1.4 STP CLK Vcore Condition Riplle after Standby/Resume(into standby) Vcore ripple waveform RESULT PASS...

  • Page 55: Vcore Ripple Test(Standby/Resume Mode)

    Vcore Ripple Test(Standby/Resume Mode) Athlon_xp_2500+ M7VIG Pro1.4 STP CLK Vcore Condition Riplle after Standby/Resume(resume) Vcore ripple waveform RESULT PASS...

  • Page 56: Four Corner Test-Ver 1.4

    FOUR CORNER TEST-Ver 1.4 Test Equipment & Environment M/B TYPE M7 VIG Pro/1.4 CPU Level Althon_XP 2500+ RAM TYPE Twin MOS 512MB x2 VGA TYPE ASUS V8170DDR/64M SAMAUNG 512MB*2 Power Supply FSP-350-60BN Floppy PANASONIC JU-257 IDE1 Primary Maxtor 80G dma-133 IDE1 Secondary Maxtor 80G DMA-133 IDE2 Primary...

  • Page 57: Vcore Static Load Test1.4

    STATIC LOAD TEST1.4 CORE Test Environment M7VIP Pro/1.0 Power Supply FSP350-60BN VID Setting 1.75V Engineer Signature Yi-hung Electronic Loading Chroma 63030 HIP6004 O.C.P test Over 50A Pass/Fail pass O.V.P test None Pass/Fail AGP Slot PCI Slot Temperature Vcore Vcore Momey 5V ATX Loading Voltage...

  • Page 58: Thermal Image Test

    THERMAL IMAGE TEST Motherboard General Information Vendor Biostar Model Number M7VIG Pro Revision V1.2 Temperature ( ¢ J ) 35 ¢ J Humidity rate ( % ) 0 ~ 60 % Thermo Tracer NEC TH5104 Test Program 3Dmark2001 Comments: The component temperature measured value was based on 35¢ J check in the chamber...
