FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here of and specially disclaims any implied warranties of merchantability or
fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here of without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we will not
be responsible for any mistakes found in this user's manual. All the brand and
product names are trademarks of their respective companies.
M
7
V
I
G
-
D
M
7
V
I
G
-
D
M
7
V
I
G
-
D
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar M7VIGD
Summary of Contents for Biostar M7VIGD
- Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
ENGLISH ... 1 M7VIG-D Features... 1 Package contents ... 2 Layout of M7VIG-D... 3 CPU Installation ... 4 DDR DIMM Modules: DDR1-2 ... 5 Jumpers, Headers, Connectors & Slots ... 6 ESPAÑOL ... 12 Características del M7VIG-D ... 12 Contenido del Paquete ... 13 Disposición del M7VIG-D... -
Page 3: English
English M7VIG-D Features CPU: Supports the single AMD Socket A for Athlon / Duron processors. Running at 200/ 266MHz Front Side Bus. Chipset: North Bridge: VIA VT8375 (KM266) Chipset. South Bridge: VT8235 Chipset. Main Memory Supports up to 2 DDR devices. Supports 200/266MHz (without ECC) devices. -
Page 4: Package Contents
BIOS AWARD legal Bios. Supports APM1.2. Supports ACPI. Supports USB Function. Operating System Offers the highest performance for Windows 98, Windows NT, Windows 2000, Windows Me, Windows XP, LINUX and SCO UNIX. Dimensions Micro ATX Form Factor: 22.9cm X 21.3cm (W X L) Package contents HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1 Flash Memory Writer for BIOS update X 1... -
Page 5: Layout Of M7Vig-D
Layout of M7VIG-D JKBMS1 JATXPWER1 JKBV1 JUSBV2 JUSB4 JCOM1 JPRNT1 JGAME1 JUSBV1 JVGA1 JUSBLAN1 Winbond JAUDIO BIOS Codec JCODECSEL JCFAN1 VT8375 (KM 266) JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JSFAN1 FDD1 JWOL1 IDE1 IDE2 BAT1 JPANEL1 JCMOS1... -
Page 6: Cpu Installation
CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU. Press the lever down. -
Page 7: Ddr Dimm Modules: Ddr1-2
DDR DIMM Modules: DDR1-2 DRAM Access Time: 2.5V Unbuffered DDR 200/266MHz (without ECC) Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference. How to install a DIMM Module 1. -
Page 8: Jumpers, Headers, Connectors & Slots
Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100/ 133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). - Page 9 Wake On LAN Header: JWOL1 Ground 5V_SB Wake up JWOL1 Clear CMOS Jumper: JCMOS1 JCMOS1 Pin 1-2 on Pin 2-3 on Front USB Header: JUSB3 Pin Assignment Pin Assignment JUSB3 Assignment Normal Operation (default) Clear CMOS Data Data (-) Data (-) Data (+) Data (+) Ground...
- Page 10 5V/ 5VSB Selection for USB: JUSBV1/2/3 JUSBV1/2/3 Pin 1-2 on Pin 2-3 on CPU Frequency Selection: JCLK1 5V/ 5VSB Selection for Keyboard: JKBV1 JKBV1 Pin 1-2 on Pin 2-3 on AMR Codec Primary/ Secondary Selection: JCODECSEL JCODECSEL Pin 1-2 Pin 2-3 Assignment 5V_SB Close ==>...
- Page 11 Case Open Connector: JCI1 JCI1 No jumper installed Pin 1-2 on Front Panel Connector: JPANEL1 PWR_LED (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==>...
- Page 12 Audio Subsystem: JF_AUDIO/ JCDIN1 JAUDIO1 JF_AUDIO (Front Audio Header) (Front Audio Header) Assignment Mic In Mic Power RT Line Out Reserved LFT Line Out Front Panel Audio Connector/ Jumper Block Jumper Setting Pin 5 and 6 Audio line out signals are routed Pin 9 and 10 to the back panel audio line out connector.
- Page 13 Game Header: JGAME1 Pin Assignment Pin Assignment MIDI-OUTR MIDI-INR Back Panel Connectors JKBMS1 JPRNT1 PS/2 Mouse Parallel JUSB4 PS/2 COM1 Keyboard JCOM1 JGAME1 Ground Ground JUSBLAN1 Line In Speaker Mic In VGA1 JVGA1 JAUDIO...
-
Page 14: Español
Español Características del M7VIG-D CPU: Soporta procesadores single AMD Socket A para Athlon Athlon XP / Duron Corre a 200/ 266MHz Front Side Bus. Chipset: North Bridge: VIA VT8375 (KM266) Chipset. South Bridge: VT8235 Chipset. Memoria Principal Soporta hasta 2 dispositivos DDR. Soporta dispositivos 200/ 266MHz (sin ECC). -
Page 15: Contenido Del Paquete
Soporta ACPI. Soporta función USB. Sistemas Operativos Ofrece el más alto funcionamiento para Windows 98, Windows NT, Windows 2000, Windows Me, Windows XP, LINUX y SCO UNIX. Dimensiones Factor de Forma Micro ATX: 22.9cm X 21.3cm (W X L) Contenido del Paquete Cable HDD X 1 Cable FDD X 1 Completa Configuración del Driver CD X 1... -
Page 16: Disposición Del M7Vig-D
Disposición del M7VIG-D JKBMS1 JATXPWER1 JKBV1 JUSBV2 JUSB4 JCOM1 JPRNT1 JGAME1 JUSBV1 JVGA1 JUSBLAN1 Winbond JAUDIO BIOS Codec JCODECSEL JCFAN1 VT8375 (KM 266) JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JSFAN1 FDD1 JWOL1 IDE1 IDE2 BAT1 JPANEL1 JCMOS1... -
Page 17: Instalación Del Cpu
Instalación del CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU. -
Page 18: Módulos Ddr Dimm: Ddr1-2
Módulos DDR DIMM: DDR1-2 DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/ 266 MHz (sin ECC) Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 pin) Localización del Módulo Módulo DDR DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * La lista de arriba para la configuración DRAM es solamente para referencia. -
Page 19: Conectores, Cabezales, Puentes Y Ranuras
Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA 33/ 66/ 100/ 133. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así... - Page 20 Cabezal Wake On LAN: JWOL1 Tierra 5V_SB Wake up JWOL1 Puente de Borrar CMOS: JCMOS1 JCMOS1 Contacto 1-2 on Contacto 2-3 on Cabezal Frontal USB: JUSB3 Contactos Asignacion Contactos Asignacion Data (-) Data (+) Tierra Asignacion Operacion Normal (Default) Borrar Datos CMOS JUSB3 Data (-)
- Page 21 5V/ 5VSB Selección para USB: JUSBV1/2/3 JUSBV1/ 2/ 3 Contactos 1-2 on Contactos 2-3 on Selección de Frecuencia del CPU: JCLK1 Cerrado ==> 100 MHz Abierto ==> 133 Mhz JCLK1 5V/ 5VSB Selección para Teclado: JKBV1 JKBV1 Contactos 1-2 on Contactos 2-3 on Asignacion...
- Page 22 AMR Codec de Selección Primario/ Secundario: JCODECSEL JCODECSEL Contacto Contacto Conector Case Open: JCI1 JCI1 Puente sin instalar Contacto 1-2 on Conector del Panel Frontal: JPANEL1 PWR_LED (+) (-) HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==>...
- Page 23 Conector Digital de Audio: JSPDIF1 (Optional) SPDIF_OUT JSPDIF1 Subsistema de Audio: JF_AUDIO1/ JCDIN1 JF_AUDIO1 (Cabezal de Audio Frontal) Contactos Asignacion Entrada del MIC Corriente del MIC RT Salida de Linea Reservado LFT Salida de Linea JCDIN1 (Cabezal de Entrada de Audio CD-ROM) JF_AUDIO Contactos...
- Page 24 Conector del Panel Frontal de Audio/ Jumper Block Jumper Setting La senal de salida de linea del Audio Contacto 5 & 6 encamina al conector de la salida de linea Contacto 9 & 10 del Audio ubicado en el panel trasero. La senal de salida de linea del Audio y la senal del entrada del mic estan disponibles No jumpers...
-
Page 25: Deutsch
Deutsch Merkmals des M7VIG-D CPU: Unterstützt Athlon™ (Thunderbird™) / Athlon XP™ / Duron ™ Prozessoren für einzeln AMD Sockel A. Mit FSB 200/ 266MHz. Chipsatz: Northbridge: VIA VT8375 (KM266) Chipsatz. Southbridge: VT8235 Chipsatz. Hauptspreicher Unterstützung für 2 DDR Geräte. Unterstützung für 200/266MHz(ohne ECC) DDR Geräte. Die maximale Speichergröße ist 2 GB. -
Page 26: Verpackungsinhalt
Unterstützung für ACPI. Unterstützung für USB Function. Betriebsysteme Unterstützung für die am meisten verbreiteten Betriebsysteme wie Window 98, Windows NT, Windows 2000, Windows ME, Windows XP, LINUX and SCO UNIX Abmessungen Micro ATX Form-Factor:: 22.9cm X 21.3cm (W X L) Verpackungsinhalt HDD Kable X 1 FDD Kable X 1... -
Page 27: Layout Des M7Vig-D
Layout des M7VIG-D JKBMS1 JATXPWER1 JKBV1 JUSBV2 JUSB4 JCOM1 JPRNT1 JGAME1 JUSBV1 JVGA1 JUSBLAN1 Winbond JAUDIO BIOS Codec JCODECSEL JCFAN1 VT8375 (KM 266) JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JSFAN1 FDD1 JWOL1 IDE1 IDE2 BAT1 JPANEL1 JCMOS1... -
Page 28: Installation Der Cpu
Installation der CPU Ziehen Sie den Hebel seitwärts von der Sockel und neigen Sie ihn um 90-Grad nach oben. Suchen Sie Pin A im Sockel und den weißen Punkt oder die Abschnittkante in der CPU. Passen Sie Pin A mit dem weißen Punkt/der Abschnittkante zusammen und legen Sie danach die CPU ein. -
Page 29: Ddr-Dimm-Modules: Ddr1-2
DDR-DIMM-Modules: DDR1-2 DRAM Zugriffszeit: 2.5V unbuffered DDR 200/266MHz (ohne ECC) Typen required. DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin) DIMM-Sockel DDR-Module Standort DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * Die obere Liste für DRAM-Konfiguration wird als Referenz gezeigt. Installation von DIMM-Modulen 1. -
Page 30: Jumpers, Headers, Connectors & Slots
Riser-Karte-Interface von Hardware definiert , das nur Modem und Soundfunktion unterstützt. Peripheral Component Interconnect Slots: PCI1-2 Dieses Motherboard ist mit 2 standardmäßigen PCI-Slots ausgestattet. PCI steht für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für Erweiterungskarten, der den älteren ISA-Busstandard in den meisten Schnittstellen ersetzt hat. - Page 31 Wake On LAN Header: JWOL1 Grund 5V_SB Erwachen JWOL1 Clear CMOS Jumper: JCMOS1 JCMOS1 Pin 1-2 geschlossen Pin 2-3 geschlossen Front USB Header: JUSB3 Pin Beschreibung Pin Beschreibung JUSB3 Beschreibung Normale Operation (Default) CMOS-Daten l schen Data (-) Data (-) Data (+) Data (+) Grund...
- Page 32 5V/ 5V_SB Auswahl für USB: JUSBV1/2/3 JUSBV1/2/3 Pin 1-2 geschlossen Pin 2-3 geschlossen CPU Frequenz Auswahl: JCLK1 geschlossen ==> 100 MHz geoffnet ==> 133 Mhz JCLK1 5V/ 5VSB Auswahl für Tastatur: JKBV1 JKBV1 Pin 1-2 geschlossen Pin 2-3 geschlossen Beschreibung 5V_SB Beschreibung 5V_SB...
- Page 33 Auswahl für Primär/ Sekundär AMR Codec: JCODECSEL J_CODECSEL Pin1-2 geschlossen Pin 2-3 geschlossen Anschluss für Gehäuse-Öffnen: JCI1: JCI1 JCI1 Kein Jumper geschlossen Pin 1-2 geschlossen Front Panel Connector: JPANEL1 PWR_LED (+) (-) HLED ==> Lautsprecheranschl. HLED ==> Festplattenanzeige ==> Reset-Taste ==>...
- Page 34 Digital-Audio-Anschluss: JSPDIF1 (optional) SPDIF_OUT JSPDIF1 Audio Subsystem: JF_AUDIO/ JCDIN1 JAUDIO1 JF_AUDIO (Front Audio Header) (Front Audio Header) Beschreibung Mic-In Mic Power RT Line-Out Reserviert LFT Lin-Out Grund JCDIN1 JCDIN1 (CD-ROM Audio-In Header) (CD-ROM Audio-In Header) JF_AUDIO1 Beschreibung Grund Audio Power RT Line-Out LFT Line-Out...
- Page 35 Audio-Anschl sse f r die Vorderseite/ Jumper-Block Jumper-Einstellen Audio-Ausgang-Singals werden zu der Audio- Pin 5 und 6 Ausgang-Anschluss an der R ckwand geleitet. Pin 9 und 10 Audio-Ausgang- und Mic-In-Singals sind verf gbar Kein Jumper f r Audio-Anschl sse an der Vorderseite. installieren Game Header: JGAME1 Pin Beschreibung Pin Beschreibung...
- Page 36 Anschlüsse auf der Rückseite JKBMS1 JPRNT1 PS/2- Maus Parallel JUSB4 PS/2- COM1 Tastatur JCOM1 JUSBLAN1 Line-In Lautsprecher- Ausgang Mic-In VGA1 JVGA1 JAUDIO...
-
Page 37: Warpspeeder
WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage. -
Page 38: Installation
Installation Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [WarpSpeeder™] utility will be automatically and immediately launched after you click “Finish”... -
Page 39: Usage
Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [WarpSpeeder™] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side... - Page 40 This utility is responsible for conveniently invoking [WarpSpeeder™] Utility. You can use the mouse by clicking the left button in order to invoke [WarpSpeeder™] directly from the little tray icon or you can right-click the little tray icon to pop up a popup menu as following figure.
- Page 41 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not. The default setting is “No”.
- Page 42 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure.
- Page 43 Overclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment. Warning: Manually overclock is potentially dangerous, especially when the overclocking percentage is over 110 %. We strongly recommend you verify every speed you overclock by click the Verify button.
- Page 44 “Auto-overclock button”: User can click this button and [ WarpSpeeder™ ] will set best stable [ WarpSpeeder™ ] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [ WarpSpeeder™...
- Page 45 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
- Page 46 Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions.
-
Page 47: Trouble Shooting
Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning. -
Page 48: Solución De Problemas
Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está... -
Page 49: Problemlösung
Problemlösung MÖGLICHE URSACHE Das System hat keine Spannungsversorgung. Die Stromanzeige leuchtet nicht, der Lüfter im Inneren Stromversorgung wird eingeschaltet. Tastaturleuchten sind nicht an. MÖGLICHE URSACHE System funktioniert nicht. Tastaturleuchten sind an, die Stromanzeige leuchtet, die Festplatte dreht sich. MÖGLICHE URSACHE Das System wird von der Festplatte nicht hochgefahren, vom CD-ROM-Treiber aber ja. - Page 50 03/14/2003...
