a. Click Wireless Settings in the main
menu. Select a Region. Do not change
the other settings. Click Apply
b. Configure your computer to use the
Network Name (SSID) NETGEAR
with WEP Security disabled.
Warning: The Network Name (SSID)
is case sensitive. You must enter NETGEAR in your computer's wireless
settings. Entering nETgear will not work.
c. To verify wireless connectivity, connect to the Internet or log in to the
wireless router from a computer with a wireless adapter.
d. You are now connected to the Internet and the wireless feature of the
wireless router is enabled! Next, configure your wireless computers to
connect to the NETGEAR Network Name (SSID).
Now, Set Up a Computer for Wireless Connectivity
1. Configure the computer's Wireless Settings
Windows displays a list of available wireless networks,
and, when wireless security is disabled, you simply
choose yours from the list and connect.
2. Verify Wireless Connectivity
Connect to the Internet from a computer with a wireless
adapter.
You are now wirelessly connected to the Internet!
Important: Implement wireless security options appropriate to your needs.
The NETGEAR wireless router provides many wireless security options.
Your wireless computer may not support all of these options. Please log in to
the router and read the help to identify the wireless security features of your
router that satisfy your requirements and work with your wireless computer.
Troubleshooting Tips
Here are some tips for correcting simple problems you may have.
Be sure to restart your network in this sequence:
1) Turn off the modem, wireless router, and computer; 2) Turn on the modem,
wait two minutes; 3) Turn on the wireless router and wait 1 minute; 4) Turn
on the computer.
Make sure the Ethernet cables are securely plugged in.
•
The Internet status light on the wireless router will be lit if the Ethernet cable
to the wireless router from the modem is plugged in securely and the modem
and wireless router are turned on.
•
For each powered on computer connected to the wireless router with a
securely plugged in Ethernet cable, the corresponding wireless router LAN
port status light will be lit. The label on the bottom of the wireless router
identifies the number of each LAN port.
Make sure the wireless settings in the computer and router match exactly.
The Wireless Network Name (SSID) and WEP security settings of the router
and wireless computer must match exactly.
Make sure the network settings of the computer are correct.
•
Ethernet cable and wirelessly connected computers must be configured to
obtain IP and DNS addresses automatically via DHCP.
November 2008
Check the router status lights to verify correct router operation.
•
If the Power/Test light does not turn solid green within
2 minutes of turning the router on, or turn the power off
and back on to see if the router recovers. Or, use a pen
tip to press and hold for 10 seconds the reset-to-default
button on the back of the router to clear the router's
configuration to factory defaults to see if the router
recovers.
•
If the Wireless light does not come on, verify that the
wireless feature is turned on by logging in to the router,
and checking the "Enable Wireless Router Radio" box
in the Advanced Wireless Settings menu.
Technical Support
Thank you for selecting NETGEAR products.
After completing the Smart Wizard configuration assistant, register your product
at http://www.NETGEAR.com/register. Registration is required before you can
use our telephone support service.
Warning: Do not install this device on top of any other electrical equipment or
install any other equipment on top of this device. Keep this device away from any
heat sources such as direct sunlight, heaters, radiators, or other A/V receivers or
devices that emit heat.
This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste
Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European
Union, this product should be treated and recycled in accordance with the laws of your jurisdiction
implementing the WEEE Directive.
© 2008 by NETGEAR, Inc. All rights reserved. NETGEAR and the NETGEAR logo are registered trademarks
of NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or
registered trademarks of their respective holders. Information is subject to change without notice.
Reset
Button
