- Page 1 SCTeci Ethernet Control Interface Instruction Manual is a trademark of the R.L. Drake Company is a registered trademark of the R.L. Drake Company © Copyright 2008 R.L. Drake Company P/N: 3852392B-01-2008 Printed in U.S.A.
- Page 2 Caution Statements WARNING: TO PREVENT FIRE OR A product and cart combination should be moved with ELECTRICAL SHOCK DO NOT care. Quick stops, excessive force and uneven EXPOSE TO RAIN OR MOISTURE surfaces may cause the product and cart combination to overturn.
- Page 3 Important Safety Instructions 1. Read Instructions—All the safety and operating instructions should be read 14. Outdoor Antenna Grounding—If an outside antenna or cable system is before the product is operated. connected to the product, be sure the antenna or cable system is grounded so 2.
- Page 4 10 Base T LAN or Internet via Ethernet Port, RJ-45. Network Interface: RS232 serial port, DB9. Output Interface to Headend: Each SCTeci has an unique address. MAC address: User may program a static IP address or may choose it to IP address: be assigned by DHCP.
- Page 5 PS151 Power Supplies. Internet or LAN. Control of up to 63 SCT860 transcoders The SCTeci is contained in a 1.75” x 19” standard rack and up to 70 SCTx860 transcoders is possible using a single SCTeci.
- Page 6 250 mA capacity. The center connected to the 'RS232 IN' connector of the transcoder terminal is positive. The SCTeci will be on as soon as power supply. Multiple power supplies should be "daisy power is applied to this connector.
- Page 7 Connect the 12 VDC connector to an appropriate source of 'adjust' mode when on a screen that does not have a 12 VDC with at least 250 mA DC capacity. The SCTeci will changeable parameter. i.e.: 'Board Setup' and 'SCTeci /IP activate as soon as power is supplied.
- Page 8 Selecting SCT860 61-63 will produce a table for only three SCTeci. Skip this step if you do not know the password transcoders. The entries for each transcoder will be as...
- Page 9 To modify parameters of any monitored transcoder, you require a password, this SCT password must be entered must first do one of the following: into the SCTeci. Do not confuse this with the SCTeci From the select mode menu, select 'single SCT860', PASWRD. Proceed as follows.
- Page 10 SCT Control program software. and channel that you wish to delete. You can use the browser connection through the SCTeci to Press the 'Delete Channel' button. This will remove make these changes initially, before the settings are the channel from the 'Preset Channels' list.
- Page 11 Using the R. L. Drake SCT Control Program with 3) Finalize any edits on the PC. the SCTeci Combining the use of the SCTeci and the R.L. Drake 4) Make sure all headends that are going to receive a SCT Control program allows the operator to create download have been connected and set up with a multiple headend files on a PC using the R.L.
- Page 12 1 through 5, below. If all of the SCTs are already loaded with a common password, you will not need to reload the transcoders, only give this password to the SCTeci - skip step 3 in the sequence below. 1) Before the SCTs are in 'LOADING PASSWORD', using your browser, enter the IP address of the SCTeci in the address box.
- Page 13 Service / If You Need To Call For Help SERVICE INFORMATION Should you want to return your unit for service, package You may contact the R.L. DRAKE Service Department for the unit carefully using the original carton or other additional information or assistance by calling suitable container.
- Page 14 14 Warranty Three Year Limited Warranty R.L. DRAKE COMPANY warrants to the original purchaser this product shall be free from defects in material or workmanship for three (3) years from the date of original purchase. During the warranty period the R.L. DRAKE COMPANY or an authorized Drake service facility will provide, free of charge, both parts and labor necessary to correct defects in material and workmanship.
- Page 15 R.L. Drake Company 230 Industrial Drive Franklin, Ohio 45005 U.S.A. Customer Service and Parts Telephone: +1 (937) 746-6990 Telefax: +1 (937) 806-1576 World Wide Web Site: http://www.rldrake.com...
