- Page 1 BBE DI-10 USER MANUAL...
- Page 2 Use the following illustrations as a starting point for proper placement of the BBE DI-10. BBE DI-10 direct box! The BBE DI-10 is an active direct box used for converting line out and speaker out signals to balanced and unbalanced signals. The user also SPEAKER OUT...
- Page 3 9 volt battery. 6. BALANCED OUT: This XLR jack provides a mic level balanced output. Pin 2 being the ‘hot’ pin. The DI-10 can also be phantom powered through this jack. NOTE: This unit may be powered by three (3) different modes.
- Page 4 (USING A 9V BATTERY) TOTAL HARMONIC DISTORTION ..0.02% (20hz - 20khz) The BBE DI-10 Active Direct Box is warranted against defects in material and workmanship for a period of five INPUT CHARACTERISTICS (5) years from date of purchase from BBE Sound, Inc. or from an authorized dealer.
