LIVE APPLICATION: INdIVIdUAL INSTRUMENTS
The BBE 382isw can be used in bass, keyboard and other instrument rigs where a sub-woofer is required
to reproduce the full frequency range of the instrument. Use the appropriate hookups to use the 382isw in
either stereo or mono configurations.
INSTRUMENT PREAMP
MAIN
OUTPUTS
MONO OR STEREO SUB-WOOFER
FULL-RANGE POWER AMP AND
SPEAKERS SPEAKERS
10
