BBE MAGNUM D.I. Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for BBE MAGNUM D.I.

Summary of Contents for BBE MAGNUM D.I.

  • Page 1 Owner’s Manual...

  • Page 2: Features Include

    Thank you for your purchase of the Magnum DI! The Magnum DI is a heavy-duty, high-quality active direct box that performs like our DI-100x, but without the built-in Sonic Maximizer. This unit is a professional grade direct box for stage and permanent installation applications.

  • Page 3: Contents Checklist

    If any of these items are found to be damaged or missing, Please contact the dealer from which the unit was purchased. We recommend reading this manual to familiarize yourself with all of the features of the Magnum DI before using. Should you have any questions, please contact BBE at 800-233-8346.

  • Page 4: Getting Started

    Getting Started 1. Hi-Z Input: 1/4” unbalanced instrument input. 2. +48v Phantom Power Status: LED illuminates when proper voltage is supplied to unit via the XLR jack (Low-Z Output). 3. Pad Switch: Depressing the switch engages a 20dB pad that prevents overload on the input.
  • Page 5 Getting Started 4. Low-Z Output: XLR balanced jack 5. Thru: 1/4” unbalanced is wired in parallel jack to the Input connector and is used to connect to the instrument amplifier input. When in 6. Ground Lift: the “lifted” position Pin 1 of the balanced XLR output (ground) is disconnected from...
  • Page 6 CURSOR ENTER STEREO The Magnum DI is designed for a direct connection to the output jack of your instrument (guitar, bass or keyboard). It provides a convenient method to split the signal to simultaneously feed the input of an instrument amp and a mixing board or DAW.
  • Page 7 Applications Note: The Magnum DI requires the use of +48v Phantom Power supplied by the mixing console. This is a common feature to most mixers, however, please make sure the mixer in use is equipped to supply +48v Phantom Power.
  • Page 8 Service There are no user serviceable parts inside. Should the Magnum DI require service please contact our Service Department for a Return Authorization at: BBE Sound, Inc. 800-233-8346 Ext.116 For service outside of North America please contact your local distributor. For a listing of BBE Distributors log on to:...

  • Page 9: Technical Specifications

    Technical Specifications Frequency Response: ––––––––10Hz to 50kHz (+/- 1dB) THD: ––––––––––––––––––––––––less than 0.005% at -l0dBu input 20-20kHz Input Impedance:––––––––––––Pad out (0dB): 1 MEG Ohms Pad in (-20dB): 12k Ohms XLR: 600 Ohms Output Impedance: –––––––––– Power Requirements:––––––––XLR: +48V Phantom Power Dimensions: ––––––––––––––––3 1/2"(W) x 5"(D) x 1 13/16"(H) Shipping Weight: ––––––––––––2.1 lbs.

  • Page 10: Warranty

    REQUESTED. 4. The equipment has been modified without authorization. The BBE Magnum DI is warranted against defects in 5. The bill of sales indicates that the purchase date material and workmanship for a period of five (5) of the equipment is not within the warranty years from date of purchase from BBE Sound Inc.

  • Page 11: Important Safeguards

    Important Safeguards For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance and described in operating instructions supplied with the appliance. INSTALLATION product.
  • Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 Phone 714-896-0736 Fax • bbesound.com BBE is the registered trademark of BBE Sound, Inc. rev.1 4/10...
