Data Warehouse Server; Data Warehouse Database; Data Warehouse Cube - TANDBERG ANALYTICS EXTENSION Administrator's Manual

Analytics Extension components and roles
Analytics User
VCS
Data Warehouse
Feedback
Server
CUBE
tmsng_dwh
TMS Web Server
tmsng
TMS SQL Server
Figure 1 Illustration of Roles and Components

Data warehouse server

Analytics Extension comprises two major elements - the data warehouse database, and the data
warehouse CUBE.

Data warehouse database

The data warehouse database is used for analysis and data mining, and contains information from the
TMS database combined with data computations and analysis.
Using credentials specified by the installing user, the data warehouse database is created in a SQL
server instance of the data warehouse server. The default database name is tmsng_dwh. The DWH
(data warehouse) service user is defined as the owner of the database, and this service account is
used by the Analytics Extension to log into the database for ongoing operations. Ordinary users of the
Analytics Extension API do not connect to this database.
The data warehouse database accesses the TMS database through a linked server, created on the
data warehouse server during installation. The linked server is created automatically using the TMS
database location and DWH TMS service user credentials supplied during installation. The DWH TMS
service user is an SQL login for the TMS SQL server. This account only needs db_datareader role to
access the TMS database, and can reuse any existing login with sufficient SQL access permissions.

Data warehouse CUBE

The data warehouse CUBE is a specialized type of database used in analysis and data mining. Its
main advantage is its ability to hold pre-computed aggregates of data across many different
dimensions, allowing fast manipulation of queries. The data warehouse CUBE holds different data
defined as „facts‟, each of which has different defined „dimensions‟, which can be used to manipulate
the information stored in the different fact tables. Analytics Extension provides sets of facts and
dimensions that can be used by programmers and analytics users.
The data warehouse CUBE is created during installation in the Analysis Services instance on the data
warehouse server. The default name for the database is tmsng_dwhAsDb (its name format must
always be <database>AsDb). The DWH service user is configured as the owner of the CUBE and the
DWH service user credentials are used by Analytics Extension to connect to the cube for ongoing
operations. Ordinary users of the Analytics Extension API connect to this CUBE using an OLAP client
and their Windows Domain accounts (with reader role permissions).
Add http pump ref
The data warehouse CUBE connects to the data warehouse database using a data source defined
configured to use the DWH service user credentials.
TANDBERG Analytics Extension Admin guide 8
