- Page 1 PRODUCT SUPPORT MANUAL Y1-03-0141 Rev. B RCL-50B™ Remote Control Searchlight Master Controller Point Pad ACR Electronics, Inc. 5757 Ravenswood Road Fort Lauderdale, Fl 33312 +1(954) 981-3333 · Fax +1 (954) 983-5087 www.acrelectronics.com Email: Info@acrelectronics.com A Chelton Group company...
-
Page 2: Table Of Contents
RCL-50B TABLE OF CONTENTS SECTION TITLE PAGE Forward General Searchlight Remote Control System URP-102 Point Pad™ URC-102 Master Controller RCL-50B Specifications Bulb Replacement RCL-50B Searchlight Components 10.0 Remote Control System Components FIGURES TITLE PAGE Figure 1 Remote Control Searchlight System Figure 2 Point Pad™... -
Page 3: Forward
RCL-50B, 12/24V REMOTE CONTROL SEARCHLIGHT SYSTEM FIGURE 1: REMOTE CONTROL SEARCHLIGHT SYSTEM FORWARD Congratulations and thank you for purchasing the ACR RCL-50B Searchlight. The combination of computer aided design, high quality raw materials, and quality-controlled manufacturing produce a superior product. The Test Facility at ACR can reproduce some of the harshest environmental conditions known to man. -
Page 4: General
GENERAL The RCL-50B was specially designed for mariners who require a high intensity remote controlled searchlight that can stand up to the tough marine environment. The RCL-50B Searchlight System contains a narrow beam searchlight that produces 80,000 peak candle power by combining a 55W halogen lamp on the 12V version or a 70W halogen lamp on the 24V version with our unique optical quality parabolic reflector. -
Page 5: Urp-102 Point Pad
“F” connectors attached to the coax cable, simply screw the “F” connectors to the Master Controller and the Point Pad™. The cable and connectors are available either through ACR Electronics, your local Radio Shack or other sources of electronic hardware. - Page 6 URC-102 URC-102 Master Master Controller Unit Controller Unit RG-59 Coaxial Cable RG-59 Coaxial Cable Fuse Fuse “T” Conn. URP-102 or Splitter Point Pad RG-59 Coaxial Cable Power Power Source Source URP-102 Point Pad RG-59 Coaxial Cable URP-102 Point Pad Single Point Pad ä Multiple Point Pads ä...
- Page 7 URP-102 Point Pad Functions · Press the ON/OFF button to turn the lights ON or OFF. · Press the SPEED button to toggle between High and Low rotation speeds. · Press the Right or Left Arrows to rotate the Searchlight in that direction. ·...
-
Page 11: Urc-102 Master Controller
URC-102 MASTER CONTROLLER Mounting The Master Controller can be mounted in any position near the Searchlight that is protected from the weather. Check in advance that the coax cable from the Point Pad™ and the wiring harness from the Searchlight can be routed to this location. Mount the Master controller with the wires and coax facing down. - Page 12 Wiring to Power Supply The power source must be a fused 12 VDC, 5-amp supply or 24 VDC, 3-amp supply. Following the wiring scheme in Table 1, use the supplied butt connectors to connect the Master Controller to the Power Source. Refer to Table 2 for proper wire size for connection of the input power lines.
-
Page 13: Figure 7 Urc-102 Master Controller Wiring Diagram
NOTE: The Searchlight should not be covered while the XRCiZ feature is enabled. The URC-102 Master Controller provides optimum voltage to ensure the brightest Searchlight performance and long bulb life. Also to extend lamp life, the Master Controller has a timed lamp power up feature. -
Page 14: Figure 8 Urc-102 Master Controller
[8.6] 2.80 [71.1] 4.50 [114.3] 3.63 [92.2] 3.64 1.15 [92.5] [29.2] Figure 8: URC-102 MASTER CONTROLLER Y1-03-0141 Rev. B... -
Page 15: Rcl-50B Specifications
RCL-50B SPECIFICATIONS (with URC-102 Controller) Specifications 12V UNIT 24V UNIT Mirror Diameter 4" Same Rated Voltage (Volt) 12 to 16 VDC 24 to 31 VDC Rated Current (A) Applicable Lamp 55W Halogen 70W Halogen Lamp Lamp (Base-x511) (Base-x511) H212V-55W H2-37R-00624 Peak Beam Candle Power (candela) 80,000 80,000... -
Page 16: Bulb Replacement
BULB REPLACEMENT A quartz-halogen bulb is provided with your RCL-50B. If the bulb should need replacement, it must be ordered through ACR Electronics, by P/N A1-14-0090-1 (12V units) or A1-14-0090-2 (24V units). To replace the lamps: Disconnect unit from power source and allow bulb to cool. -
Page 17: 10.0 Remote Control System Components
PRODUCT NO. 1940.3 - RCL-50B 24 V Searchlight Installation Kit includes: Description Quantity ACR Part Number Searchlight, RCL-50B, 24 V A3-06-0092-4 Kit, Nylon Washers (4) A3-06-1940 Connector, “F” A1-03-0220 Cable, Coaxial A2-07-0002-6 Master Controller, URC-102 A3-06-2231 Connector, "In-Line" A1-03-0222 Point Pad™, URP-102 with Surface Mount Case A3-06-2230 Case, Flush Mount... - Page 18 Adapter Plate, Surface mount A1-18-1892 Instruction Sheet, Point Pad™ Y1-06-0179 Mounting Templates Y1-03-0138-1 PRODUCT NO. 1929.1 - Wiring Kit RCL-50 / 100 Series Searchlights Includes: Description Quantity ACR Part Number Connector, “F” A1-03-0220 Cable, Coaxial A2-07-0002-6 PRODUCT NO. 9282.3 – URP-102 Point Pad™ Secondary Station Installation Kit includes: Description Quantity ACR Part Number...
- Page 19 PRODUCT NO. 9283.3 – Remote Control Installation Kit Includes: Description Quantity ACR Part Number Master Controller, URC-102 A3-06-2231 Connector, "In-Line" A1-03-0222 Point Pad™, URP-102 with Surface Mount Case A3-06-2230 Case, Flush Mount A1-18-1875-2 Gasket, Surface Mount A1-25-0140-1 Gasket, Flush Mount A1-25-0140-2 U Clamp A1-17-1366...
