3.0
BEFORE YOU RUN SETUP
Before you run the FPR-100/10 software, please make sure that your computer
meets the minimum requirements in section 3.2.
3.1
FPR-10 Components
See Figure 5 for a visual representation of each component listed below.
FPR-10 Interface Unit (Module Assembly)
Programming Head, PLB
Programming Head, RLB-32/33
Serial Cable Assembly
6 Conductor Cable with RJ11 plug (phone)
240 VAC / 12v DC, 800 mA Euro Compatible
Power supply
3.2
Check the Hardware and System Requirements
To run the FPR-10, you must have certain hardware and software installed on your
computer. The requirements include:
Microsoft Windows 95 / 98 /, NT4.0, 2000 or ME.
Pentium 75 MHz microprocessor (minimum).
A hard disk with at least 10 megabytes of available storage.
VGA or higher-resolution screen supported by Microsoft Windows.
16 megabytes of RAM.
A mouse or other pointing device.
1 available serial port.
Printer (optional)
4.0
INSTALLING THE FPR-100/10 SOFTWARE
The
FPR-100/10
http://www.acrelectronics.com/download.html. The software is installed using the
setup program included on disk 1. The setup program will install all of the needed
files to your hard disk automatically. The software must be installed in the
C:\FPR100 directory to work correctly. This directory is the default directory in
the setup program.
1. Place the disk marked 1 of 4 into the floppy drive of your computer.
2. Click the START button on the bottom of your Windows operating system.
3. Type a:\setup.exe and press ENTER.
software
may
be
3
A3-06-2260
A3-06-2117
A3-06-2119
A3-06-2129
A2-07-0137
A3-03-0263
downloaded
from
the
web
at
Y1-03-0164 Rev. A
