- Page 1 PRODUCT SUPPORT MANUAL Y1-03-0116 Rev. C L-32 Field Marker Lighting System L-32 L-32 RC L-32 RCL CC-1 ACR Electronics, Inc. 5757 Ravenswood Road Fort Lauderdale, Fl 33312 +1(954) 981-3333 Fax +1 (954) 983-5087 www.acrelectronics.com Email: Info@acrelectronics.com A Chelton Group company...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION DESCRIPTION PAGE 1.0 ........Introduction............2 2.0 ........Complete System Overview ........3 3.0 ........Subsystems ............4 4.0 ........System Set-up and Operation ........ 5 5.0 ........Customizing the Activation Code ......8 6.0 ........Code Configuration Set-up ........9 FIGURE DESCRIPTION PAGE... -
Page 3: Introduction
The ACR Field Marker Light System is an evolutionary refinement of signaling technology that exemplifies how we can improve upon and redefine the application of existing systems. Working with the United States military, ACR Electronics provided a solution to a critical combat situation problem. -
Page 4: Complete System Overview
Since the introduction of the Field Marker System, ACR has expanded it to be available in a sequential version as well. COMPLETE SYSTEM OVERVIEW The ACR/L-32 or L-32RCL may be plugged directly into the BA-4386 or BA-5598 Battery and act as a stand alone, manually controlled light. For remote controlled operation, the ACR/L-32 may be inserted into the ACR/L32RC which in turn is inserted into the battery. -
Page 5: Subsystems
SUBSYSTEMS 1. The Model ACR/L-32 Field Marker Light (See Figure 1) The ACR/L-32 light is designed to plug into a BA-4386 or BA-5598 Battery. Canvas straps are provided for holding the light to the battery, and the combination to the ground (use spikes or long nails to secure the canvas strap to the ground). -
Page 6: System Set-Up And Operation
SYSTEM SET-UP AND OPERATION Manual Activation 1) Insert the ACR/L-32 or ACR/L-32 RCL Light into a BA-4386 or BA-5598 Battery. 2) Press the Push-ON, Push-OFF switch for the desired position (light will turn ON or OFF accordingly). 3) Repeat steps 1 and 2 for all additional lights. (Each light must have its own battery.) Figure 3 ACR / L-32 RCL... - Page 7 6) Set the PRC-77 to a transmit mode. 7) Turn the ACR/CC-1 ON and position it next to hand-set of the PRC-77, make sure the microphone of the ACR/CC-1 is facing the microphone on the hand-set. 8) On the key pad, press button number 1, 2, or 3 to turn light(s) ON, or press button number 4, 5, 6, or 7 to turn light(s) OFF (see Note 2).
- Page 8 Figure 5: ACR/L-32 / L-32 RC Combo Remote Light System Remote Controlled Activation of the ACR/L-32RCL unit (See Figure 6) 1) Insert the ACR/L-32RCL Remote Controlled Light directly into the battery. 2) Plug antenna onto banana plug. 3) Secure the complete assembly of the light, and battery together with the canvas hold down strap and secure the light to the ground with a long nail or stake down pins.
-
Page 9: Customizing The Activation Code
7) Codes 4, 5, 6 are pre-programmed as "OFF" code at the factory and 1, 2, 3 are preprogrammed as "ON" codes. (See Note 2) Note 1: Code number 7 is always the universal "OFF" and cannot be reprogrammed for any other function. Note 2: The codes on the ACR/L-32RCL Remote Controlled Light are factory preset, however, other code combinations are able to be set by the user. -
Page 10: Code Configuration Set-Up
Wall of case ON or Activation OFF or Deactivation Codes Codes This depicts a code 1 This depicts a code 3 will turn the light "ON" will turn the light "OFF" Figure 7: SETTING THE ON AND OFF REMOTE CODES CODE CONFIGURATION SET-UP To access the DIP switch Remove rear cover of the ACR/L-32RC unit by removing 4 phillips-... - Page 11 Example 1: Light shall turn "ON" when code 1 is selected. Set-up: Set DIP switch number 1 to "ON" position (away from the case wall), set all others (2, 3, 4, 5, and 6) to "OFF" position (toward the case wall). Setting the "OFF"...
-
Page 12: Replacement Parts List And Figure
Lamp (GE 94 or 104) A1-14-0101 Lamp, Halogen 2005 A3-06-1420 Hold Down Strap A3-06-1565 Antenna for RC A3-06-1565-1 Antenna for L-32 RCL POWER BATTERY LOW MODEL No. SERIAL No. CC-1 TYPE CODE CONTROLLER ACR ELECTRONICS, INC. FT. LAUDERDALE, FL 33312 U.S. Y1-03-0116 Rev. C... - Page 13 NOTES: Y1-03-0116 Rev. C...
