ISIS iQ UNO ™ parts
Pump parts
a
h
g
b
c
d
i
e
j
f
1x Funnel cover (same as
a 1x Control handle h
1x Silicone diaphragm with stem 1x Battery pack
b i
1x Wall plug lead
c 1x White Valve j
1x Pump body 1x Dome cap
d k
1x Newborn Teat (0m+)
e 2x Reusable bases
l
(1x 125ml/4oz and 1x 260ml/9oz) 2x Screw rings
m
1x Travel cover
1x Stand (same as ) n
f h
g 1x Let-down Massage Cushion™ 2x Sealing discs
o
2
Main parts in detail
Bottle
parts
Power socket
k
Control button
l
Control handle
m
n
Power cable
o
)
f
Only the following batteries are compatible
with the ISIS iQ UNO™ Battery Pack:
Duracell Ultra M3, Duracell Plus, Energiser
Ultra Plus, Duracell Accu (NiMH),
Ansmann (NiMH). For Duracell Acc (NiMH)
& Ansmann (NiMH) use / charge in
accordance with manufacturers
guidelines. Dispose of batteries as per
manufacturers instructions.
Light
Control handle
NEVER STERILISE OR IMMERSE IN WATER!
Battery pack
NEVER STERILISE OR IMMERSE IN WATER!
3
Cracking or • Avoid contact with antibacterial detergents/cleaners
discolouration as they can damage the plastic. Combinations of
of pump parts detergents, cleaning products, sterilising solution,
softened water and temperature fluctuations may,
under certain circumstances, cause the plastic to
crack. If this occurs, do not use. The pump body and
breast milk containers are dishwasher safe but food
colourings may discolour them. Follow guidelines
in 'How to clean and sterilise your ISIS iQ UNO™'
on pages 5-6.
Lost or • Contact the AVENT Customer Services for
broken parts replacements (see back cover for contact details).
Pump not • Ensure the pump is correctly assembled and switched
responding on with the power indicator illuminated 'GREEN'.
• Make sure the lead between the electrical wall
socket or battery pack and the pump is correctly
connected.
Pump light • 3 flashes, delay, 3 flashes etc – if the pump stops
flashing RED working and the power light is flashing RED the
pump has detected a vacuum fault. Disconnect the
power and check the control handle and diaphragm
for obstructions or damage.
• Continuous RED pulsing flash – Low battery warning.
You should consider replacing the batteries.
Difficulties • The pump must be switched off via the control
separating the button in order to separate these parts. If the
control handle from batteries go flat mid-pumping, you may experience
the pump body difficulty. Replace the batteries or connect the pump
to the mains. Turn the pump on by holding down the
control button for 2 seconds – the light will turn
GREEN. Now turn it off by holding the button for
2 seconds – the light will go off. You can now
disconnect the pump from the power supply and
should be able to separate the parts.
