Dacor Distinctive DCT305 Planning Manual
Distinctive series 30” and 36” wide, drop-in gas cooktops
Hide thumbs
Also See for Distinctive DCT305:
- Use and care manual (21 pages) ,
- Installation instructions manual (16 pages) ,
- Installation instructions manual (15 pages)
Advertisement
Quick Links
Document # PG04-006
•
Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
•
This appliance must be installed in accordance with the
accompanying installation instructions.
Product tolerances ±1/16" (±1.6 mm) unless otherwise noted.
Model
(a)
DCT305
30" (76.2 cm)
DCT365
36" (91.4 cm)
Rear
overhang
1 3/16 "
(3.0 cm)
Front of unit
Specifications subject to change without notice.
DCT305, DCT365
30" and 36" Wide, Distinctive series
Drop-in Gas Cooktops
warning
2" (5.1 cm)
countertop
to cooking surface
4" (10.2 cm)
chassis height
(B)
27 5/16" (69.4 cm)
33 5/16" (57.8 cm)
19 9/32" (49.0 cm)
Side View
Power cord
42" (106.7 cm) long
UTILITy LoCATIoNs
Front
overhang
17/32"
1 11/32"
(1.3 cm)
(3.4 cm)
Product Dimensions
1/2" male
NPT gas inlet
www.dacor.com
B
Front View
Front of cooktop
Power
1/2" male NPT
cord in
gas inlet*
1 3/4"
(4.4 cm)
1 3/4"
(4.4 cm)
(5.1 cm)
*Gas inlet protudes 1/2" (1.3 cm) from bottom
UTILITy DImENsIoNs
Revised 08/19/11 Page 1/4
PLANNING
GUIDE
A
21"
(53.3 cm)
1 11/32"
(3.4 cm)
Chassis
2"
Top panel overhang
4.18
Phone: (800) 793-0093
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dacor Distinctive DCT305
Summary of Contents for Dacor Distinctive DCT305
- Page 1 DCT305, DCT365 Document # PG04-006 Revised 08/19/11 Page 1/4 30” and 36” Wide, Distinctive series PLANNING Drop-in Gas Cooktops GUIDE warning • Observe all governing codes and ordinances during planning and installation. Contact your local building department for further information.
-
Page 2: Electrical Requirements
DCT305, DCT365 Document # PG04-006 Revised 08/19/11 Page 2/4 30” and 36” Wide, Distinctive series PLANNING Drop-in Gas Cooktops GUIDE Electrical requirements gas Supply requirements ◊ Be certain that the cooktop being installed is correct for the gas warning service being provided (natural gas or LP gas). Also, if operating the cooktop at an altitude above 4000 ft. - Page 3 Vent Compatibility See cutout Model DCT305 is not compatible with a raised vent. If installing cooktop model DCT365 with a raised vent, install only Dacor raised vent model dimensions ERV3615. Installation of any other raised vent model may cause improper 1 5/8”...
- Page 4 6 7/8” (17.5 cm) 33 5/8” (85.4 cm) DCT365 with ERV3615 raised vent 3/8” (1.0 cm) 22 3/4” (57.8 cm) * Model DCT305 is not compatible with a raised vent 3/8” min. (1.0 cm) flat countertop overhang Countertop required behind cutout...
