Note:
This page will be refreshed automatically every 5 seconds.
4.7

DHCP

Figure 4-25 The DHCP menu
There are three submenus under the DHCP menu (shown in Figure 4-25 ): DHCP Settings, DHCP
Clients List and Address Reservation. Click any of them, and you will be able to configure the
corresponding function.
4.7.1

DHCP Settings

Choose menu "DHCP→DHCP Settings", and then you can configure the DHCP Server on the
page (shown in Figure 4-26 ).The Router is set up by default as a DHCP (Dynamic Host
Configuration Protocol) server, which provides the TCP/IP configuration for all the PC(s) that are
connected to the Router on the LAN.
DHCP Server - Enable or Disable the DHCP server. If you disable the Server, you must
have another DHCP server within your network or else you must configure the computer
manually.
Start IP Address - Specify an IP address for the DHCP Server to start with when assigning
IP addresses. 192.168.0.100 is the default start address.
End IP Address - Specify an IP address for the DHCP Server to end with when assigning IP
TL-WR720N
Figure 4-26 DHCP Settings
-40-
150Mbps Wireless N Router
