Power LED
A solid amber light indicates the
device is in standby or is ready.
A solid blue light indicates the device
is active.
VGA Connector
Connect to a projector or
monitor using a VGA cable.
Power Receptor
Connect the supplied
power adapter.
Hardware Overview
Antenna
Allows you to connect
wirelessly.
DVI Connector
Connect to a projector
or monitor using a DVI
cable.
Reset Button
Press and hold for 5 seconds
to reset the device back to the
default settings.
Audio Jack
Connect to speakers.
D-Link DPG-100 Quick Install Guide
Ethernet Port
Connect to the Internet
to upgrade firmware.
