HUAWEI HG536a
Home Gateway Quick Start
1 Installation
Host Installation
The following figure shows how to connect the cables to the host.
Using the power adapter of 12 V, 1.5 A to connect to the host.
1. Power adapter
To connect the cables to the host, do as follows:
Step 1 Connect the telephone jack on the wall to the ADSL interface on the HG536a
with a telephone line. Connect the telephone to the PHONE interface on the
splitter with a telephone line.
Step 2 Connect the ADSL interface on the HG536a to the MODEM interface on the
splitter with a telephone line.
2. Computer
1
3. Telephone jack on the wall

Advertisement

Table of Contents
loading

Summary of Contents for Huawei HG536a

  • Page 1 3. Telephone jack on the wall To connect the cables to the host, do as follows: Step 1 Connect the telephone jack on the wall to the ADSL interface on the HG536a with a telephone line. Connect the telephone to the PHONE interface on the splitter with a telephone line.
  • Page 2: Battery Installation

    Step 3 Connect the LAN1 interface on the HG536a to the Ethernet interface on your computer with a network cable. Step 4 Connect the POWER interface on the HG536a to the power socket with the power adapter. Battery Installation A handset is provided with the HG536a. Install the battery before using your handset,...
  • Page 3 - Electrify the base by connected to the host. - Electrify the base by connected the power adapter. Using the power adapter of 12 V, 0.5 A to connect to the base. 1. Power adapter for base 2. Base...
  • Page 4 LCD scroll. 2 Powering On To power on the HG536a, press the ON/OFF button on the side panel of the HG536a. After you power on the HG536a, the ADSL indicator blinks (for less than three minutes), which indicates that the HG536a is being activated.
  • Page 5: Setting The Internet Access Parameters

    Step 1 Set the network connection of your computer and ensure that your computer obtains an IP address automatically. By default, the DHCP function of the HG536a is enabled. In this case, the HG536a assigns an IP address to your computer automatically and you do not need to configure the IP address of your computer.
  • Page 6: Configuring The Wireless Network Connection

    Step 1 Log in to the Web-based configuration utility. Step 2 Set the wireless network name and access password of the HG536a. To set the wireless network name and the access password, do as follows (taking the...
  • Page 7: Handset Registration

    5 Handset Registration You can register up to five handsets to your host. The HG536a assigns a name to each handset according to the registration order of the handsets. For example, the name assigned to the first handset that is registered is HS 1, and in standby mode, the name HS 1 is displayed on the LCD of that handset.
  • Page 8 Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved. Trademarks and Permissions , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners.
