Summary of Contents for THUNDER TIGER RAPTOR V.2
- Page 8 For sport kit (29BB) version, (3) will be replaced by Bushing(BK0107x4)
- Page 9 Warning, do not over-torque the self-tapping screws.
-
Page 32: Troubleshooting
After Flight Checklist (1) Check every screw and bolt to make sure none has loosened due to vibration. (2) Check every rotating and movable part to ensure they still move smoothly and normally. (3) Clean off the exhaust residue from the muffler, engine, and helicopter. (4) Check all movable parts, such as gears, ball links, belt, etc. -
Page 50: Specification
SPECIFICATION: Full length of fuselage:1150mm(45.27") Full width of fuselage:140mm(5.51") Total height:400mm(15.75") Main rotor dia:1245mm(49") Tail rotor dia:260mm(10.25") Gear ratio:1:9.56:4.57 Full Equipped weight:3000g (6.6 lbs) JK0094.V3 THUNDER TIGER CORP. www.thundertiger.com Printed in Taiwan C 2004...
