OCZ OCZ700SXS - MECHANICAL DRAWING Manual

8 6 .0

ALL CASE MEASUREMENTS ARE IN mm

5.9" X 3.4" X 5.5" (W X H X D)

ALL WIRE LENGTHS ARE IN INCHES

1 4 0 .0
4 X 6-32
6 4 .0
1 6 .0
6 .0
MECHANICAL DRAWING: OCZ700SXS
1 3 8 .0
11 4 .0
1 5 0 .0
8 0 .0
6 .0
20" 29" 38" from case
YELLOW (+12V3)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
20" 29" 38" from case
YELLOW (+12V3)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
21" from case
20/24 Motherboard
(+3.3V) Orange
(+3.3V) Orange
(GND) Black
(+5V) Red
(GND) Black
(+5V) Red
(GND) Black
(PG) Gray
(+5VSB) Violet
(+12V3) Yellow
(+12V3) Yellow
(+3.3V) Orange
4/8 Cpu Power
21" from case
(GND) Black
(GND) Black
(GND) Black
(GND) Black

PCI Express Video

21" from case
(+12V4) Yellow
(+12V4) Yellow
(+12V4) Yellow
6/8 Pci Express Video
21" from case
(+12V2) Yellow
(+12V2) Yellow
(+12V2) Yellow
(GND) Black
19" from case
Yellow (+12V3)
Black (GND)
Black (GND)
Red (+5V)
26" from case
Yellow (+12V3)
Black (GND)
Black (GND)
Red (+5V)
33" from case
Yellow (+12V3)
Black (GND)
Black (GND)
Red (+5V)
41" from case
Yellow (+12V ) 3
Black (GND)
Black (GND)
Red (+5V)
19" from case
Yellow (+12V ) 3
Black (GND)
Black (GND)
Red (+5V)
26" from case
Yellow (+12V ) 3
Black (GND)
Black (GND)
Red (+5V)
33" from case
Yellow (+12V ) 3
Black (GND)
Black (GND)
Red (+5V)
41" from case
Yellow (+12V ) 3
Black (GND)
Black (GND)
Red (+5V)
Serial ATA
Orange (+3.3V)
1 13
Blue (-12V)
2 14
Black (GND)
3 15
Green (PS-ON)
4 16
Black (GND)
5 17
Black (GND)
6 18
19 Black (GND)
7
8 20 Not Used
9 21 Red (+5V)
10 22 Red (+5V)
11 23 Red (+5V)
12 24
Black (GND)
Yellow (+12V1)
1 5
Yellow (+12V1)
2 6
Yellow (+12V2)
3 7
Yellow (+12V2)
4 8
Black (GND)
1 4
Black (GND)
2 5
Black (GND)
3 6
Black (GND)
1 5
Black (GND)
2
6
Black (GND)
3 7
4 Black (GND)
8
IDE Drive
