The Hayward
Perflex™ Filtration System is specifically designed for the demanding requirements of today's above-ground
swimming pools. The advanced design reduces maintenance requirements while providing superior performance.
To prevent potential injury and to avoid unnecessary service calls, read this manual carefully and completely.
CAUTION –
We highly recommend a qualified professional install and service this product.
WARNING –
This manual contains important safety information that must be furnished to the end
user of this product. FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY.
SAVE THIS INSTRUCTION MANUAL
HAYWARD POOL PRODUCTS, INC.
Corporate Headquarters:
620 Division Street
Elizabeth, NJ 07207
Canada:
2880 Plymouth Drive
Oakville, Ontario L6H 5R4
OWNER'S MANUAL
INSTALLATION, OPERATION, & PARTS
Perflex Extended Cycle Filtration System
EC40C90 Series
U.S.A:
1 Hayward Industrial Drive
2935 Sidco Drive
Clemmons, NC 27012
Nashville, TN 37204
Europe:
Parc Industriel de la plaine de l'Ain
Allêe des Chênes
01150 Saint Vulbas
France
ISEC40C90
Rev. A
2875 Pomona Blvd.
Pomona, CA 91768
