MOUNTING and OPERATING MANUAL
Reversible Air-to-Water Heat Pump
for Outdoor Installation
LA 16ASR
Order No.: 452158.66.21
FD 8507

Advertisement

Table of Contents
loading

Summary of Contents for Dimplex LA16ASR

  • Page 1 MOUNTING and OPERATING MANUAL Reversible Air-to-Water Heat Pump for Outdoor Installation LA 16ASR Order No.: 452158.66.21 FD 8507...
  • Page 2: Table Of Contents

    CONTENTS READ IMMEDIATELY Important Information Legal Provisions and Guidelines Energy-Efficient Use of Heat Pumps PURPOSE OF HEAT PUMP Application Principle of Operation SCOPE OF DELIVERY Baseline Unit Control Box Heat Pump Controller TRANSPORT INSTALLATION General Condensate Line MOUNTING General Heating and Hot Water Connection...
  • Page 3: Read Immediately

    This heat pump was designed and built in compliance with all relevant EU directives, DIN and VDE regulations (see CE Declaration of Conformity). The electrical connection of the heat pump must be performed according to and conforming with all relevant VDE, EN and IEC standards. Beyond that, all technical connection requirements of the local electrical utility company have to be observed.
  • Page 4: Purpose Of Heat Pump

    (available as accessory) be installed. In the cooling mode, the heat pump is suited for air temperatures ranging from +15 °C ... +40 °C. It can be used for passive and dynamic cooling applications alike.
  • Page 5: Control Box

    3.2 Control Box The control box is integrated in the heat pump. It can be folded downward after removing the lower front panel and loosening the fastening screws located at the top on the right. The control box houses the mains terminals as well as the power contactors and the soft start unit.
  • Page 6: Installation

    Frost Protection As a precaution against frost, manual drain valves should be provided. If the heat pump is placed out of service or in the event of a power failure, the system has to be drained at three points (see figure) and blown out.
  • Page 7: Electrical Connection

    - Proper condensate drainage must be ensured. 7.3 Procedure During Heating Season The start-up of the heat pump is effected via the heat pump controller. The settings must be made in accordance with its instruction manual. Malfunctions during operation are displayed on the...
  • Page 8: Cleaning / Maintenance

    To prevent malfunctions in the heat exchanger of the heat pump caused by dirt deposits, care must be taken that the heat exchanger cannot become contaminated in the heating installation. In the event...
  • Page 9: Cleaning Of Air Side

    8.3 Cleaning of Air Side Evaporator, fan and condensate drain should be cleaned of debris (leaves, branches, etc.) from time to time. To this end, the front panel of the heat pump should be opened first at the bottom and then at the top.
  • Page 10 APPENDIX APPENDIX 11.1 DIMENSION DRAWING 11.2 EQUIPMENT DATA 11.3 SCHEMATICS 11.3.1 Heating Mode 11.3.2 Cooling Mode 11.4 WIRING DIAGRAMS 11.4.1 Control 11.4.2 Load 11.4.3 Terminal Diagram 11.4.4 Legend 11.5 HYDRAULIC BLOCK DIAGRAM 11.6 EC DECLARATION OF CONFORMITY 11.7 WARRANTY CERTIFICATE AFTER-SALES SERVICE...
  • Page 11 APPENDIX: 11.1 DIMENSION DRAWING Dimension Drawing...
  • Page 12 APPENDIX: 11.2 EQUIPMENT DATA Equipment Data...
  • Page 13 APPENDIX: 11.3 SCHEMATICS 11.3.1 Heating Mode...
  • Page 14 APPENDIX: 11.3 SCHEMATICS 11.3.2 Cooling Mode...
  • Page 15 APPENDIX: 11.4 WIRING DIAGRAMS 11.4.1 Control...
  • Page 16 APPENDIX: 11.4 WIRING DIAGRAMS 11.4.2 Load...
  • Page 17 N e t z 3 / P E 4 0 0 V A C - 5 0 H z Heat pump controller W ä r m e p u m p e n r e g l e r APPENDIX: 11.4 WIRING DIAGRAMS...
  • Page 18 Frost protection sensor for heating water Heating water return flow sensor Coding resistor (5k6) Terminal strip: load terminal Terminal strip: internal wiring Terminal strip: heaters Plug connector, heat pump controller Plug connector, control lead Plug connector, control lead Plug connector, heat pump 4-way reversing valve...
  • Page 19 APPENDIX: 11.5 HYDRAULIC BLOCK DIAGRAM Hydraulic Block Diagram...
  • Page 20: Ec Declaration Of Conformity

    EC Declaration of Conformity Declaration of Conformity The undersigned KKW Kulmbacher Klimageräte-Werk GmbH, Geschäftsbereich Dimplex Am Goldenen Feld 18 D-95326 Kulmbach hereby confirm that the design and construction of the product(s) listed below, in the version(s) placed on the market by us, conform to the relevant requirements of the applicable EC directives.
  • Page 21 Notes...
  • Page 22 Notes...
  • Page 23 Notes...
  • Page 24 KKW Kulmbacher Klimageräte-Werk GmbH Technical data subject to change without notice Geschäftsbereich Dimplex Fax +49 (0) 92 21 709-589 Am Goldenen Feld 18 www.dimplex.de D-95326 Kulmbach...
