- Page 1 OWNER'S MANUAL V-CA504CEU V-CA504CT reddot design award winner 2003...
- Page 2 Table of contents Information for Your Safety to Use Assembling cleaner Using the and Accessory Nozzles. How to use elbow tube, Air turbine brush. Changing Dust Bag Operation.. How to Plug in and use . Adjusting the Suction level. Park-System Cleaning the Exhaust Filter...
- Page 3 Do not vacuum water or other liquids. Do not unplug by pulling on cord. Use only LG's recommended filters. When you vacuum with an attachment appliance that has a rotating brush roller: • Do not reach into the running brush roller.
- Page 4 HOW to Use Assembling Cleaner Fit the large cleaning head onto the end of the tube. Spring latch Elbow (V-CA504CEU) Telescopic tube (V-CA504CEU) Push telescopic tube into • Press the spring latch to release. • Pull out the tube to the desired length.
- Page 5 Head Flexible Hose Button Attachment Point • Push of the head on the flexible hose into the attachment point on the vacuum cleaner. • To remove the flexible hose from the vacuumcleaner, press on the button situated on the head, then pull the head out of the vacuum cleaner.
- Page 6 HOW to Use Using the Accessory Nozzles Crevice tool Dusting brush Upholstery nozzle Upholstery Nozzle is for Dusting Brush is for vacuuming Crevice Tool is for vacuuming upholstery, picture frames, furniture frames, vacuuming in those mattresses, etc.The thread books and other irregular surfaces. normally hard-to-reach collectors help to pick up...
- Page 7 (V-CA504CEU) • The 2 position cleaning head • Efficient cleaning of hard floors equipped with a pedal which allows (Wood, Linoleum etc.) you to alter its position according the type of floor to be cleaned. • Hard floor position (tiles, parquets floor) Press the pedal to lower brush.
- Page 8 How to use elbow tube, Air turbine brush V-CA504CEU) Pile Adjustment Spring latch I Long Pile (V-CA504CEU) Short Pile Spring latch Elbow tube is for cleaning under the sofa, • Slide the Pile Adjustment to the right for table and bed easily.
- Page 9 HOW to Changing dust b ag otor Filter The dust bag needs changing when the cleaner is set to maximum power and the cleaner head is off the floor but the 'bag full" indicator window is completely coloured red. Even if the dust bag does not appear to be full at this stage, it should be changed. It could be that a great deal of very fine dust has clogged up the pores of the dust bag.
- Page 10 Operation Cord reel button Suction control switch Plug • Puli out the power cord t) the • Adjust the power by • To store after vacuuming • When you have switched off cLsired length and plug inb using the power control and pause while and unplugged the socket.
- Page 11 Cleaning the Exhaust Filter Filter cover • The exhaust filter is a washable reusable HEPA filter. • To change the exhaust filter, removethe filter cover on the body by release hook. • Pull out the exhaust filter. • Clean it with cold, running water. Do Not use the brush...
- Page 12 What to Do if Your Vacuum Cleaner Does Not Work: Check that the vacuum is plugged in correctly and that the electrical socket is working. What to Do When Suction Performance Decreases: • Turn off the vacuum cleaner and unplug it. •...
- Page 13 Note...
- Page 14 Note...
- Page 15 LG Electronics Inc. P/N0.: 3828F128...
