Page 1: Installation Guide
PCXBV-Ux Multi-Scanning Color Monitor Installation Guide Order Number: ER XBVUX IM. A01 Digital Equipment Corporation Maynard, Massachusetts... - Page 2 February 1996 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Restricted Rights: Use, duplication, or disclosure by the U.S. Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.
-
Page 3: Table Of Contents
Introduction Overview ... 1 DDC (Display Data Channel) ... 2 Installation Installation/Operation Guidelines... 2 Monitor Installation ... 3 Servicing Cleaning the Monitor ... 7 Maintenance and Troubleshooting ... 7 Tilt/Swivel Stand Removal... 9 Specifications Scanning Modes... 10 Monitor Specifications ... 11 Power Management System ... - Page 4 Table 6 Power Saving States ... 12 Figures Figure 1 PCXBV-Ux Color Monitor ... 1 Figure 2 PCXBV-Ux Monitor (Rear View) ... 3 Figure 3 Monitor Control Panel... 4 Figure 4 Monitor Controls ... 5 Figure 5 Tilt/Swivel Stand Removal ... 9 Audience This guide is intended for user’s who wish to install the monitor.
-
Page 5: Introduction
Introduction Overview The PCXBV-Ux Monitor is a 17-inch, 15.7 viewable, multi-scanning color monitor with high resolution, compatible with VGA, SVGA, 1024 x 768, and 1280 x 1024 modes. The PCXBV-Ux offers the following features: 1280 x 1024 non-interlaced mode. Power Management system that exceeds EPA ENERGY STAR™... -
Page 6: Ddc (Display Data Channel)
DDC (Display Data Channel) DDC is a communication channel over which the monitor automatically informs the host system about its capabilities. DDC uses a formerly unconnected signal pin in the 15-pin VGA connector. The system will perform the “Plug ‘n Play” feature if both the monitor and the host implement DDC protocol. -
Page 7: Monitor Installation
High Resolution Graphic Video Adapter on the back of the computer. 3. Plug the ac power cord to the monitor, then to a properly-grounded ac electrical outlet. Figure 2. PCXBV-Ux Monitor (Rear View) D E C 0 0 80 1... -
Page 8: Figure 3 Monitor Control Panel
Turn On Power to Monitor Push the power switch button (3) to turn on the monitor. The power indicator LED (2) should light green. For screen alignment, use the monitor controls (1). D E C 0 0 80 2 Figure 3. Monitor Control Panel... -
Page 9: Table 1 User Controls And Functions
Monitor Adjustments Figure 4 shows the monitor adjustment controls. Some of the controls (1) have two functions. Press the button once or Function 1; press the button again for Function 2. Tables 1 and 2 define these functions. The monitor saves your settings four seconds after your last adjustment. -
Page 10: Table 2 User Controls Used With Arrow Buttons
Table 2. User Controls Used With Arrow Buttons Icon Name With Function 1 Position (H/V) Position (H/V) Size (H/V) Size (H/V) Geometric distortion Geometric distortion COLOR Color TEMP. temperature Function 2 Adjusts horizontal Selects user or position. preset modes. Adjusts vertical Pages through list position. -
Page 11: Servicing
Servicing Cleaning the Monitor To clean the monitor: 1. Unplug the monitor. 2. Clean the monitor with a soft, slightly damp cloth. Do not use an aerosol cleaner directly on the screen. _____________________ CAUTION __________________________ Do not use benzene, thinner, or any volatile substance to clean the monitor, as these products may discolor the monitor’s cabinet. -
Page 12: Table 3 Identifying And Correcting Problems
Troubleshooting Table Use Table 3 to identify and correct any problem area. Table 3. Identifying and Correcting Problems Symptom Possible Cause Display does not Brightness or appear. contrast control is set too low. Power Management feature is active in the off state. There is no power. -
Page 13: Figure 5 Tilt/Swivel Stand Removal
Tilt/Swivel Stand Removal To remove the stand, remove the screw that secures the bottom of the stand and slide it back. D E C 0 0 7 9 9 Figure 5. Tilt/Swivel Stand Removal... -
Page 14: Table 4 Display Modes And Addressability
Specifications Scanning Modes Table 4 Display Modes and Addressability Mode Display Address- Mode ability VGA 60 640 x 480 DOS 70 720 x 400 VGA/350 70 640 x 350 640 x 480 VESA 75 ErgoVGA 640 x 480 SVGA/60 800 x 600 SVGA 800 x 600 VESA 75... -
Page 15: Monitor Specifications
Monitor Specifications Table 5 Monitor Specifications 43 cm (17-inch, 15.7 maximum viewable) Monitor non-glare, non-static, multilayer optical coating Active Area 32.0 x 24.0 cm (12.6 x 9.4 in) Height 42.6 cm (16.8 in), includes tilt/swivel base Width 43.4 cm (17.1 in) Depth 44.4 cm (17.5 in) Swivel... -
Page 16: Power Management System
This monitor has been designed and manufactured to minimize the impact to the environment. Acoustic Levels Preliminary declared values per ISO 9296 and ISO 7779: Sound Power Level Idle PCXBV-Ux 1 B = 10 dBA Operator position Power Consumption Recovery (Watts)* 110 (max) <... - Page 17 Asbestos This monitor does not use asbestos in any form. Flame Retardants The enclosures do not contain polybrominated diphenylether (PBDE) as a flame retardant additive; therefore, they do not emit toxic dibenzofuran and dibenzodioxin gases. Ozone Depleting Substances (ODS) These monitors are in full compliance with the labeling requirements in the U.S.
