Quick Reference Guide

Front Panel Controls

Pitch Bend Wheel - temporarily changes the instrument's tuning
Modulation Wheel - adds effects like vibrato and tremolo; its effect can be
different from one Program to the next
Master Volume - determines the output level of the analog outputs
Controller A-C Sliders - modulates a sound in Program or Mix mode
Controller D / Edit Value Slider - modulates a sound in Program or Mix mode,
changes the currently selected parameter in any of the Edit modes
Value buttons - increase or decrease the currently selected parameter, or let you
scroll backward and forward through Mixes or Programs
Edit Select button - determines which Edit Mode is selected (Mix Edit, Program
Edit, Effects Edit or Global Edit)
Store button - lets you store an edited Program or Mix into internal memory, or
a sound card, or to external MIDI devices
QS Quick Facts
Welcome to the QS-Series Synthesizer Quick Reference Guide. This is a supplement to the manual designed to quickly get you up
and running with these keyboards. Some of the key features of the QS include:
• 16 MB of Sound ROM standard
• Expandable to 32 MB via our 8 MB PCMCIA format QCards
• Up to 16 MB of user sample storage available through Flash RAM PCMCIA cards
• True 64 Note Polyphony
• 4 High Quality Multieffects Busses
• ADAT Optical Digital Outputs
• 4 Independant Analog Outputs
• 4 Realtime Controller Sliders
• Built-In Serial port for direct Mac
• Extensive Tracking Generator and Matrix Modulation sections
• 88 Note Weighted (QS8.1), 76 Note Semi-Weighted (QS7.1), or 61 Note Semi-Weighted (QS6.1)
Keyboard with Aftertouch and Release Velocity
• Included CD-ROM with Sequencing and Sound Editing Applications and Files
For more information please refer to the QS Reference Manual that comes with your keyboard.
TM
™
or PC connection
TM
Page buttons - move the display between the various pages of a selected Function
Mix button - selects Mix Mode
Program button - selects Program Mode
Bank buttons - let you switch between banks in Mix/Program Play Mode
Compare button - compares an edited Mix or Program to its original version
Global button - gives you access to parameters that control the entire instrument
including master tuning/transposition and keyboard sensitivity
00-120 Buttons - in Program and Mix modes these select the sound group (Pianos,
Brass, etc.), in Edit modes these select parameters to be edited
0-9 Buttons - in Mix or Program modes these select individual Programs/Mixes, in
Edit modes these select parameters to be edited
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the qs6.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Alesis qs6.1

Summary of Contents for Alesis qs6.1

  • Page 1: Front Panel Controls

    PC connection • Extensive Tracking Generator and Matrix Modulation sections • 88 Note Weighted (QS8.1), 76 Note Semi-Weighted (QS7.1), or 61 Note Semi-Weighted (QS6.1) Keyboard with Aftertouch and Release Velocity • Included CD-ROM with Sequencing and Sound Editing Applications and Files For more information please refer to the QS Reference Manual that comes with your keyboard.
  • Page 2 How To Play The Demos The QS is equipped with five demo sequences to show a few of its Programs and Effects in various musical styles. To listen to the demo sequences: 1. Press and hold the MIX button. 2. Press the 0,1,2,3 or 4 button. 3.

  • Page 3: Editing A Mix

    Using The Modulation Sources Each Program has the Modulation Wheel assigned to the most logical parameter. For example, the Modulation Wheel may be assigned to Vibrato on a Brass sound and Reverb Mix on a Piano sound. The A-D Controller Sliders also transmit controller data which can affect local synthesizer functions, MIDI data, or both. This allows you to alter the currently recalled Program (or Mix), or control external MIDI devices using the QS as a master controller.

  • Page 4: Editing Effects

    6. Press any of the other Keypad buttons to view and edit other parameters in the Program. There is a wide variety of parameters to edit in the pages of Edit Functions. See your QS Reference Manual for more information about editing Programs. ©1999 Alesis Corporation Specifications Subject To Change Without Notice 7-52-0022-A 6/00...
