User Manual TT-IR
DE: IR-FERNSTEUERUNG (WOCHENTIMER)
EN: INFRARED PROGRAMMABLE THERMOSTAT
FR: THERMOSTAT PROGRAMMABLE INFRA-ROUGE
IT:
TERMOSTATO PROGRAMMABILE AD INFRAROSSI (IR)
PL: PROGRAMATOR ZDALNY (TYGODNIOWY)
RU: ДИСТАНЦИОННЫЙ ПРОГРАММАТОР (НЕДЕЛЬНЫЙ)
NL: GEBRUIKSHANDLEIDING TT-IR
DE
EN
FR
IT
PL
RU
NL
Advertisement
Related Manuals for TERMA TT-IR
Summary of Contents for TERMA TT-IR
- Page 1 User Manual TT-IR DE: IR-FERNSTEUERUNG (WOCHENTIMER) EN: INFRARED PROGRAMMABLE THERMOSTAT FR: THERMOSTAT PROGRAMMABLE INFRA-ROUGE TERMOSTATO PROGRAMMABILE AD INFRAROSSI (IR) PL: PROGRAMATOR ZDALNY (TYGODNIOWY) RU: ДИСТАНЦИОННЫЙ ПРОГРАММАТОР (НЕДЕЛЬНЫЙ) NL: GEBRUIKSHANDLEIDING TT-IR...
- Page 2 Contents Description ............27 Location ............28 Mountings ............29 Starting up ............30 Return to the initial settings ......34 Time Setting ............. 35 Setting the temperatures (set-points) ..... 35 Programming ........... 36 Automatic mode ..........39 Absence mode ..........40 Manual mode ........... 41 Shutdown mode..........42 Changing the batteries ........43 Characteristics ..........44 Communication with the TTIR programmer ...
- Page 3 Warning • Carefully read these instructions prior to installation. • Do not attempt to repair the unit yourself; an after-sales service is available. We hereby declare that the equipment complies with the essential requirements and other relevant provisions of the Directive EMC 2014/30/UE Electromagnetic compatibility • Class B device as described in EN 55032 European Directive 2012/19/EC (WEEE) Disposal of old electrical & electronic equipment (applicable in the European Union and in other European countries with separate collection systems) This symbol on the product or its packaging indicates that this product shall not be treated as household waste. Instead, it shall be handed over to the applicable collection point for the...
- Page 4 Description Battery level indicator Time Current mode (e.g. comfort) Temperature (set or measured) Current day Heating demand mode Adjustment buttons Program profile Automatic mode Economy Comfort Frost Protection Time setting Shutdown Programming Cover opening marks...
- Page 5 Location To control the heating, the thermostat must measure the most repre- sentative room temperature in your home. As the temperature measure- ment probe is in the transmitter unit, you must place the unit: • wall-mounted or placed on a shelf or accessible furniture at a height of 1.50 m, • away from heat sources (fireplaces, sunlight) and draughts (windows, doors), Before mounting in the final position, ensure no object can block the transmission between the transmitter and the radiator’s receiver. IMPORTANT: Do not install the wall-mounted thermostat on a wall in contact with approx. height the outside or in an 1.50 m unheated room placed on furniture (e.g. garage, etc.). min.
- Page 6 Mountings • Lift off the cover by using a screwdriver and remove the batteries • Wall mounting Secure the ther- mostat using the screws and pegs or fit onto a flush-mounted box (❶, distance between centres 60 mm). • Insert the batteries, ensuring that they are correctly fitted. • Place the cover back on the thermostat.
- Page 7 Starting up After installation you need to program initial settings. Turn the dial to the off position and press the right-hand button for 5 seconds until H600 code appears (maintenance menu reserved for the installer). Press OK. 5 sec. The screen displays CF01. CF01 — Correction of room temperature measurement. If there is a difference between the room temperature and the temperature indicated by the programmer, it is possible to correct it (from -4° C to +4° C in steps of 0.1° C). Press + or –...
- Page 8 CF02 — AUTO mode temperature display option Continuous room temperature display Temperature displayed Continuous display of the set-point Press + or – to make your choice, OK to con- firm it and go to the next menu. CF03 — Selection of the “EARLY START” function Early start means for the device to start heat- ing in advance so that at the time set in the schedule you get the desired temperature, and not just start work (concerns the change from Eco to Comfort).
- Page 9 Press + or - to select the set 1 or 0, press OK to confirm and go to the next menu. Early Start non active Early Start active „EARLY START” function CF04 - Deviation level adjustment (if the EARLY START function is active) Adjustment from 1 ° C to 6 ° C, every 0.1 ° C. If the temperature is reached too early, decrease the value. If the temperature is reached too late, increase the value. The default value is 3,0 °...
- Page 10 CF05 – Infrared test The transmitter sends a control signal to the receiver every 3 seconds. Check whether the receiver’s light flashes on every reception. To leave the configuration mode, turn the knob.
- Page 11 Return to the initial settings You can carry out a general reset to return to the factory settings: • the installer settings (grayed out on the start up menus), • the time and day, • set-point temperatures, • default program. Turn the dial off, then press the left-hand button for 10 seconds until “init” is displayed. Press OK to confirm or C to cancel. Return to the shutdown mode display. 10 sec.
- Page 12 Time Setting Turn the knob to . Hours The days flash. Press + or – to make your choice, OK to confirm it and go to the next setting. Repeat the operations to set the hours and minutes. Turn the dial to exit the setting mode. Minutes Setting the temperatures (set-points) Turn the dial to: — to set the system freezing protection temperature or to maintain the mini- mum room temperature (from 5-15 degrees Celsius), —...
- Page 13 Programming When starting up, the “Comfort mode from 6 a.m. to 11 p.m.” program is applied to all the days of the week. To change the programming, turn the knob to PROG. The 1 time slot flashes on and off. 1. Create your program Programming starts on day 1 at midnight. Press the or buttons to create different Economy or Comfort periods. Economy mode Go to the next for 1 hour program change Confirm and go to Comfort for 1 hour the next day 2. Confirm and copy the program Press and hold the OK button for 3 seconds to confirm the program you...
- Page 14 3. Confirm the program Press the OK button to confirm and continue on to the next day to pro- gram it separately. Example: Comfort from 6:00 to 8:00 and from 17:00 to 23:00 Press and hold until you reach 6:00 Press and hold until you reach 23:00 Press and hold until you reach 8:00 Press and hold until you reach 00:00 Copy and confirm or simply confirm Press and hold until you reach 17:00...
- Page 15 4. Check your program Press the button repeatedly to check the accuracy of the Comfort and Economy periods you created. Time slot consulted Program profile Verification of the different periods Press OK to check the next day. To exit the mode, turn the dial to another mode.
- Page 16 Automatic mode Turn the dial to AUTO. Current setting (e.g. comfort) Time Heating demand Measured mode temperature Absence mode Comfort or economy Forced operation manual mode (from 30 minutes to 4 hours) (up to program change) When starting up, the temperature measured by the thermostat is displayed (the symbol appears above the ° C). Press the button to display the set-point temperature.
- Page 17 Absence mode This mode is used to set a temperature (5 to 15° C) for a period that can be set from 1 to 365 days. From the automatic mode (AUTO), press the button. The number of days flash on and off. Press + or – to set the number of days. Example: leaving on 10 January, returning on 19 January, indicate 9 days. Automatic opera- tion will restart on 19 January at 00.00 h. Press OK to confirm. The temperature flashes on and off. Press + or – to set the tempera- ture.
- Page 18 Manual mode Manual mode ) Up to the next program change is the current mode This mode is used to go from comfort to economy mode (or conversely) until the next program change. Example: when in economy mode, pressing the button allows you to go to comfort mode. To cancel the manual mode, press the button again or turn the dial. ( ) Forced operation can be set from 30 minutes to 4 hours This mode makes it possible to program a forced operation for the heating from 30 minutes to 4 hours.
- Page 19 Manual mode is the current The manual mode period flashes mode on and off. Press + or – to set the period required (e.g. 1.5 hours). Press OK to confirm. To cancel the manual mode, press the C button or turn the dial. Shutdown mode To shut down the heating (in summer, for example). Turn the dial to . The thermostat displays the room temperature measured. Measured temperature...
- Page 20 Changing the batteries Battery level symbol From the moment the battery level symbol appears, you have around 3 months to change them (2 LR03 or AAA-type 1.5 V alkaline batteries). The following precautions must be re- spected: • ensure that the +/– polarities are correct when the batteries are fitted into the unit, • do not dispose of used batteries in unau- thorized places (you should respect the environment by taking the batteries to a suitable collection site), •...
- Page 21 Characteristics • Power supplied by two LR03 or AAA-type 1.5 V alkaline batteries (sup- plied), autonomy greater than 2 years for normal use • Appliance class: Class III • Built-in proportional control, time basis 10 min. • Dimensions: 135 x 81 x 0.87 in • Casing protection index: IP 30 • Range (outside): 10 m • Transmission angle: 50° • Wall mounting or on flush-mounted box • Installation in an environment with normal pollution levels • Storage temperature: -10° C to +70° C • Operating temperature: 0° C to +40° C...
- Page 22 TTIR control panel and KTX 4 (or SKT 4) you may need to assign a new IR transmission channel in your KTX 4 (SKT 4). The channel KTX 4 (SKT 4) should be set up for is A5. CHANGING KTX 4 (SKT 4) IR COMMUNICATION CHANNEL To ensure proper infrared communication Terma KTX 4 must operate on the same IR channel as TTIR controller. To change the IR channel in KTX 4 (SKT 4) do as follows: 1. M ake sure KTX 4 controller is connected to mains and KTX 4 is on. If the device is switched off please switch it on by pressing ON/OFF button.
