Sealey AK459DX.V3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions
protection
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this equipment.
‰
Familiarise yourself with the application and limitations of the oil drainer, as well as the potential hazards.
9
WARNING! Disconnect the drainer from the air supply before changing accessories, servicing or performing any maintenance.
‰
Maintain the drainer in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Observe work area conditions. Keep area well lighted.
9
When not in use disconnect from the air supply, vent reservoir and store in a safe, dry, childproof area.
9
Use the right product for the job. There are certain applications for which the oil lift was designed. DO NOT modify the oil lift and DO NOT
9
use the oil lift for a purpose for which it was not intended.
DO NOT operate the drainer if any parts are damaged before using any product, any part that appears damaged should be carefully
8
checked to determine that it will operate properly and perform its intended function. Check for any broken or damaged parts and any other
conditions that may affect its operation. Replace or repair damaged or worn parts immediately.
Replacement parts and accessories. When servicing, use only identical replacement parts. Use of any other parts will void the warranty.
9
DO NOT operate the drainer when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
WARNING! Use eye and hearing protection. Always wear ANSI approved impact safety goggles, full face shield and ANSI approved
‰
hearing protection when working with this product.
DO NOT exceed the product's working pressure of 0.5bar.
8
Only use on a flat surface capable of supporting the Portable Oil Lift and its maximum load of 26 gallons.
8
Dress safely. Non-skid footwear or safety boots should be used when working with the product. DO NOT wear loose clothing or jewelry as
9
they can become caught in moving parts wear a protective hair covering to prevent long hair from becoming caught in moving parts.
Dress safely. Non-skid footwear or safety boots should be used when working with the product. DO NOT wear loose clothing or jewelry as
9
they can become caught in moving parts wear a protective hair covering to prevent long hair from becoming caught in moving parts.
DO NOT allow children in the work area.
8
Always check hardware and assembled parts after assembling. All connections should tight and hardware tightened.
9
DO NOT overreach. Keep proper footing and balance at all times to prevent tripping, falling and injury.
8
Always secure the wheels and casters in place while operating the oil lift.
9
Dispose of waste oil in accordance with local authority regulations.
9
Keep the drainer clean for best and safest performance.
9
Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use, and ensure that all connections are secure.
9
DO NOT stand on the drainer.
8
DO NOT adjust or tamper with the safety valve.
8
DO NOT move the drainer by the hose, or pull the hose sharply from the air supply.
8
DO NOT place attachments close to your face and DO NOT point hose at other persons or animals.
8
DO NOT allow untrained persons to operate the drainer.
8
DO NOT leave the drainer operating unattended.
8
DO NOT direct air from the air hose at yourself or others.
8
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of waste oil.
‰
1.1. OIL DRAINER SAFETY
Failure to heed the following warnings may result in personal injury and/or property damage.
WARNING! Never leave unit unattended when operating or evacuating.
‰
WARNING! Never use near open flame or heat source.
‰
WARNING! Always check that valve below funnel is closed before emptying.
‰
WARNING! Always disconnect air supply after emptying.
‰
WARNING! Never use unit for handling highly volatile fuels and fluids.
‰
WARNING! Use only the nozzle assembly provided.
‰
WARNING! Never fill the tank over the maximum level indicated by the level indicator.
‰
2. INTRODUCTION
Steel fabricated 90L reservoir. Height-adjustable steel drain pan, fitted with grid filter. Gravity feed reservoir with air discharge hose.
Includes quick release oil dipstick probes, plus adaptors for BMW and VW, powered by venturi suction pump. Fitted with reservoir oil
level indicator tube. Heavy-duty wheels and castors for easy mobility.
© Jack Sealey Limited
90LTR AIR DISCHARGE MOBILE OIL DRAINER
WITH PROBES
MODEL NO:
Wear protective Wear protective
gloves clothing
Original Language Version
AK459DX.V3
Wear safety Wear ear
footware protection
AK459DX.V3 Issue 1 19/03/25
