EvoluX
iQ
™
Robotic Pool Cleaner
TYPE EC15 --
Models: EX5050 iQ
EX6050 iQ
This Quick Start Guide contains essential installation and startup instructions. For additional operation, maintenance, and
troubleshooting instructions, please refer to the complete Owner's Manual. Read the complete manual and all safety warnings
before commencing installation. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the
appliance. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualifi ed persons in
order to avoid a hazard.
Before You Start
Quick Start Guide
Advertisement
Related Manuals for Zodiac Evolux iQ Series
Summary of Contents for Zodiac Evolux iQ Series
- Page 1 Quick Start Guide EvoluX ™ Robotic Pool Cleaner TYPE EC15 -- Models: EX5050 iQ EX6050 iQ Before You Start This Quick Start Guide contains essential installation and startup instructions. For additional operation, maintenance, and troubleshooting instructions, please refer to the complete Owner’s Manual. Read the complete manual and all safety warnings before commencing installation.
- Page 2 ENGLISH Zodiac EvoluX iQ | Quick Start Guide ® ™ Zodiac EvoluX iQ Robotic Pool Cleaner ™ handle frame handnut wheels (x 2) wheel axle / hubcap (x 2) base unit caddy handle Page 2...
- Page 3 • To reduce the risk of electrical shock, do not use the robotic cleaner or control unit if the cord is worn or damaged. Contact Zodiac Customer Care Service 1300 763 021 immediately for proper servicing and replacement of the damaged cord.
- Page 4 ENGLISH Zodiac EvoluX iQ | Quick Start Guide ® ™ 2. Connect the Floating Cable Wait for bubbles to stop completely, then let the cleaner sink to the bottom of the pool. 3.5 m Residual Current Device 240V Figure 3. Ideal entry point in pool.
- Page 5 ENGLISH Zodiac EvoluX iQ | Quick Start Guide ® ™ 5. Configure the System 7. Start Cleaning From the App or the Control Box, press the Start/Stop After logging into the iAquaLink app, press ™ button to begin cleaning. the plus icon (+) at the top of My Systems.
- Page 6 ENGLISH Zodiac EvoluX iQ | Quick Start Guide ® ™ 8. Control Unit Button Functions Control unit is receiving power Start/Stop cleaning Select cleaning mode: Waterline only (45 min) Quick Clean (1h 15 min) Floor only EX5050 iQ SMART Cycle...
- Page 7 ENGLISH Zodiac EvoluX iQ | Quick Start Guide ® ™ 9. Proper Removal from Pool 1. Use Lift System from the Main app screen or the Control Unit to drive the cleaner to the nearest wall. Figure 6. Untangle the Floating Cable 4.
- Page 8 Model No. : Serial No. : A Fluidra Brand | Zodiac.com.au | Zodiac.co.nz Fluidra Group Australia Pty Ltd | 1 Herbert Place, Smithfield NSW 2164, PO Box 7238 Wetherill Park NSW 1851, Australia ABN: 87 002 641 965 | 1300 186 875...
