Seagate Savvio 10K.3 SAS Product Manual

Seagate Savvio 10K.3 SAS Product Manual

Standard/self-encrypting drive/sed fips 140-2
Hide thumbs Also See for Savvio 10K.3 SAS:

Advertisement

Quick Links

Download this manual
Product Manual
Savvio
10K.3 SAS
®
Standard Models
ST9300603SS
ST9146803SS
100516229
Rev. E
September 2010
Self-Encrypting Drive Models
ST9300503SS
ST9146703SS
SED FIPS 140-2 Models
ST9300403SS
ST9146603SS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Savvio 10K.3 SAS and is the answer not in the manual?

Questions and answers

Related Manuals for Seagate Savvio 10K.3 SAS

Summary of Contents for Seagate Savvio 10K.3 SAS

  • Page 1 Product Manual Savvio 10K.3 SAS ® Standard Models Self-Encrypting Drive Models ST9300603SS ST9300503SS ST9146803SS ST9146703SS SED FIPS 140-2 Models ST9300403SS ST9146603SS 100516229 Rev. E September 2010...
  • Page 2 LLC in the United States and/or other countries. Savvio and SeaTools are either trademarks or regis- tered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 3 Seagate Technology support services ........
  • Page 4 Signal characteristics ........... . . 62 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 5 Additional information ........... . 63 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 6 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 7 SAS transmitters and receivers ..........62 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 9 Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance For information regarding Data Recovery Services, visit http://www.i365.com For Seagate OEM & Distribution partner portal, visit https://direct.seagate.com/portal/system For Seagate reseller portal, visit http://spp.seagate.com Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 10 Savvio drives support the SAS Protocol specifications to the extent described in this manual. The SAS Inter- face Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives. The Self-Encrypting Drive Reference Manual, part number 100515636, describes the interface, general operation, and security features available on Self-Encrypting Drive models.
  • Page 11 Mounting by bottom holes must meet the requirements of Section 11.3. Standards The Savvio family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The drives are recognized in accordance with UL 60950-1 and CSA 60950-1 as tested by UL and EN60950-1 as tested by TUV.
  • Page 12 • Printer • Mouse Although the test system with this Seagate model complies with the directives/standards, we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide the appropriate marking for their product.
  • Page 13 Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our...
  • Page 14 The shipping lock disengages and the head load process begins when power is applied to the drive. The drives also use a high-performance actuator assembly with a low-inertia, balanced, patented, straight arm design that provides excellent performance with minimal power dissipation. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 15 • Authenticated firmware download Media description The media used on the drive has an aluminum substrate coated with a thin film magnetic material, overcoated with a proprietary protective layer for improved durability and environmental protection. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 16 Seagate recommends product planning in one of two modes: Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. We recommend customers use this capacity in their project planning, as it ensures a stable operating point with backward and forward compatibility from generation to generation.
  • Page 17 Users planning single unit distribution should specify this option. • The Safety and Regulatory Agency Specifications, part number 75789512, is usually included with each standard OEM drive shipped, but extra copies may be ordered. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 18 Typical access times are measured under nominal conditions of temperature, voltage, and horizontal orientation as measured on a representative sample of drives. Access time = controller overhead + average seek time and applies to all data transfer commands. Access to data = access time + latency time. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 19 The START STOP UNIT command may be used to command the drive to stop the spindle. Stop time is 20 sec- onds (maximum) from removal of DC power. SCSI stop time is 20 seconds. There is no power control switch on the drive. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 20 Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 21 When prefetch (read look-ahead) is enabled (enabled by DRA = 0), the drive enables prefetch of contiguous blocks from the disc when it senses that a prefetch hit will likely occur. The drive disables prefetch when it decides that a prefetch hit is not likely to occur. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 22 If an unrecoverable data error is detected, a MEDIUM ERROR (03h) in the Sense Key will be reported. Multiple unrecoverable data errors resulting from the same cause are treated as 1 error. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 23 It is the responsibility of the systems integrator to assure that no temperature, energy, voltage haz- ard, or ESD potential hazard is presented during the hot connect/disconnect operation. Discharge the static electricity from the drive carrier prior to inserting it into the system. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 24 The interval defines the number of operations over which to measure the rate. The counter that keeps track of the current number of operations is referred to as the Interval Counter. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 25 65°C. A sense code is sent to the host to indicate the rounding of the parameter field. Table 1: Temperature Log Page (0Dh) Parameter Code Description Primary Temperature 0000h Reference Temperature 0001h Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 26 DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive.
  • Page 27 This will cause a 01 (self-test aborted by the application client) code to appear in the self-test results values log. All other abort mechanisms will be reported as a 02 (self-test routine was interrupted by a reset condition). Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 28 Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure.
  • Page 29 ASIC is enabled and functional in the SED models. This represents a small additional drain on the 5V supply of about 30mA and a commensurate increase of about 150mW in power consumption. There is no additional drain on the 12V supply. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 30 Maximum (peak) DC 3σ 1.16 0.30 1.20 0.30 Peak operating current (sequential write) Typical DC 0.83 0.16 0.84 0.15 Maximum DC 3σ 0.85 0.16 0.87 0.15 Maximum (peak) DC 3σ 1.08 0.28 1.08 0.32 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 31 Operating condition is defined as random 8 block reads. During idle, the drive heads are relocated every 60 seconds to a random location within the band from three-quarters to maximum track. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 32 450 mV pp from 8 KHz to 20 KHz. 250 mV pp from 20 KHz to 5 MHz. 7.2.2 Power sequencing The drive does not require power sequencing. The drive protects against inadvertent writing during power-up and down. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 33 7.2.3 Current profiles The +12V and +5V current profiles for the Savvio 10k.3 drives are shown below. Figure 17. Current profiles for 300GB models Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 34 Figure 18. Current profiles for 146GB models Note: All times and currents are typical. See Tables 2 and 3 for maximum current requirements. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 35 +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 19. 300GB (at 3 Gbit) DC current and power vs. input/output operations per second Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 36 +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 20. 300GB (at 6 Gbit) DC current and power vs. input/output operations per second Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 37 +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 21. 146GB (at 3 Gbit) DC current and power vs. input/output operations per second Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 38 To confirm that the required cooling for the electronics and HDA is provided, place the drive in its final mechanical configuration, perform random write/read operations. After the temperatures stabilize, measure the case temperature of the drive. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 39 Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 86°F (30°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.
  • Page 40 36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.
  • Page 41 Vibration occurring at these levels may degrade operational performance during the abnormal vibration period. Specified operational performance will continue when normal operating vibration levels are resumed. This assumes system recovery routines are available. Operating abnormal translational random flat profile 10 - 500 Hz 1.2 GRMS Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 42 The sil- ver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.
  • Page 43 See Section 11.3, “Drive mounting.” Height: 0.583 in 14.8 mm Width: 2.76 in 70 mm Depth: 3.957 in 100.5 mm Weight: 0.50 pounds 0.227 kilograms Temperature Measurement Location Figure 25. Mounting configuration dimensions Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 44 (CSPs) within the module, or pick-resistant locks on covers or doors to protect against unauthorized physical access. Figure 26. Example of FIPS tamper evidence labels. Does not represent actual drive. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 45 (TCG) Enterprise Storage Specifications as detailed in Section 3.2. The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the com- puter, storage and digital communications industry. Seagate’s SED models comply with the standards pub- lished by the TCG.
  • Page 46 Each data band has its own drive-generated encryption key and its own user-supplied password. The host may change the Encryption Key (see Section 9.6) or the password when required. The bands should be aligned to 4K LBA boundaries. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 47 Authenticated firmware download In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1.
  • Page 48 10.0 Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive).
  • Page 49 Status returned by the drive to the initiator is described in the SAS Interface Manual. Status reporting plays a role in systems error management and its use in that respect is described in sections where the various com- mands are discussed. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 50 DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location.
  • Page 51 Any sectors that fail the comparison result in the invocation of a rewrite and auto-reallocation process. The process attempts to rewrite the data to the original location. If a verification of this rewrite fails, the sector is re-mapped to a spare location. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 52 The drive may be mounted in any orientation. All drive performance characterizations, however, have been done with the drive in horizontal (discs level) and vertical (drive on its side) orientations, which are the two pre- ferred mounting orientations. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 53 Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Above unit Under unit Note. Air flows in the direction shown or in reverse direction (side to side) Figure 28. Air flow Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 54 Increased radiated emissions may result if you do not provide the maximum surface area ground connection between system ground and drive ground. This is the system designer’s and integrator’s responsibility. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 55 Table 6 lists the SAS response codes returned for task management functions supported. Table 6: Task management response codes Function name Response code Function complete Invalid frame Function not supported Function failed Function succeeded Invalid logical unit Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 56 • Concurrent port transfers—The drive supports receiving COMMAND, TASK management transfers on both ports at the same time. • Full duplex—The drive supports sending XFER_RDY, DATA and RESPONSE transfers while receiving frames on both ports. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 57 TMC bit LP bit Protocol-specific Log Page for SAS (18h) Log Sense Application Client Log page (0Fh) Buffer Over-run/Under-run page (01h) Cache Statistics page (37h) Factory Log page (3Eh) Information Exceptions Log page (2Fh) Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 58 Mode Sense (10) (same pages as Mode Sense 1Ah) Persistent Reserve In Persistent Reserve Out Prefetch Read (6) Read (10) DPO bit supported FUA bit supported Read (12) Read (16) Read (32) 7Fh/0009h Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 59 Security Protocol Out Y (SED models only) Seek (6) Seek (10) Send Diagnostics Supported Diagnostics pages (00h) Translate page (40h) Set Limits Start Unit/Stop Unit (spindle ceases rotating) Synchronize Cache Synchronize Cache (16) Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 60 Warning. Power loss during flash programming can result in firmware corruption. This usually makes the drive inoperable. Reference Mode Sense command 1Ah for mode pages supported. Y = Yes. Command is supported. N = No. Command is not supported. A = Support is available on special request. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 61 When power is applied to the drive, it takes saved values from the media and stores them as current val- ues in volatile memory. It is not possible to change the current values (or the saved values) with a Mode Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 62 SCSI implementation (see the SAS Interface Manual ). DEF = Default value. Standard OEM drives are shipped configured this way. CHG = Changeable bits; indicates if default value is changeable. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 63 9c 0a 10 00 00 00 00 00 00 00 00 01 9c 0a 9d 0f ff ff ff ff ff ff ff ff 80 06 00 80 0f 00 00 00 80 06 b7 c0 8f 00 00 00 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 64 9c 0a 10 00 00 00 00 00 00 00 00 01 9c 0a 9d 0f ff ff ff ff ff ff ff ff 80 06 00 80 0f 00 00 00 80 06 b7 c0 8f 00 00 00 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 65 SMP = 1 in Mode Select command needed to save RPL and rotational offset bytes Table 12: Miscellaneous status Supported Status Good Check condition Condition met/good Busy Intermediate/good Intermediate/condition met/good Reservation conflict Task set full ACA active ACA active, faulted initiator Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 66 Figure 29 shows the location of the SAS device connector J1. Figures 30 and 31 provide the dimensions of the SAS connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. Figure 29. Physical interface...
  • Page 67 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43 0.05 15.875 15.875 1.27 (14X) 1.27 (6X) 0.84 0.05 (22X) 5.08 0.15 B 4.90 0.08 0.35MIN C OF DATUM B Figure 30. SAS device plug dimensions Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 68 SECTION A - A CONTACT SURFACE FLUSH 0.08 0.05 TO DATUM A 0.03 1.90 0.08 1.23 0.05 Detail 2 0.08 0.05 2.40 0.08 0.10 A SECTION B - B Figure 31. SAS device plug dimensions (detail) Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 69 Diff output pair Ground S13* +Port B_out 12 Volts charge Port B Ground P14* 12 Volts P15* 12 Volts * - Short pin to support hot plugging NC - No connection in the drive. Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 70 Spun up and activity (command executing) Spinning up or down Blinks steadily (50% on and 50% off, 0.5 seconds on and off for 0.5 seconds) Format in progress, each cylinder change Toggles on/off Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 71 For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068.
  • Page 72 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 73 MSID password 38 data 7 defects 40 space 12 Deferred Auto-Reallocation 42 busy status 57 deferred error handling 57 bytes per surface 10 DEK 37 bytes per track 10 description 6 DFE 63 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 74 Format command execution time 11 Korean Communications Commission 4 front panel 35 function complete, code 00 47 not supported, code 05 47 latency reject, code 04 47 average rotational 10 Locking SP 37 LockOnReset 38 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 75 RCD bit 12 read error rates 14 read/write data heads 10 noise receivers 62 audible 3 recommended mounting 33 noise immunity 24 Recoverable Errors 14 non-operating 31 recovered media data 14 temperature 31 reference Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 76 31 shock mount 46 SID 37 vibration 31 signal characteristics 62 single-unit shipping pack kit 9 warranty 20 SMART 8 SMP = 1 in Mode Select command 57 SNW-3 training gap 63 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 77 57 zone bit recording (ZBR) 7 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 78 Savvio 10K.3 SAS Product Manual, Rev. E...
  • Page 80 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100516229, Rev. E...
