OWNER'S MANUAL

FRIDGE & FREEZER

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

MFL71782472

Rev.02_061625

Scan the QR code to see the manual.

www.lg.com

Need help?

Do you have a question about the GML861PYPE and is the answer not in the manual?

Questions and answers

Summary of Contents for LG GML861PYPE

Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH www.lg.com MFL71782472 Rev.02_061625 Copyright © 2024-2025 LG Electronics. All Rights Reserved...
Page 2 Product Features....................25 Control Panel ....................29 Ice and Water Dispenser.................31 Automatic Icemaker ..................33 InstaView......................37 Door in Door .....................37 Drawer.......................37 Shelf ........................38 Door Basket ......................39 SMART FUNCTIONS LG ThinQ Application ..................41 Smart Diagnosis ....................43 MAINTENANCE Cleaning ......................44 Water Filter .......................45 Air Filter ......................46...
Page 3 TROUBLESHOOTING Before Calling for Service................48 APPENDIX CARING FOR THE ENVIRONMENT ..............56...
Page 4 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
Page 5 SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 6 Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble or repair the appliance.
Page 7 SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials • If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes. In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance is used should correspond to the amount of refrigerant used.
Page 8 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
Page 9 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
Page 10 SAFETY INSTRUCTIONS - If connected to a water supply, connect to a potable water supply only. • Fill with potable water only. - If using an icemaker or dispenser water tank, make sure to fill it with potable water only. Disposal •...
Page 11 They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • To remove frost from the appliance, contact an LG Electronics customer information centre. • Dispose of the ice inside the ice bucket in the freezer compartment...
Page 12 INSTALLATION INSTALLATION Before Installation • The climate class can be found on the rating label. Dimensions and Clearances Ambient Temperature Climate Class Too small of a distance from adjacent items may Range ºC result in the degradation of freezing capability and SN (Extended +10 - +32 increased electricity costs.
Page 13 INSTALLATION Accessories at the bottom of the front side of the cover with a flat-head screwdriver. *1 This feature is only available on some models. Removing the Left Fridge Door Spanner C-Clip (Snap Ring) The water supply line is connected to the top Water Filter right part at the back of the appliance.
Page 14 INSTALLATION Lift the door from the middle hinge pin and NOTE remove the door. • Disassembling/Assembling the Water Lines Collet Tube Insert line Clip CAUTION • Place the door, inside facing up, on a Pull out the water supply lines .
Page 15 INSTALLATION Rotate the hinge lever clockwise. Lift the top Twist the hinge to raise the pivoting end so that the door can be lifted off. Lift the door off the hinge free of the hinge lever latch lower hinge pin and remove it. CAUTION Remove the door by lifting it off the lower •...
Page 16 INSTALLATION banging in the pipes) in house plumbing can NOTE cause damage to appliance parts and can lead to water leakage or flooding. Correct • Connect to potable water supply only. • Connecting the water line must only be installed by a qualified plumber and in accordance with local legislation and regulations governing water quality.
Page 17 INSTALLATION should be held firmly whilst the connector is Press and hold the Water Filter button for pushed onto the pipe. three seconds. The new water filter has been activated. Place a cup under the water dispenser to verify that water is flowing through the appliance. Check the connecting tube and joints for leaks once again.
Page 18 INSTALLATION Door Alignment for Freezer NOTE Door - Spanner Type C If the door of the appliance is not level, adjust the difference in the height of appliance door. Levelling the Appliance The appliance has two front levelling legs. Adjust the legs to alter the tilt from front to back or side to side.
Page 19 INSTALLATION If the door is too low, lift the left door up and use Use the spanner to fasten the keeper nut by a pair of long nose pliers to insert C-Clips until turning it to the right. both doors are level. •...
Page 20 INSTALLATION Moving the Appliance for • Type B Relocation Moving the Appliance If the door is too low, lift the right door up and insert only one C-Clip with proper thickness. Remove all food from inside the appliance. - If a C-Clip is already inserted on the middle hinge, remove the C-Clip before inserting a new C-Clip.
Page 21 INSTALLATION - Do not move the appliance in zigzags. After installing the appliance, connect the power plug into a mains outlet socket and switch it on.
Page 22 NOTE • Contact the LG Electronics customer information centre if the alarm sound continues even after Suggestion for Energy Saving closing all doors. • For the most efficient use of energy, keep all inner parts (e.g.
Page 23 OPERATION • When storing food in the freezer compartment, • If there are chill compartments in the appliance, set the freezer temperature lower than the do not store vegetables and fruits with higher temperature indicated on the food. moisture content in the chill compartments as they may freeze due to the lower temperature.
Page 24 OPERATION NOTE • The shape of each drawer may be different, insert in the right position.
Page 25 OPERATION Product Features The appearance or components of the appliance may differ from model to model. Exterior *1 This feature is only available on some models. Filtered Water and Ice Dispenser Dispenses purified water and ice. Door in Door The Door in Door is a double layered door system. It can be opened individually or together with the main door.
Page 26 OPERATION Interior *1 This feature is only available on some models. Control Panel Sets the fridge temperature and freezer temperature.
Page 27 OPERATION LED Lamp The LED lamps inside the fridge light up when you open the door. Air Filter Reduces odours inside the fridge compartment. Automatic Icemaker This is where ice is automatically produced and stored. Water Dispenser Tank Stores water to supply the dispenser or the automatic icemaker. It requires manual filling. Fridge Door Basket Stores small packages of refrigerated foods, drinks and sauce containers.
Page 28 OPERATION Freezer Tray Stores small packaged frozen food or frequently-used foods. The sliding trays allow easy access and convenience of use. Freezer Drawer Stores frozen food for longer storage.
Page 29 OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Craft Ice After pressing and holding the Craft Ice button for three seconds, press the button repeatedly to set to 6 ICE, 3 ICEor OFF.
Page 30 Water Filter Replace the water filter when the indicator lights up. Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the LG ThinQ application. Non Plumbing...
Page 31 OPERATION The Non Plumbing icon is illuminated when the water dispenser tank is installed correctly. Water & Ice Type Select the desired dispenser mode from the buttons on the dispenser control panel. Press the dispenser switch with a glass or other container to dispense cubed ice, water or crushed ice. NOTE •...
Page 32 OPERATION Using the Ice and Water Cleaning the Dispenser Tray Wipe the entire area with a damp cloth. The Dispenser dispenser tray may become wet easily due to spilled ice or water. Press the dispenser selection button , and then the LED above the icon that you want illuminates.
Page 33 OPERATION Fill with bottle filtered or clean filtered water up CAUTION to the reference line indicated inside the water • Do not apply excessive force or impact when dispenser tank. (Total capacity: 4 ℓ) removing or assembling the water dispenser tank.
Page 34 • If discoloured ice is dispensed, check the water Before Using the Freezer tank and the water supply for a possible source. If the problem continues, contact the LG Icemaker Electronics customer information centre. Do not use the ice or water until the problem is corrected.
Page 35 OPERATION Freezer Icemaker (Craft Ice) hours. In 6 ICE mode, the Craft Ice icemaker produces 2 batches of round ice (6 pieces total) This feature is only available on some models. in the same period. • For more ice, select the 6 ICE mode. For clearer ice, select the 3 ICE mode.
Page 36 OPERATION not continue to make ice due to sensor Gently pull the handle to open the ice disruption. compartment. Turning the Icemaker On/Off To turn the automatic icemaker On/Off, press and hold the Ice On button on the control panel for three seconds.
Page 37 OPERATION InstaView Door in Door This feature is only available on some models. This feature is only available on some models. Using the InstaView Using the Door in Door The InstaView lets you see if you’re running low on Pull the lever at the bottom of the door upwards frequently used items like beverages and snacks, until the door in door opens.
Page 38 OPERATION Removing/Refitting the Freezer Open both fridge doors completely. Hold the Drawer cover with both hands and tilt the cover slightly while pulling it out. This feature may vary depending on model purchased. Open both freezer doors completely. Pull out the freezer drawer to full extension and remove all of the contents.
Page 39 OPERATION exposed to sudden temperature changes or To assemble, tilt the front of the shelf up and impact. guide the shelf hooks into the slots at a desired height. Using the Folding Shelf This feature is only available on some models. Lower the front of the shelf so that the hooks Store taller items, such as gallon containers or drop into the slots.
Page 40 OPERATION To remove the baskets, simply lift the basket up and pull straight out. To assemble the baskets, slide it in above the desired support and push down until it snaps into place.
Page 41 • Functions may vary by model. Run the LG ThinQ application and sign in with your existing account or create an LG account to sign in. Touch the add ( ) button on the LG ThinQ application to connect your LG appliance.
Page 42 To check your network frequency, contact your Internet service provider or refer to your Radio Equipment Specifications wireless router manual. • LG ThinQ is not responsible for any network connection problems or any faults, Operating malfunctions, or errors caused by network...
Page 43 If you experience a problem with your Wi-Fi equipped appliance, it can transmit troubleshooting data to a smartphone using the LG ThinQ application. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.
Page 44 MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • Before removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to • Performing manual defrosting, maintenance or the appliance.
Page 45 • Do not install if water pressure exceeds 1 MPa. If - Visit your local dealer or distributor or contact your water pressure exceeds 1 MPa, you must the LG Electronics Customer Information install a pressure limiting valve. Contact a Centre. For further assistance, visit our plumbing professional if you are uncertain how website at lg.com...
Page 46 • Failure to replace filters when required or using Place the new filter inside of the cover with the non LG authorised water filters can cause the side that says FRONT facing outward. filter cartridge to leak and result in property...
Page 47 MAINTENANCE Align tabs on the filter cover with hooks on the fridge wall. Rotate the air filter cover clockwise until the hooks engage and the cover locks in place. Press and hold the Air Filter button on the control panel for 3 seconds to reset the filter. CAUTION •...
Page 48 TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Appliance is unplugged. • Plug the power plug in the outlet properly. A fuse in your home may be blown or the circuit breaker tripped.
Page 49 • Press I on the automatic icemaker switch or set ON for the automatic icemaker button on the control panel. (For more details on how to use, visit LG Electronics website or use your smart device.) Is the temperature of the freezer compartment set too high? •...
Page 50 TROUBLESHOOTING Symptoms Possible Cause & Solution The automatic Is the appliance door completely closed? icemaker does not • If the appliance door is not completely closed, the temperature of the produce ice or freezer compartment will increase, slowing down the ice production produces a small speed.
Page 51 TROUBLESHOOTING Symptoms Possible Cause & Solution Water tastes strange. Has the purified water or cold water not been used for an extended period of time? • The taste of old water may change due to bacterial growth. Use the product after dispensing and discharging approximately 5 litres (approximately three minutes) from the water dispenser.
Page 52 TROUBLESHOOTING Symptoms Possible Cause & Solution Frost or condensation Is the installation environment humid? has formed inside or • Condensation can appear on the exterior of the appliance if the installation outside the appliance. area is too humid or on a humid day such as a rainy day. Wipe off any moisture with a dry cloth.
Page 53 Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp. Noises Symptoms Possible Cause & Solution...
Page 54 Move the location of the router so that it is closer to the appliance. Customer Care and Service Contact an LG Electronics customer information centre. • To find information on LG authorized service centre, visit our website at www.lg.com.
Page 55 • The minimum warranty period of this refrigerating appliance is 24 months. • Spare parts referenced in Regulation EU 2019/2019 are available for 7 years (only door gaskets are available for 10 years). • To purchase spare parts, contact an LG Electronics customer information centre or our website at www.lg.com. NOTE •...
Page 56 APPENDIX APPENDIX CARING FOR THE ENVIRONMENT Disposal of Your Old Appliance...
Page 57 APPENDIX...
Page 58 APPENDIX...
Page 59 APPENDIX...
Page 60 APPENDIX...
Page 61 APPENDIX...
Page 62 APPENDIX...
Page 63 APPENDIX...
Page 64 APPENDIX...
Page 65 APPENDIX...
Page 66 Memo...
Page 67 Memo...
