FLA00102B-2
Outdoor Furniture
IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
PLEASE DO NOT RETURN TO THE RETAILER/STORE
from where you purchased the product.
1-866-988-3300
Please call our Toll-Free Customer Service Hotline at:
Between 8:00 AM and 5:00 PM Pacific Standard Time, Monday through Friday
To expedite any future warranty claims, please retain the instruction sheet, warranty card
and receipt for future use.
Care and Maintenance
Store furniture in an upright position. Be careful to never allow water to build up in frames as this will
cause corrosion and freeze damage in cold climates. Wash all frames with a solution of mild soap and
water. Rinse with clean water and dry with a soft absorbent cloth towel. Frames can be treated with a
liquid wax for maximum protection against UV rays and/or salty, damp air. If your set includes cushions,
slings, and/or an umbrella they may be cleaned by hand with a solution of soap and water with a clean
water rinse. (Never machine wash cushions, slings or umbrella covers as this will result in shrinkage or
damage). After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer
to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty.
4
Advertisement
Related Manuals for Hanover FLA00102B-2
Summary of Contents for Hanover FLA00102B-2
- Page 1 FLA00102B-2 Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. 1-866-988-3300 Please call our Toll-Free Customer Service Hotline at:...
- Page 2 FLA00102B-2 Outdoor Furniture 1-Year Limited Warranty Program For a period of one (1) year after date of purchase, the Manufacturer will either repair or replace defective components in accordance with this Limited Warranty. This warranty is between the Manufacturer and the original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing original date of purchase and location of purchase.
- Page 3 Assembly Instructions FLA00102B-2 Aluminum Sling Chaise Lounge Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. -5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 4 FLA00102B-2 Parts & Tools PART PICTURE & DESCRIPTION PART PICTURE & DESCRIPTION Seat & Back Bucket M6x15 Screw M6 Flat Washer Front Rear Leg Allen Wrench WARNING: To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
- Page 5 FLA00102B-2 Chaise Lounge Assembly Step 1: Attach the front leg (B) to the seat & back Bucket (A) by lining up the screw holes on the front leg (B) and Seat & Back Bucket (A). Insert M6x15 screw (E) through M6 flat washer (F).
- Page 6 Assembly Instructions FHTS80048D Outdoor Fireplace Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday ContactUs@Hanover-Products.com Retain this manual for future use.
- Page 7 Contents Safety Instructions Parts List Assembly Operation Cleaning & Maintenance Troubleshooting Warranty Specifications This appliance complies with “ANSI Z21.97-2017/CSA 2.41-2017, Outdoor Decorative Gas Appliances.” IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. FHTS80048D...
- Page 8 Safety Instructions WARNING WHAT TO DO IF YOU SMELL GAS For your safety: For outdoor use only (outside, only (outside, non-enclosed area). Do not use for cooking. • Do NOT try lighting any appliance. • Do NOT touch any electrical switch. •...
- Page 9 Safety Instructions WARNING FIRE TABLE IS FOR OUTDOOR USE ONLY Installation and repair should be done by a qualified service person. The appliance should be inspected before use and at least annually by a qualified service person. More frequent cleaning may be required as necessary.
- Page 10 Safety Instructions • Only use propane gas for this unit. • Converting this unit to natural gas is dangerous. This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority having jurisdiction. The maximum inlet natural gas pressure for this outdoor fire table is 10 1/2”...
- Page 11 Safety Instructions fire table is not in use. • DO NOT sit on the fire table when the unit is in operation. • DO NOT throw anything onto the fire when the unit is in operation. • Lava rocks are very hot; please keep children or pets at a safe distance. •...
- Page 12 Safety Instructions ANSI Z223.1/NFPA54, or CAN/CGA-B149.1, Natural Gas and Propane Installation Code. • LP gas tank must be arranged for vapour withdrawal. • The LP gas tank must have a listed overfilling prevention device (OPD) and a QCCI Type I (CGA810) LP gas tank connection.
- Page 13 Safety Instructions a. The CGA No 791 connection incorporates a magnetic flow limiting device that acts to limit the flow of gas if a leak is detected between the regulator and the burner valve. b. If the burner valve is open prior to the LP gas cylinder service valve being opened, the connection will interpret this free flow of gas to be a leak.
- Page 14 Safety Instructions LAVA ROCKS WARNING: 1. Lava rocks may have sharp edges. Wear safety glasses and gloves when handling. 2. If changing or substituting the lava rocks with other media, use lava rocks/pumice stones/glass shards/glass beads available from your local authorized dealer/distributor. 3.
- Page 15 Parts List Frame - 1 Handle - 1 Lava Rock - 1 Bag Burner Bowl - 1 (pre-assembled) Burner Ring - 1 (pre-assembled) Pilot Housing - 1 (pre-assembled) Flame Igniter - 1 (pre-assembled) Switch Knob - 1 (pre-assembled) Regulator Hose - 1 (pre-assembled) AAA Battery - 1 FHTS80048D...
- Page 16 Assembly STEP 1 Required Pieces: A, D, E, F Install handle (D) to frame (A), and tighten by hand. Place the lava rocks (E) into the burner bowl (F). Igniter Box Burner Tube Do not block opening CORRECT INCORRECT FHTS80048D...
- Page 17 Assembly STEP 2 Required Pieces: I, J, L Insert the included battery (L) and knob (J) into the electric igniter (I) and twist the button cover onto igniter housing. Do not overtighten. WARNING: Batteries may contain mercury. Do not put batteries into the fire or trash.
- Page 18 Assembly STEP 3 Inserting LP gas tank CAUTION: LP gas tank must be properly disconnected and removed prior to moving this outdoor fireplace. To operate, you will need one precision-filled standard grill LP gas tank with external valve threads. 1. Loosen LP gas tank retainer bolt by turning counter-clockwise. 2.
- Page 19 Assembly STEP 4 Connecting LP Gas Tank Required Pieces: K 1. Before connecting, be sure there is no debris caught head of the LP gas tank, head of the regulator valve or in the head of the burner or burner ports. 2.
- Page 20 Assembly STEP 5 Disconnecting LP Gas Tank Required Piece: K 1. Before disconnecting make sure the LP gas tank valve is “CLOSED”. 2. Disconnect regulator/hose assembly from LP gas turning knob counter-clockwise until it is loose. 3. Place the protective cap cover on LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight.
- Page 21 Assembly STEP 6 Checking for Leaks WARNING: Before using this outdoor fireplace, make sure you have read, understand and are following all information provided in the “Important Safeguards” section. Failure to follow those instructions can cause death, serious injury or property damage. Failure to inspect this connection or follow these instructions could cause death, serious bodily injury or damage to property.
- Page 22 Assembly STEP 7 Leak Test 1. Make 2-3 oz of leak detection solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are in the “OFF” position. 3. Connect LP gas tank per “Installing LP Gas Tank” section. 4.
- Page 23 Assembly STEP 8 Once your propane tank is properly installed close the door on the fire pit. FHTS80048D...
- Page 24 Assembly STEP 9 Now the firepit is complete and ready to use. FHTS80048D...
- Page 25 Operation WARNING NEVER light the burner with the cover on the outdoor fireplace. CAUTION PROPER FLAME HEIGHT Do NOT obstruct the flow of combustion and ventilation air. CAUTION Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire. CAUTION Keep outdoor gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
- Page 26 Operation LIGHTING (CONTINUED) 11. If igniter does not light burner: a. Wearing heat-resistant gloves, position a long, lit match or long, lit butane lighter near the pilot housing. b. Push and turn control knob to “ON”. c. Remove match/lighter once burner is lit. 12.
- Page 27 Cleaning & Maintenance Cleaning Surfaces 1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water. 2. For stubborn stains, use a citrus-based cleaner and a nylon scrubbing brush. 3. Rinse clean with water. 4. Allow to air dry. Before Storing 1.
- Page 28 Troubleshooting LP gas tank valve is closed Make sure regulator is securely attached to the LP gas tank per “Installing LP Gas Tank,” then turn LP gas tank valve to “OPEN” LP gas tank is low or empty Exchange, refill or replace LP gas tank LP gas leak 1.
- Page 29 Troubleshooting Out of gas Exchange, refill or replace LP gas tank Overfilling prevention device may 1. Turn control knob to “OFF” have been activated 2. Wait 30 seconds and light outdoor fireplace per “Lighting” section 3. If flames are still too low, reset the overfilling prevention device: Sudden drop a.
- Page 30 Warranty Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. Please call our Toll-Free Customer Service Hotline at: 1-866-988-3300 Between 8:00 AM and 5:00 PM Pacific Standard Time, Monday through Friday To expedite any future warranty claims, please retain the instruction sheet, warranty card and receipt for future use.
- Page 31 Warranty Outdoor Furniture 1-YEAR LIMITED WARRANTY PROGRAM For a period of one (1) year after date of purchase, the Manufacturer will either repair or replace defective components in accordance with this Limited Warranty. This warranty is between the Manufacturer and the original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing original date of purchase and location of purchase.
