- Page 1 PHONE SUPPORT WARRANTY Small Kitguard MINI ALARM KIT Includes motion detector, remote control, door opening detector and door opening detector with integrated siren Ref. 100021 433 MHz 90 dB BUILT-IN SIREN www.avidsen.com...
- Page 3 CONTENTS A - SAFETY 3 - INFRARED SENSOR 3.1 - POWER ON INSTRUCTIONS 3.2 - LED INDICATOR 3.3 - OPERATING INSTRUCTIONS 3.4 - SETTING SWITCHES 1 - OPERATING PRECAUTIONS 3.5 - INSTALLATION 2 - MAINTENANCE AND CLEANING 4 - DOOR DETECTOR 3 - RECYCLING 4.1 - POWER ON 4.2 - INSTALLATION...
- Page 4 A - SAFETY INSTRUCTIONS This symbol means that devices no 1 - OPERATING PRECAUTIONS longer in use should not be disposed of with household waste. The hazardous • Do not allow children to handle the product. substances they may contain can be •...
- Page 5 B - PRODUCT DESCRIPTION 1 - KIT CONTENTS Opening detector with keypad Opening detector Presence detector A remote arming and disarming device Installation and double-sided adhesive kit AAA batteries CR2032 battery...
- Page 6 C - INSTALLATION 1 - OPENING DETECTOR WITH KEYPAD 1.3 - SWITCHES switch 1.1 - POWER ON Install the 2 AAA batteries in the compartment on the back of the product. The device will beep once and the four LEDs will light up to indicate that the Alarm Doorbell device is switched on.
- Page 7 C - INSTALLATION 2 - REMOTE CONTROL 2.2 - OPERATION Remote control of door opening detector with 2.1 - POWER ON keypad. The CR2032 battery is already installed in the Delayed remote control. arming Disarming If the battery does not work anymore. Take a Armed screwdriver and a CR2032 battery.
- Page 8 C - INSTALLATION 2.4 - DELETING A REMOTE CONTROL 3.3 - OPERATING INSTRUCTIONS Press and hold the “ ” button; the 4 LEDs light up, Antenna the detector enters the settings menu. Next, press and hold “ ”; the detector’s indicator light flashes five times and the detector beeps five times.
- Page 9 4.2 - INSTALLATION Distance between detector and magnet: < 10 mm Mounting height: The door opening detector is designed for View from above installation on doors and windows. Before installing 110° the product, clean the surface thoroughly. When installing, check that the small triangle on the magnet is on the same level as the small triangle on the detector.
- Page 10 C - INSTALLATION If the selected digit flashes once and the detector The zone indicator light flashes five times and beeps once, the accessory has already been the detector beeps five times. This means that all paired. detectors have been deleted from the zone. If the selected digit flashes 3 times and the detector Note: beeps three times, the detector cannot add any...
- Page 11 Normal zone: The mini-alarm only works when 7 - INSTALLATION armed. Emergency zone: Regardless of the mini-alarm state, when a sensor is activated in this zone, it triggers the alarm. Chime zone: regardless of the mini-alarm state, when a sensor in this zone is triggered, a bell rings by way of notification.
- Page 12 The warranty does not cover damage caused by negligence, knocks, or accidents. The parts of this product must not be opened or repaired by any persons not employed by Avidsen. The warranty will be void if the device is tampered with.
- Page 13 4 - EU DECLARATION OF CONFORMITY Avidsen hereby declares that the equipment designated below: AVIDSEN SMALL KITGUARD reference 100021 complies with the RED 2014/53/EU directive and its conformity has been assessed pursuant to applicable standards: ETSI EN 301 489-1 V2.2.3 (2019-11) ETSI EN 301 489-3 V2.1.1 (2019-03)
- Page 14 Avidsen 19 avenue Marcel Dassault - ZAC des Deux Lions 37200 Tours - France...
