- Page 1 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Hydraulic Trolley Jack 3 T AR-HE-HRW3T Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO List of contents 1. Safety instructions ......3 1.1 Explanation of the symbols ....................3 1.2 General safety instructions ....................4 2. Set Up ..........5 2.1 Overview of product ......................5 2.2 Control before use ......................
- Page 3 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it.
- Page 4 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 1.2 General safety instructions • This jack is designed for lifting objects only and shall be supported by an adequate aid, such as a stand. • Make sure that the lifted object is firmly fixed to the jack. •...
- Page 5 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 2. Set Up 2.1 Overview of product A. Handle Socket H. Oil filler plug B. Foot pedal Knurled Knob C. Lifting arm J. Safety overload valve D. Saddle E.
- Page 6 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 3. Operation 3.1 Bleeding BEFORE EACH USE OR IF JACK PERFORMANCE DECREASES check for excessive air and proper hydraulic fluid level in Jack. If Jack appears not to be working properly, it may be necessary to purge its hydraulic system of excessive air as follows: 1) Remove the oil Filler Plug (H).
- Page 7 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 3.3.1 Lifting 1) Park vehicle on a flat, level, solid, surface safely away from oncoming traffic. Turn off the vehicle’s engine. Place the vehicle’s transmission in “PARK” (if automatic) or in its lowest gear (if manual).
- Page 8 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 4. Explosion view...
- Page 9 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Part description Part description Part description Part description saddle left side plate washer screw assembly lifting arm right side plate throttle valve steel ball assembly assembly radius link frame tie rod spring reservoir...
- Page 10 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 5. Maintenance of the jack • If you want to stow the jack, lower the jack to the lowest position and close the drain valve. • Keep the jack clean. Lubricants should be applied to all moving parts every three months. •...
- Page 11 Our customer service number: Tel. +44 (0) 208 068 5604 Fax: +49 (0) 931 4523 2799 / E-Mail: info@arebos.de Office address: Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/...
- Page 12 Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
- Page 13 User’s Manual – AREBOS Axle stand 3 t Axle stand 3T AR-HE-UB 3 Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 14 User’s Manual – AREBOS Axle stand 3 t List of contents 1. Safety ..........3 1.1 Safety signs ..............3 1.2 Safety instructions ............3 2. Product Overview ....... 5 3. Technical specifications ...... 6 4. Operation ........... 6 5. Maintenance ........7 6.
- Page 15 User’s Manual – AREBOS Axle stand 3 t Please read and save these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
- Page 16 User’s Manual – AREBOS Axle stand 3 t • Use only as specified by the manufacturer. • No alterations or modifications shall be made to this product. • Ensure the load does not exceed the maximum capacity as marked on the axle stand, per pair.
- Page 17 User’s Manual – AREBOS Axle stand 3 t • PLEASE FOLLOW STEPS 1, 2 AND 3 TO CORRECTLY PLACE VEHICLE/LOAD ONTO AXLE STANDS. 2. Product Overview Explosive View Part Part name number Rubber Pad Rachet assembly Frame assembly Axle assembly...
- Page 18 User’s Manual – AREBOS Axle stand 3 t 3. Technical specifications • Changes are reserved. Modell AR-HE-UB3 Capacity 3000 kg Min. HEIGHT (Without Saddle Pad) 295 mm Max. HEIGHT (Without Saddle Pad) 438 mm Min. HEIGHT (With Saddle Pad) 299 mm Max.
- Page 19 User’s Manual – AREBOS Axle stand 3 t 5. Maintenance • Check the stands for optical defects such as scratches, cracks, missing or damaged parts. If you find any damage, do not use the jack. WARNING! Any stand that appears to be damaged in any way must be removed from service immediately.
- Page 20 User’s Manual – AREBOS Axle stand 3 t Imprint Name of the product: Arebos Axle stand 3t (pair) Model Nr.: AR-HE-UB3 Art. Nr.: 4252023112277 If the product has any modification not allowed by us, this declaration loses its validity. Date/Manufacturer Signature/Location: Würzburg, 23/12/2022...
