- Page 1 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Hydraulic Trolley Jack 3 T AR-HE- HRW3 Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO List of contents 1. Safety instructions ......3 1.1 Explanation of the symbols ......................3 1.2 General safety instructions ......................3 2. Construction ........5 2.1 Overview of product ........................5 2.2 Control before use ......................... -
Page 3: Safety Instructions
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it. - Page 4 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO • Use the jack only on a firm surface that can support the load. • Make sure that the jack is central and stable with its supporting saddle under the object and the lifting point.
-
Page 5: Construction
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 2. Construction 2.1 Overview of product A. Handle Socket I. Grease Fitting B. Cover Plate J. Oil Fill Screw C. Lifting arm K. Safety Valve Covers D. Saddle L. -
Page 6: Attaching The Saddle, Front Wheels, Rear Wheels
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 2.3 Attaching the saddle, front wheels, rear wheels Saddle (Fig.2) • Place the metal saddle directly onto the lifting arm at the top of the jack. • Align the hole and secure it with the provided bolt. Front Wheels (Fig. -
Page 7: Operation
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 3. Operation 3.1 Bleeding BEFORE EACH USE OR IF JACK PERFORMANCE DECREASES , check for excessive air and proper hydraulic fluid level in Jack. If Jack appears not to be working properly, it may be necessary to purge its hydraulic system of excessive air as follows: 1) Turn handle counterclockwise to open Release Valve. -
Page 8: Lifting And Lowering
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 3.3 Lifting and Lowering 3.3.1 Lifting WARNING! Park vehicle on a flat, level, solid, surface safely away from oncoming traffic. Turn off the vehicle’s engine. Place the vehicle’s transmission in “PARK” (if automatic) or in its lowest gear (if manual). -
Page 9: Lowering
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO WARNING! The rated capacity of jack stands is per pair, not the individual capacities combined unless specifically noted on the product by the jack stand manufacturer. Do not exceed rated jack stand capacity. -
Page 10: Explosion View
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 4. Explosion view... - Page 11 Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO Part Description Part Description Part Description Number Number Number Saddle Bowl-Type washer Pump core rest spring Saddle bolt Y-type seal Spring sleeve Lifting arm Snap ring Spring stop sheet assembly Rocker Arm Top nut...
-
Page 12: Cleaning, Maintenance, And Lubrication
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 5. Cleaning, Maintenance, and Lubrication WARNING! To prevent serious injury from tool failure: Do not use damaged equipment. if abnormal noise or vibration occurs, have the problem corrected before further use. 1) BEFORE EACH USE: inspect the general condition of the jack. -
Page 13: Troubleshooting
Original User Manual – A S Hydraulic Trolley Jack 3 Ton REBO 6. Troubleshooting WARNING: DO NOT USE A DAMAGED OR MALFUNCTIONING JACK. PROBLEM POSSIBLE CAUSE REMEDY 1) Overloaded 1) Be sure to use jack with adequate Jack will not lift the 2) Oil level low capacity load... -
Page 14: Specifications
Our customer service number: Tel. + 49 931 90 80 3000 E-Mail: info@arebos.de Office address: Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/... -
Page 15: Ec Declaration Of Conformity
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
