Summary of Contents for OLIGHT Arkfeld Ultra
- Page 2 IN THE BOX Arkfeld Ultra WHITE LIGHT: MAX 9W UV LIGHT: MAX 1.8W LASER: MAX 0.08W COOL WHITE CCT: 5700~6700K CRI:70 1400 4 min TURBO 100% lumens 121 min 135 min HIGH 100% lumens 12 min 9 h 45 min...
- Page 3 Max Output: 5mW @510nm~530nm Wavelength Caution: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Above data are tested per ANSI/PLATO FL 1-2019 standard in Olight's labs for reference. 0.5m Cable length Input USB-A DC 5V 1A CC&CV 4.2V 1A...
- Page 4 Figure 1 Lock/Unlock Press and hold >1 sec >2 sec Figure 2 Charging GREEN Charging Completed Charging...
- Page 5 Figure 3 Selector---Switch Mode: Laser UV Light White Light Rotate the selector Rotate the selector counterclockwise clockwise Selector Button Mode change...
- Page 6 OPERATE IN WHITE LIGHT MODE Figure 4 ON/OFF Press Figure 5 Moonlight Press and hold 1 to 2 sec Moonlight...
- Page 7 Figure 6 Turbo Triple press TURBO Figure 7 Strobe Double press Strobe...
- Page 8 Figure 8 Change Brightness Level Press and hold Moonlight Turbo High Medium Figure 9 Timed shutdown Double press and hold Blink once : 3 min Blink twice : 9 min...
- Page 9 OPERATE IN LASER MODE Figure 10 ON/ OFF Press Figure 11 urn on the white light while the aser on Double press OFF(white light) ON(High)
- Page 10 Figure 12 Turn off the white light while the laser on Double press ON (white light) Figure 13 When the laser and white light are turned on at the same time, change the brightness of the white light Press and hold High Medium...
- Page 11 OPERATE IN UV MODE Figure 14 ON/ OFF Press Figure 15 Battery Level Indicator Display Four green indicators (>75%) Three green indicators (50%-75%) Two green indicators (25%-50%) One green indicator (10%-25%) * One red indicator (＜10%)
- Page 12 （ EN ） English 1. Please refer to Table 1 and Table 2 for product specifications; 2. Lock/unlock, see Figure 1; When the light is off, press and hold the button (about 2 seconds) until you see moonlight mode, the laser (Laser mode), or UV light (UV mode) turn on and then quickly off, the flashlight has then been locked out.
- Page 13 When the laser and white light are on at the same time, press and hold the button to cycle through the brightness levels. The order of brightness is low, medium, then high. 7. In UV mode, turn on/off the flashlight, see Figure 14; Single press the button to turn on or off the UV light;...
- Page 14 FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 15 NMB-005 du Canada. EU Declaration of Conformity Hereby Hereby Dongguan Olight E-Commerce Technology Co.,Ltd declares that the equipment [Arkfeld Ultra] is in compliance with Directive 2014/30/EU and RoHS Directive 2011/65/EU & (EU) 2015/863. The full text of the EU declaration of conformity is available at the following internet address:https://www.olight.com/download.
- Page 16 2 or 5-year warranty. The warranty covers defects in material and workmanship under normal use, excluding loss, theft, deliberate damage, or cosmetic damage. For complete warranty information, please visit Olight.com or your local Olight official website.
- Page 17 For other countries and regions, please contact Global Customer Support contact@olight.com Dongguan Olight E-Commerce Technology Co., Ltd 4th Floor, Building 4, Kegu Industrial Park, No. 6 Zhongnan Road, Chang'an Town, Dongguan City, Guangdong, China. Made in China CAN ICES-005 (B) / NMB-005 (B) 3.4000.1036...
