- Page 1 User 's manual...
- Page 2 Product Safety Information (1) This device does not come with a power adapter. When charging, please use a power adapter that has obtained CCC certification and meets relevant standards. (2) Please use this device within the temperature range of 0℃-35℃, and store the device and accessories within the temperature range of -20℃...
- Page 3 (6) Dispose of the device, battery, and related accessories in accordance with local regulations. Do not dispose of them as household waste. Warning: The battery (battery pack or combination battery) should not be exposed to environments with excessive heat such as sunlight or open flames.
- Page 4 Accessories 4 5 6 7 Key Function ⑴ Microphone ⑵ Magnetic ring ⑶ Power switch ⑷ Recording indicator light ⑸ Power Indicator light ⑹ USB interface ⑺ Reset switch Note: The appearance picture is subject to the actual product...
- Page 5 Power On/Off (1) Power On: Push the power switch button to the ON position, the device power indicator light will stay on and then turn into a flashing blue light. The recorder will power on and enter the recording mode. (2) Power Off: In the power on state, push the power switch button to the OFF position, all indicator lights will go off, and the recorder will...
- Page 6 4. Bluetooth Connected: In recording mode, when the recorder is connected to an app, the recording will automatically stop, and the power indicator light will stay on, indicating that the device is connected to the app. 5. Saving Recording: Power off and all indicator lights will go off, indicating that the recorder has saved the recording and powered off.
- Page 7 7. Charging: When the device is being charged by connecting to a charger, the power indicator light will stay on in red. After charging is complete, the power indicator light will turn off in red. APP Download and Installation This recorder can be used independently or paired with the "DVR Link"...
- Page 8 Bluetooth Connection When the recording pen is in the power-on state, log in to the "DVR Link" APP on your phone, click the "Connect Device+" button in the top menu bar, search for the device and connect it via Bluetooth. After successful Bluetooth connection, the "Connected"...
- Page 9 Voice Recording 1. Recording initiated on the pen: When the recording pen is not connected to the APP, after power-on, the red power indicator light goes off and the blue recording indicator light flashes, indicating that the recording pen has entered the recording state.
- Page 10 3. Ending recording: When the recording pen is not connected to the APP, turn off the power switch to shut down and save the recording. When the recording pen is connected to the APP, click the "Stop Recording" button in the top menu bar of the APP, and the APP will prompt whether to save the file.
- Page 11 Playback and Management of Recorded Files 1. Playback of recorded files: Saved recorded files can be directly played on the app. Click on the audio file saved on the app to start playing the current recorded file. 2. Editing of recorded file names: In the app's recorded file list, find the recorded file you need to...
- Page 12 3. Audio Sharing: While playing or stopping an app audio file, swipe left to bring up the menu, choose "share," and share the current recorded file with your friends via mainstream media such as Facebook, Twitter or Instagram.
- Page 13 File Deletion In the app, you can directly delete local and recorded files on the recording pen. Find the file you want to delete, swipe left to bring up the menu, choose "delete," and select "delete local audio only" or "delete local and recorded audio."...
- Page 14 Batch Deletion On the app, click the top menu bar's upper-left file selection button to bring up the batch deletion menu option. After clicking, you can batch select the files you want to delete, and then choose to "delete local audio only" or "delete local and recorded audio."...
- Page 15 Hidden Recording The device can be set to hide and turn off the recording indicator light. Click the top menu bar's upper-right menu button to enter the settings menu, find the "Hidden Recording" switch, set the switch to the "on" position, and the recording indicator light will be hidden.
- Page 16 Setting Menu While the recording pen is connected to the APP, you can view the real-time battery and memory usage status, as well as the firmware version. Click the menu button at the top right corner of the menu bar to enter the setting menu, where you can view the battery level, memory space, and firmware version of the recording pen.
- Page 17 Insert the small end of the USB cable (included in the package) into the USB port of the recording pen and the large end into the USB port of a computer or charger. The red power indicator light will stay on continuously to indicate that the recording pen is in charging mode.
- Page 18 Technical Specifications: 1. Dimensions: 60×22×16MM 2. CPU: ATS2837, dual-core 240MHZ 3. Bluetooth: dual-mode Bluetooth 5.0 4. Mobile System: Android 5.0 or above / IOS 9.0 or above 5. Mobile Magnetic Attraction: supports magnetic attraction for iPhone 12 and above 6. USB Interface: TYPE C 10PIN USB2.0 7.
- Page 19 Statement Please be sure to back up the data by yourself during use. The company is not responsible for any loss or damage to personal data caused by software or hardware errors, product repairs, battery replacement, or other unexpected circumstances, nor is it responsible for any other indirect losses caused by this.
- Page 20 2. During the warranty period, if the user needs to request warranty services for the product, please send email to us through the Amazon order you purchased and tell us the specific problem about your voice recorder, we will always help you until your problem is solved. 3.The following circumstances are not within the scope of free warranty services: (1)Exceeding the warranty period;...
- Page 21 (6)Failure or damage caused by reasons such as dropping, moving or transportation, not related to product quality after purchase; (7)Damage caused by force majeure events such as lightning strikes, floods, fires, earthquakes, etc.; (8)Random accessories are not covered by the warranty.
