ADCS-601-AF™
Air Data Calibration Standard
Operation and Maintenance Manual
NSN 6695-01-534-6087
© 2005 - 2007 DH Instruments, a Fluke Company

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADCS-601-AF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DH Instruments ADCS-601-AF

Summary of Contents for DH Instruments ADCS-601-AF

  • Page 1 ADCS-601-AF™ Air Data Calibration Standard Operation and Maintenance Manual NSN 6695-01-534-6087 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 2 The fidelity of the translation cannot be guaranteed. In case of conflict between the English version and other language versions, the English version predominates. DH Instruments, DH, DHI, ADCS-601-AF, ADCS Tools, AMH, COMPASS, FPG8601, PG7601, PPC3 and RPM4 and are trademarks, registered and otherwise, of DH Instruments, a Fluke Company.

  • Page 3: Table Of Contents

    3.1.7 FPG8601 PLATFORM, PISTON-CYLINDER AND ACCESSORIES............34 3.1.8 FPG8601 MASS SET (MS-8601-2)......................35 3.1.9 SCROLL VACUUM PUMPS ........................35 3.1.10 TURBO MOLECULAR VACUUM PUMP .....................35 3.1.11 SYSTEM CONTROLLER..........................35 3.1.12 SYSTEM CONTROLLER STAND........................36 Page I © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 4 PRESSURE EXERCISING THE DEVICE UNDER TEST ................63 4.2.6 SETTING A HEAD CORRECTION ......................64 4.2.7 STOPPING PRESSURE CONTROL, ABORTING FUNCTION EXECUTION ..........64 4.2.8 SECURITY, USER RIGHTS.........................65 4.2.8.1 SETTING UP USERS AND MANAGING USER RIGHTS................65 © 2005 - 2007 DH Instruments, a Fluke Company Page II...
  • Page 5 6.6.3.3 LUBRICATING THE PISTON-CYLINDER MODULE ................127 6.6.3.4 CLEANING THE PISTON-CYLINDER ....................128 PG7601, PISTON POSITION DETECTION ADJUSTMENT ..............130 PG7601, REPLACE PISTON ROTATION DRIVE BELTS ..............131 PG7601, ADJUST INTERNAL VACUUM GAUGE................131 Page III © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 6 A P P E N D I X ..............1 5 9 CONVERSION OF NUMERICAL VALUES..................159 9.1.1 PRESSURE..............................159 GLOSSARY............................160 WARRANTY STATEMENT ........................161 © 2005 - 2007 DH Instruments, a Fluke Company Page IV...

  • Page 7: Tables

    Table 22. FPG8601 P, T, H limits ......................141 Table 23. Recalibration requirements...................... 147 Table 24. Troubleshooting checklist ......................157 Table 25. Pressure unit of measure conversions ..................159 Table 26. DHI Authorized Service Providers ................... 161 Page V © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 8 Figure 25. Turbo pump local interface panel (local control not used in regular ADCS-601-AF operation)............ 28 Figure 26. Typical layout of overall ADCS-601-AF system at site of use ..........37 Figure 27. Piston-cylinder module installation ................... 44 Figure 28. Local gravity and pressure medium fields in ADCS Tools ............54 Figure 29.
  • Page 9 Figure 63. ADCS Tools PG7601 Piston-Cylinder Calibration Form ............149 Figure 64. ADCS Tools PG7601 AMH-38 Mass Set Calibration Form ........... 151 Figure 65. ADCS Tools PG7601 Piston-Cylinder Calibration Form ............154 Page VII © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 10 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page VIII...

  • Page 11: A B O U T T H I S M A N U Al

    Before using the manual, take a moment to familiarize yourself with the Table of Contents structure. Set up of an ADCS-601-AF system should not be attempted without using Section 3. All first time ADCS-601- AF users should read Section 4. Section 8 is a quick troubleshooting guide. Use the information in Section 8 to troubleshoot unexpected ADCS-601-AF behavior based on the symptoms of that behavior.
  • Page 12 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page X...

  • Page 13: 1. Introduction

    ADCS-601-AF is not intended to duplicate the functions of an ADTS in calibrating and testing on- board aircraft instruments. ADCS-601-AF covers the pressure range of 1 to 380 kPa (0.3 to 120 inHg) in absolute and gauge modes with fully automated operation and state of the art uncertainty.

  • Page 14: Pg7601 Piston Gauge Specifications

    Cylinder material Tungsten carbide Nominal diameter 35 mm Nominal area 1 000 mm Mounting system Positive free deformation Typtical drop rate 0.2 mm/min Piston assembly nominal mass 0.5 kg © 2005 - 2007 DH Instruments, a Fluke Company Page 2...

  • Page 15: Mass Set

    Maximum deviation of the indicated pressure from the true value of applied pressure including all sources of uncertainty combined and expanded (k=2) following the ISO “Guide to the Expression of Uncertainty in Measurement.” Page 3 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 16: To 15 Kpa, Fpg8601 And Ppc3-100K

    (k=2) following the ISO “Guide to the Expression of Uncertainty in Measurement.” Note: The uncertainty assigned to the FPG8601 used in an ADCS-601-AF system is expanded relative to the standard FPG8601 instrument. to allow validation by the PG7601 and an indefinite recalibration interval.

  • Page 17: S Y S T E M O V E R V I Ew

    Pt and Ps range pressure transducers. To this end, the system automatically sets pressure values with very low measurement uncertainty in the range of 1 to 380 kPa (0.3 to 120 inHg) in absolute and gauge modes. ADCS-601-AF is not intended to duplicate the functions of an ADTS.
  • Page 18 5. Utility vacuum pump 3. Turbo pump controller and reference Note: System controller (PC), display and turbo pump (behind controller) keypad not shown Figure 1. ADCS-601-AF overall, front view © 2005 - 2007 DH Instruments, a Fluke Company Page 6...
  • Page 19 2. SYSTEM OVERVIEW Figure 2. ADCS-601-AF system pneumatic schematic Page 7 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 20 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL Figure 3. ADCS-601-AF simplified operational schematic © 2005 - 2007 DH Instruments, a Fluke Company Page 8...
  • Page 21 2. SYSTEM OVERVIEW Figure 4. ADCS-601-AF system electrical schematic Page 9 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 22 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL Figure 5. ADCS-601-AF system communications schematic © 2005 - 2007 DH Instruments, a Fluke Company Page 10...

  • Page 23: Figure 6. Adcs-601-Af Software, Communications And Control Flow Chart

    2. SYSTEM OVERVIEW Figure 6. ADCS-601-AF software, communications and control flow chart Page 11 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 24: Reference Bench

    2.1.1 REFERENCE BENCH The ADCS-601-AF Reference Bench is a wooden topped laboratory work bench onto which are installed the PG7601 and FPG8601 pressure standards. Also included on the bench is a pneumatic interconnections box (see Figure 8), the system connections to the device under test (DUT) and the pumping system for the reference vacuum against which absolute pressure is defined.

  • Page 25: Control Cabinet

    2.1.2 CONTROL CABINET The ADCS-601-AF Control Cabinet is a 19 inch rack mount enclosure into which are mounted the PPC3 pressure controllers that provide automated pressure control for the PG7601 and FPG8601 pressure standards and an RPM4 Reference Pressure Monitor used to perform the validation comparison of the PG7601 and FPG8601 (see Figure 9).

  • Page 26: Figure 9. Control Cabinet, Front And Rear Views

    6. PPC3 pressure controller for PG7601 system 7. PPC3 pressure controller for FPG8601 system 8. Access door to Gas Supply Panel Figure 9. Control Cabinet, front and rear views © 2005 - 2007 DH Instruments, a Fluke Company Page 14...

  • Page 27: Gas Supply Panel

    2.1.3 GAS SUPPLY PANEL The Gas Supply Panel is in the ADCS-601-AF Control. It is accessed by a door in the lower part of the front of the Control Cabinet (see Figure 9). The Gas Supply Panel is used to set and indicate gas pressure supplies to various ADCS-601-AF systems and components (see Figure 10).

  • Page 28: Pressure Standards

    PRESSURE STANDARDS 2.2.1 PG7601 PISTON GAUGE The heart of the ADCS-601-AF Air Data Calibration Standard is a PG7601 gas operated piston gauge. The PG7601 piston gauge system includes: PG7601 piston gauge platform with terminal (on reference bench) PC-7600/7100-10, TC 10 kPa/kg piston-cylinder module (mounted in platform)

  • Page 29: Platform

    2 x 20 vacuum fluorescent display and 4 x 4 membrane keypad. Local commands to PG7601 are not used in normal ADCS-601-AF operation. See the PG7000 Operation and Maintenance manual for details on local operation of PG7000. 1. Fluorescent display 2.

  • Page 30: 10 Kpa/Kg Piston-Cylinder Module

    PG7601 10 KPA/KG PISTON-CYLINDER MODULE The piston-cylinder module is mounted in the PG7601 Platform (see Section 2.2.1.1) and performs the pressure to force conversion. Figure 15. PG7601 10 kPa/kg piston-cylinder module © 2005 - 2007 DH Instruments, a Fluke Company Page 18...

  • Page 31: Amh-38 Automated Mass Handler

    Operation and Maintenance manual is available with much more complete information than is included in this manual. A copy of the AMH manual is provided on the ADCS-601-AF Support CD and is available at www.dhinstruments.com. 1. KF-40 vacuum connections (2) 5.

  • Page 32: Figure 17. Amh-38 Operating Principle Schematic

    5. Mass lifting assembly 12. Piston cap 6. Lifting ledge on mass lifting shaft 13. Main mass column 7. Electronics and electrical controls 14. Main masses Figure 17. AMH-38 operating principle schematic © 2005 - 2007 DH Instruments, a Fluke Company Page 20...

  • Page 33: Amh-38 Mass Set

    Operation and Maintenance manuals are available with much more complete information than is included in this manual. A copy of the FPG8601 manual is provided on the ADCS-601-AF Support CD and is available at www.dhinstruments.com. The FPG8601 operates on the principle of the piston gauge (see Section 2.2.1); however, the...

  • Page 34: Figure 19. Force Balanced Piston Gauge Operating Principle

    The PPC3 pressure controller is used to automate pressure control to set the pressure measured by the FPG8601. LUBRICATING FLOW SUPPLY MASS COMPARATOR Figure 19. Force balanced piston gauge operating principle © 2005 - 2007 DH Instruments, a Fluke Company Page 22...

  • Page 35: Fpg8601 Platform

    2.2.3 PPC3 PRESSURE CONTROLLERS The ADCS-601-AF system includes two PPC3 pressure controllers that are installed in the Control Cabinet (see Section 2.1.2). One of the pressure controllers is used to automate pressure control for the PG7601 piston gauge system (see Section 2.2.1). The other is used to automate pressure control of the FPG8601 force balanced piston gauge system.

  • Page 36: Figure 21. Ppc3 Front Panel

    The PPC3 pressure controllers are stand alone products for which a separate Operation and Maintenance manual is available with much more complete information than is included in this manual. A copy of the PPC3 manual is provided on the ADCS-601-AF Support CD and is available at www.dhinstruments.com.

  • Page 37: Rpm4 A116K Reference Pressure Monitor

    The RPM4 pressure controller is a stand alone product for which a separate Operation and Maintenance manual is available with much more complete information than is included in this manual. A copy of the RPM4 manual is provided on the ADCS-601-AF Support CD and is available at www.dhinstruments.com.

  • Page 38: Figure 23. Rpm4 Front Panel

    10. Product label (bottom of case) 4. COM2 connector 11. TEST(+) pressure port 5. COM1 connector 12. TEST(-) pressure port 6. Power switch 13. ATM pressure port 7. Fuse Figure 24. RPM4 rear panel © 2005 - 2007 DH Instruments, a Fluke Company Page 26...

  • Page 39: Vacuum Pumps

    2. SYSTEM OVERVIEW VACUUM PUMPS The ADCS-601-AF vacuum pumps are stand alone products for which separate Operation and Maintenance manuals are available with much more complete information than is included in this manual. A copy of the manual is provided on the ADCS-601-AF Support CD.

  • Page 40: Figure 25. Turbo Pump Local Interface Panel (Local Control Not Used In Regular Adcs-601-Af Operation)

    5. Turbo pump START/STOP button. 3. Turbo pump life button 6. Turbo pump LO SPEED button Figure 25. Turbo pump local interface panel (local control not used in regular ADCS-601-AF operation) © 2005 - 2007 DH Instruments, a Fluke Company Page 28...

  • Page 41: I N S T A L L A T I O

    UNPACKING AND INSPECTION Check that all items included in the ADCS-601-AF system are present and have NO visible signs of damage. A parts list of the major components supplied and how they are packed is provided in Table 1. Unpack and inspect the items following the instructions in Sections 3.1.1 to 3.1.12 and detailed parts list Table 1 to Table 10.

  • Page 42: Adcs Control Cabinet

    Interconnecting tubing (mounted on top of bench) in 402230, 402214 1 ea. Turbo pump controller in bracket with power cord installed (mounted on bench) 402212 1 ea. Power strip (mounted under bench) in 402210 © 2005 - 2007 DH Instruments, a Fluke Company Page 30...

  • Page 43: Table 3. Interconnections Kit Parts List

    Quick connect stem, 1/4 in. NPT F 102117 2 ea. Quick connect stem, AN4 M 102115 1 ea. Adaptor, KF40 x KF16 103650 1 ea. ADCS-601-AF Operation and Maintenance Manual (hard copy) 550140 Page 31 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 44: Platform And Bell Jar

    The piston-cylinder module is shipped in a PVC bullet case packed in a corrugated container with custom foam inserts. The piston-cylinder module accessories are also in the corrugated container. Open the corrugated container and remove the piston-cylinder module and accessories. © 2005 - 2007 DH Instruments, a Fluke Company Page 32...

  • Page 45: Mass Set (Ms-Amh-38)

    123850-03 1 ea. 0.8 kg tubular mass 123850-04 1 ea. 1.6 kg tubular mass 123850-05 1 ea. 3.2 kg tubular mass 123850-07 5 ea. 6.4 kg mass disc 123851 Page 33 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 46: Automated Mass Handler (Amh-38)

    CDG, reference vacuum assembly with valve 402227 1 ea. Cable, CDG connection 402228 1 ea. Piston-cylinder assembly in PVC bullet case 401662 1 ea. Molded transit case (in which the Platform is shipped) 123346 © 2005 - 2007 DH Instruments, a Fluke Company Page 34...

  • Page 47: Fpg8601 Mass Set (Ms-8601-2)

    The FPG8601 mass set is shipped in a black, molded plastic case in a corrugated liner. The FPG8601 mass set is not used in day to day ADCS-601-AF operation (see Section 7.2.5). Table 10 details all items included with the FPG8601 mass set.

  • Page 48: System Controller Stand

    The environment required to operate an ADCS-601-AF Air Data Calibration Standard within its estimated measurement uncertainty limits is generally that of a high level, physical metrology laboratory. When selecting and preparing a site to set up the ADCS-601-AF system, the following should be considered: •...

  • Page 49: Figure 26. Typical Layout Of Overall Adcs-601-Af System At Site Of Use

    3. INSTALLATION Figure 26. Typical layout of overall ADCS-601-AF system at site of use Page 37 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 50: Setup

    Allow a minimum of three hours to complete the process. To set up the ADCS-601-AF system, first unpack it following the instructions in Section 3.1. Then follow the set up instructions in Sections 3.3.1 to 3.3.13 sequentially. Once the system is set up, power it up, initialize it and verify it following the instructions in Section 3.4.

  • Page 51: Install Reference Turbo Vacuum And Roughing Pumps

    (the two scroll vacuum pumps provided are identical, so either one may be used here). Connect turbo pump KF25 connection to roughing pump using KF25 plastic hose. Page 39 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 52: Position The Pg7601 And Fpg8601 Platforms On The Reference Bench

    Connect the FPG8601 power cord (16 AWG) from the FPG8000 Terminal to the power strip underneath the bench. Do not power up the FPG8601. Fill the FPG8601 bubbler bowl with distilled water (see Section 6.2). © 2005 - 2007 DH Instruments, a Fluke Company Page 40...

  • Page 53: Make Pneumatic Interconnections On The Reference Bench

    VACUUM port on the rear of the PG7601 platform. The gland for the DH200M plug is delivered in the TEST port. No collar us used with a plug. Page 41 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 54: Position Control Cabinet And Make Pneumatic, Communications And Electrical Connections To Reference Bench

    Connect the 1/8 in. PFA tube labeled FPG LUB SUP to the LUBRICATION SUPPLY port on the rear of the FPG8601 platform. Connect the 9 pin D-sub cable labeled PG COM1 to the COM1 port on the rear of the PG7601 Platform. © 2005 - 2007 DH Instruments, a Fluke Company Page 42...

  • Page 55: Connect Pressure Supplies To Control Cabinet

    Leave the AMH DRIVE and FPG LUBRICATION regulators set to zero. Check and adjust the other Control Panel regulator settings as necessary. See Section 6.13 for definition of correct settings. Page 43 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 56: Set Up The

    Protective gloves are provided in the accessory kit of the PG7601 Platform. See Section 2.2.1.5 to identify the different elements of the 38 kg mass set. © 2005 - 2007 DH Instruments, a Fluke Company Page 44...

  • Page 57: Install The Amh-38 Mass Handler

    The steps of this procedure are commented on the PG Terminal display as they execute. See Section 6.5 for additional information on installing and removing AMH-38 from the PG7601 Platform. Page 45 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 58: Install The Reference Vacuum Cdg Assembly

    Use a KF40 centering ring and clamp. Install so that the CDG body is in the vertical position. Connect the 15 pin cable labeled PG CDG from the Control Cabinet to the top of the CDG. © 2005 - 2007 DH Instruments, a Fluke Company Page 46...

  • Page 59: Complete Fpg8601 Setup

    The bypass/control manifold is connected to the right side (viewed from the front) of the FPG8601 Platform. The manifold itself was already connected to the FPG8601 (see Section 3.3.4) and the piston-cylinder has already been installed (see Section 3.3.10.1). Page 47 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 60: Install The Reference Vacuum Cdg Assembly

    FPG8601 platform. Connect the 1/8 in. pneumatic line labeled 12 from the CDG isolation valve (valve 12) to the V12 port on the front of the FPG8601. © 2005 - 2007 DH Instruments, a Fluke Company Page 48...

  • Page 61: Complete Reference Vacuum Interconnections

    Connect the USB cable labeled PC USB that comes out of the back of the Control Cabinet to a USB port on the back of the system controller (PC). Page 49 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 62: Power Up, Initialization, Verification

    Then press [ENT] followed by [ESC]. Choose <2yes> in response to the <Save edits> prompt. When <Reply conv coef> is displayed, press [ENT] to accept the value of <1.00 Pa/unit>. © 2005 - 2007 DH Instruments, a Fluke Company Page 50...

  • Page 63: Edit And Select Pg7601 Setup File

    PG7601 3.4.3.1 POWER UP In normal ADCS-601-AF operation, the PG7601 is controlled remotely by ADCS Tools software. For power up and initialization, the PG7601’s PG7000 Terminal keypad and display are used. Turn the PG7601 power ON by pressing the power ON/OFF switch on the rear panel of the PG7000 Terminal.

  • Page 64: Fpg8601

    SETUP file. SETUP files are viewed, created, edited and selected using the SETUP function accessed by pressing [SETUP] on the PG7000 Terminal. ADCS-601-AF systems use SETUP file #2. VERIFY/SELECT AUTOGEN ON Press [AutoGen] on the PG7000 Terminal. AutoGen should be ON.

  • Page 65: Verify System Operation

    PG7601 PPC3 pressure controller to decrease pressure and float its piston, rotate its piston and indicate Ready. - Set a target pressure of 10 kPa (3 inHg). The ADCS-601-AF will transition from the PG7601 to the FPG8601 standard. The FPG8601 pressure controller should descend pressure and set a stable pressure near the target pressure value and indicate Ready.

  • Page 66: Enter Value Of Local Gravity

    ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL - Set a target pressure of 10 kPa (3 inHg). The ADCS-601-AF will transition from the PG7601 to the FPG8601 standard. The FPG8601 pressure controller should descend pressure and set a stable pressure near the target pressure value and indicate Ready.

  • Page 67: Specify Test Gas Species

    SHUT DOWN AND RESTART 3.8.1 RESTART To restart an assembled ADCS-601-AF, follow the steps below. If the ADCS-601-AF has been shut down for an extended period, consider performing the maintenance functions (see Section 6). If they have been disconnected, connect and apply required pressure supplies to the Control Cabinet rear panel (see Section 1.1.1).

  • Page 68: Shut Down

    3.8.2.2 LONG TERM SHUT DOWN If the ADCS-601-AF will not be used for an extended period, or to shut it down completely for disassembly, proceed as follows. Complete the short term shut down (see Section 3.8.2.1). Use the ADCS Tools [FPG] button to display the FPG run screen. In the ADCS Tools FPG Run Screen, press the [Shutdown] (OFF) button.

  • Page 69: O P E R A T I O

    4.1.1 SYSTEM CONFIGURATION The ADCS-601-AF system is completely configured from a hardware and software standpoint when it is delivered. All necessary operating values are entered into individual components and all interfaces are set for internal consistency and to communicate with ADCS Tools software.

  • Page 70: Ready/Not Ready When Using The Fpg8601 Force Balanced Piston Gauge

    TRANSITION BETWEEN STANDARDS, ACTIVE AND INACTIVE STANDARD The ADCS-601-AF system is made up of two automated pressure standards with overlapping ranges to cover the full pressure range. An automated PG7601 piston gauge covers the range of 15 to 380 kPa (4.5 to 120 inHg) (see Section 2.2.1). The PG7601 range is extended down to 1 kPa (0.3 inHg) by an FPG8601 force balanced piston gauge with automated...

  • Page 71: Difference Between Requested And Actual Set Pressure

    The majority of the ADCS-601-AF pressure range (15 kPa (4.5 inHg) and up) is covered by an automated PG7601 piston gauge (see Section 2.2.1). The automated mass handling system of the PG7601 can load mass in steps of 0.1 kg.

  • Page 72: Asolute And Gauge Measurement Modes

    DUT and pressure standards are at a common reference pressure. See Section 4.2.3 for additional information on changing measurement modes. There is a well defined order of operation for transitioning the ADCS-601-AF system between measurement modes. The order is controlled by the ADCS Tools software. Mode transitions should only be performed under ADCS Tools control.

  • Page 73: Connecting A Device Under Test (Dut)

    4.2.2 CHANGING PRESSURE UNIT OF MEASURE ADCS-601-AF supports a variety of pressure units of measure. To change the pressure unit for the ADCS pressure, press the [Unit of Measure] button on the ADCS Run Screen Toolbar (see Section 4.3.5.3) and select the desired unit. When the ADCS pressure unit of...

  • Page 74: Changing Measurement Mode (Absolute, Gauge)

    Execution of certain pressure requests could damage the ADCS-601-AF system if the TEST(+) port is open. If nothing is connected to the TEST(+) port, it must be plugged with the plug quick connect stem provided.

  • Page 75: Setting Zero Pressure

    Many devices require pressure exercising prior to validation or calibration. Generally, their exercising can be performed quickly and without precise knowledge of the endpoint pressures. ADCS-601-AF supports a function to allow simple, rapid exercising of the DUT. The exercise function uses the PG7601’s pressure controller alone rather than the pressure standards.

  • Page 76: Setting A Head Correction

    The reference level of the ADCS-601-AF system is the reference level of the PG7601 piston gauge which is marked on the front of the AMH automated mass handler vacuum chamber.

  • Page 77: Security, User Rights

    4. OPERATION 4.2.8 SECURITY, USER RIGHTS The ADCS Tools program that runs the ADCS-601-AF system includes provisions to protect against undesired editing and changes to program parameters. The protection system is based on user rights. ADCS Tools always has an active user. User access can be password protected. User rights can be managed to prevent a user from being able to make changes in specific areas of ADCS Tools.

  • Page 78: Changing Active User

    4.2.9 PRESSURE LEAK TEST It is good practice to run a leak test on the ADCS-601-AF after performing a setup or maintenance operation that requires pressure fittings to be disconnected. The leak test can quickly determine if the ADCS-601-AF is performing properly. A report detailing the status of the individual portions of the leak test is provided upon test completion.

  • Page 79: Local Operation, Adcs Tools

    4. ADCS Run Screen (see Section 4.3.5): The Run Screen is the main operator interface for actually running the ADCS-601-AF system. It is equivalent to the front panel of an instrument and includes real time ADCS-601-AF displays and controls. The ADCS Run Screen includes the ADCS Control Panel, ADCS System Display and ADCS Run Screen Toolbar.

  • Page 80: Figure 32. Adcs-601-Af Software, Communications And Control Flow Chart

    ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL Figure 32. ADCS-601-AF software, communications and control flow chart Figure 33. ADCS-601-AF program window © 2005 - 2007 DH Instruments, a Fluke Company Page 68...

  • Page 81: Main Menu

    7.3.3, 3.5, View and edit value of local gravity used by PG7601 and FPG8601. View and edit species of test gas used in ADCS-601-AF system. Run FPG Run automated routine to validate FPG8601 with PG7601. 7.2.3...

  • Page 82: Adcs Main Toolbars

    Causes communications between ADCS Tools and system components to Pause pause, suspending most operation. To restart, when paused, press pause again When running a test, suspends test execution and pauses test timers. © 2005 - 2007 DH Instruments, a Fluke Company Page 70...

  • Page 83: Figure 36. Adcs Run Screen

    When a test is running, opens the Data Grid Run Screen. 4.4.3.2 Data Grid Run Screen When a test is running, opens the Data Plot Run Screen. 4.4.3.1 Data Plot Run Screen Page 71 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 84 The output of all manual entry devices must be entered for every data point logged. This minimizes the automation provided by this function. Taking data at short time intervals can quickly result in a very large Data File. © 2005 - 2007 DH Instruments, a Fluke Company Page 72...
  • Page 85 When a test is running, opens the DUT/Reference Comparison Run 4.4.3.3 DUT/Reference Screen. This display provides convenient, real time, error information Comparison Run calculated for each DUT compared to the ADCS-601-AF. Screen When running an automated test, generates a popup menu to allow the 4.4.2 Device Run Screen selection of the desired Device Run Screen to display.

  • Page 86: Adcs Status Bar

    The ADCS Tools ADCS Run Screen should be considered the equivalent of an instrument front panel. It is the front panel of the ADCS-601-AF system. The run screen is the interface through which ADCS functions are controlled and readings are observed (see Figure 36).

  • Page 87: Adcs Run Screen Control Panel

    Table 15. Table 15. ADCS Run Screen Control Panel features LABEL DESCRIPTION Green when the ADCS-601-AF pressure is Ready. Red when the Circular Ready/Not Ready pressure is Not Ready. When the FPG8601 is the active pressure Indicator and Ready timer...

  • Page 88: Adcs System Display

    4.3.5.2 ADCS SYSTEM DISPLAY The ADCS System Display is a simplified operational schematic of the ADCS-601-AF system that provides the operator with real time, quick visual indication of ADCS-601-AF system states (see Figure 37). The schematic represents the FPG8601 and PG7601 pressure standards, their pressure controllers and the measured pressure and reference pressure circuits with valves.

  • Page 89: Table 16. Adcs System Display Symbols

    AMH vacuum chamber area. - Bell jar light blue = ADCS-601-AF is in gauge measurement mdoe; atmospheric pressure is under the bell jar. - Bell jar black = ADCS-601-AF is in absolute measurement mode;...

  • Page 90: Adcs Run Screen Toolbar

    Measure Click any displayed quantity on any ADCS-601-AF run screen to access a popup menu with a choice to change the unit of measure. Transition active pressure standard from PG7601 to FPG8601 or Change Active Pressure vice-versa (see Section 4.1.3).

  • Page 91: Other Device Run Screens

    The PG7601 Run Screen should only be used to view PG7601 status. Use of the Toolbar on this run screen may conflict with other ADCS-601-AF Tools functions. The PG7601 Run Screen Toolbar should only be used for advanced trouble shooting by qualified personnel.

  • Page 92: Fpg8601 Pressure Standard

    The FPG8601 Run Screen should only be used to view FPG8601 status. Use of the Toolbar on this run screen may conflict with other ADCS-601-AF Tools functions. The FPG8601 Run Screen Toolbar should only be used during ADCS-601-AF start up or for advanced trouble shooting by qualified personnel.

  • Page 93: Rpm4 Reference Pressure Monitor

    The RPM4 Run Screen should only be used to view RPM4 status. Use of the Toolbar on this run screen may conflict with other ADCS-601-AF Tools functions. The RPM4 Run Screen Toolbar should only be used for advanced trouble shooting by qualified personnel.

  • Page 94: Automated Testing

    Definition must also be set up (see Section 4.4.1.2). If support devices that are not part of the ADCS-601-AF such as a multimeter or a temperature chamber are needed to run a test, Support Device Definitions must be set up to define them (see Section 4.4.1.3).
  • Page 95 DUT cannot be used as a controller in ADCS Tools. Press the Editor Toolbar, [Save] button to save all changes. Any errors in the setup must be remedied before the DUT Definition can be saved. Page 83 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 96: Setting Up Test Definitions

    ® ADCS Tools uses the engine of COMPASS for Pressure calibration software to manage automated testing using ADCS-601-AF. The Test Editor is a COMPASS for Pressure feature. See the COMPASS for Pressure User’s Manual for complete information on Test Editor.

  • Page 97: Setting Up Support Devices

    ADCS Tools uses the engine of COMPASS for Pressure calibration software to manage automated testing using ADCS-601-AF. The Support Device Editor is a COMPASS for Pressure Device Editor. See the COMPASS for Pressure User’s Manual for complete information on Device Editors and Support Device Definitions.

  • Page 98: Running Automated Tests

    Manual Run Modes Section for complete information on running automated tests. The COMPASS for Pressure manual is an on-line manual available by pressing the [?] button, when available, in COMPASS features. It can also be accessed on the ADCS-601-AF system controller in the COMPASS for Pressure program group reached using the Windows START button , Programs.

  • Page 99: Running A Manual Test

    RUNNING A TEST DEFINITION ADCS Tools uses the engine of COMPASS for Pressure® calibration software to manage automated testing using ADCS-601-AF. The Run Test Definition function supported by ADCS Tools is a COMPASS for Pressure feature. See the COMPASS for Pressure User’s Manual Run Modes Section for complete information on running automated tests.

  • Page 100: Test Run Screens

    - Select Test Definition to be run. By default, the Test Definition specified in the DUT Definition is selected. Double click the desired Test Definition. - After the Test Definition has been selected, most ADCS-601-AF users can press [Finish] to skip remaining initialization steps and go directly to running the test.

  • Page 101: Data Plot Run Screen

    The COMPASS for Pressure manual is an on-line manual available by pressing the [?] button, when available, in COMPASS features. It can also be accessed on the ADCS-601-AF system controller in the COMPASS for Pressure program group reached using the Windows START button , Programs.

  • Page 102: Dut/Reference Comparison Run Screen

    The Reference/DUT Comparison Run Screen is available any time a test is running. The screen vizualizes real time DUT and ADCS-601-AF readings and the error of the DUT(s) compared to the ADCS-601-AF. The information on the display is organized into rows and columns. The columns separate different pieces of information.

  • Page 103: Test Data

    Pressure manual is an on-line manual available by pressing the [?] button, when available, in COMPASS features. It can also be accessed on the ADCS-601-AF system controller in the COMPASS for Pressure program group reached using the Windows START button , Programs.

  • Page 104: Running A Model 3682 Air Data Calibrator

    4.4.6.1 RUNNING A VALIDATION (CALIBRATION) When the ADCS-601-AF is connected to the model 3682 ADC, do not execute any function on the 3682 that will cause it to vent pressure unless the ADCS-601-AF is vented first. Causing pressure on the ADCS-601-AF TEST(+) port to vent when the ADCS-601-AF is not vented, may cause damage to the ADCS-601-AF.
  • Page 105 [Finish]. There are no further initialization steps. The test will complete initialization and start to run. The status bar updates during initialization to display the current system operation. Page 93 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 106 • Press [Advance] • Press [Calibration Manual] • Press [Advance] • Select [Calibration] • Select [PS] or [PT] • Press [Advance] • Select [Dead Weight Tester] • Press [Advance] © 2005 - 2007 DH Instruments, a Fluke Company Page 94...
  • Page 107 Press [OK] to continue. The ADCS-601-AF vents the pressure immediately after [OK] is pressed. It is important that the ADCS-601-AF vent rather than the model 3682 venting the pressure. Page 95 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 108 ADCS Tools as the test excutes through the test pressure points. Use the display buttons on the ADCS Tools Main Toolbox to display other system windows if desired. © 2005 - 2007 DH Instruments, a Fluke Company Page 96...

  • Page 109: Running A Standardization

    4.4.6.2 RUNNING A STANDARDIZATION When the ADCS-601-AF is connected to the model 3682 ADC, do not execute any function on the 3682 that will cause it to vent pressure unless the ADCS-601-AF is vented first. Causing pressure on the ADCS-601-AF TEST(+) port to vent when the ADCS-601-AF is not vented, may cause damage to the ADCS-601-AF.
  • Page 110 Set the ADCS-601-AF to absolute measurement mode using the [MODE] button on the ADCS Tools Main Run Screen. Vent the ADCS-601-AF using the [VENT] button on the ADCS Tools Main Run Screen. Enter the appropriate <Upper Limit> value on the ADCS Run Screen. Enter 32 inHg when calibrating the Ps transducer and 110 inHg when calibrating the Pt transducer.
  • Page 111 [x] in the upper right hand corner of the Run Screen. ADCS Tools sets the test pressure, dwells for 60 seconds, determines the pressure value set by the ADCS-601-AF and prompts the user with a dialog box. Page 99...
  • Page 112 Pressing [ADVANCE] on the model 3682 after the last point causes the 3682 to vent while the ADCS-601-AF is still at a set pressure which can damage the ADCS-601-AF.
  • Page 113 Test] to close the dialog box and return to the ADCS Main Run Screen. On the model 3682, press [ADVANCE] and follow its prompts to complete the standardization process. Page 101 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 114 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page 102...
  • Page 115 The overall ADCS-601-AF system is controlled by a Windows based personal computer running ADCS Tools software. Interfacing between a host computer and the ADCS-601-AF system computer is not available at the time of publication of this manual. Individual ADCS-601-AF components such as the PG7601 and the PPC3 pressure controllers can be addressed individually on their RS232 and/or IEEE-488 interfaces, but this is not a normal part of ADCS- 601-AF operation.
  • Page 116 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page 104...

  • Page 117: Summary

    Use to reduce PG7601 controllers difference between requested pressure pressure controllers to agree with their and final pressure when using FPG8601 pressure reference (PG7601 or PFG8601). pressure reference. Page 105 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 118: Fpg8601, Check Bubbler And Add Water If Necessary

    To check the bubbler level proceed as follows: Go to the back of the ADCS-601-AF Reference Bench to observe the back of the FPG8601 Platform (see Figure 45). Observe the water level in the bubbler (clear plastic reservoir on the right side looking at the FPG8601 from the rear).

  • Page 119: Fpg8601, Remove Clean And Reinstall The Piston-Cylinder

    6. GENERAL MAINTENANCE AND ADJUSTMENTS To refill the FPG8601 bubbler proceed as follows: Prepare the ADCS-601-AF system for access to the bubbler: Set gauge measurement mode using the [MODE] button on the ADCS Run Screen Toolbar (see Section 4.3.5.3). Wait for the process to complete.

  • Page 120: Figure 46. Fpg8601 Piston-Cylinder Assembly In Mounting Post

    1. Upper mounting post Gimbal ring 2. Piston retaining nut 5. Cylinder 3. Indexing block with 3 mm indexing pin 6. Piston Figure 46. FPG8601 piston-cylinder assembly in mounting post © 2005 - 2007 DH Instruments, a Fluke Company Page 108...

  • Page 121: Removing The Piston-Cylinder From The Mounting Post

    Great care must be taken when removing the assembly. Permanent damage can occur if the recommended steps are not specifically followed. Prepare the ADCS-601-AF system for access to the piston-cylinder: Set gauge measurement mode by pressing the [MEASUREMENT MODE] button on the ADCS Run Screen Toolbar and selecting <gauge>...

  • Page 122: Figure 47. Removing The Fpg8601 Mounting Post

    Remove one of the piston retaining nuts. Figure 48. Removing the FPG8601 piston-cylinder With one hand supporting the piston to maintain its current position, slowly remove the remaining piston retaining nut. © 2005 - 2007 DH Instruments, a Fluke Company Page 110...

  • Page 123: Removing The Piston From The Cylinder

    FPG8601 piston insertion tool. Slide the cup containing the cylinder up and off the spindle. Remove the cylinder from the cup. Page 111 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 124: Cleaning The Piston And Cylinder

    The cleaning process is complete and the piston can now be put back into the cylinder. The instructions in Section 6.3.5 must be followed to safely put the piston in the cylinder. © 2005 - 2007 DH Instruments, a Fluke Company Page 112...

  • Page 125: Putting The Piston Into The Cylinder

    Slide the cup and cylinder all the way down the insertion tool spindle. Page 113 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 126: Installing The Piston-Cylinder In The Mounting Post

    (where the piston retaining pins will go). Insert one piston retaining pin and thread it half way in. Insert the remaining piston retaining pin so that it is tight. © 2005 - 2007 DH Instruments, a Fluke Company Page 114...

  • Page 127: Restoring Piston-Cylinder Lubrication And Mobility

    These procedures are used with the piston-clinder installed in the mounting post but with the lower mounting post removed so that the piston-cylinder can be Page 115 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 128 Lighly “strum” the bearing to cause a small amount of movement and let the ring return naturally. The movement is very limited. Do not force it. © 2005 - 2007 DH Instruments, a Fluke Company Page 116...

  • Page 129: Disassemble Platform And Remove Mounting Post Prt

    Table 19. PG7601 mounting post wire colors, description and location WIRE COLORS DESCRIPTION AND LOCATION Black/Yellow/White RPM (P4) Black/Black/Black/Black Vacuum Sensor (center raised micro board) White/White/Yellow/Yellow Mounting Post PRT (P2) Purple/Blue/Red Motor Solenoid (J2) Gray/Orange/Green/Brown LVDT (P1) Page 117 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 130: Remove And Reinstall The Automated Mass Handler And Mass Set

    To remove the AMH-38 mass handler from the PG7601 Platform, proceed as follows (see Figure 50). Prepare the ADCS-601-AF system for local operation of PG7601 and access to the mass set: Put the ADCS-601-AF system into gauge measurement mode (see Section 4.2.3).

  • Page 131: Figure 50. Amh Installation On Pg7000 Platform

    PG7000 Platform (see Figure 50). Page 119 © 2005 - 2007 DH Instruments, a Fluke Company...
  • Page 132 Reinstall the reference vacuum DCG assembly: If the CDG assembly has been removed, reinstall it at the KF40 connection on the AMH vacuum chamber. Resume normal ADCS-601-AF operation: Press [ESC] on the PG7601 until its main run screen appears. Press [PAUSE] on the ADCS Main Tool Bar (see Section 4.3.3) to resume normal ADCS-601-AF system operation.

  • Page 133: The Mass Set

    The mass loading process is complete: The mass set is in the all loaded position. The mass lifting shaft/trim mass tray assembly is not yet installed. It will be attached after the AMH automated mass handler is installed over the masses on the platform. Page 121 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 134: Remove, Clean And Reinstall The Piston-Cylinder Module

    Sections 6.6.1 to 6.6.3.4. 6.6.1 REMOVING THE PISTON-CYLINDER MODULE To remove the piston-cylinder module, remove the AMH automated mass handler and mass set from the PG7601 Platform (see Section 6.5). © 2005 - 2007 DH Instruments, a Fluke Company Page 122...

  • Page 135: Installing The Piston-Cylinder Module

    Low torque rotation by hand is all that should be required to fully seat the piston-cylinder module into the PG7601 mounting post. Never force the piston-cylinder module into the mounting post. Page 123 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 136: Disassembling The Module And Cleaning The Piston-Cylinder Assembly

    NEVER touch the lapped surfaces (polished appearance) of the piston or cylinder with your bare hands. Body oils and acids can permanently etch the surfaces. © 2005 - 2007 DH Instruments, a Fluke Company Page 124...

  • Page 137: Figure 53. 10 Kpa/Kg Gas Piston-Cylinder Module, Expanded View

    Remove the O-ring assembly (8). Then, being sure to support the cylinder (7) so it doesn’t fall out, turn over the remaining assembly so that the piston cap (2) is up. Page 125 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 138: Figure 54. 10 Kpa/Kg Piston Insertion Tool

    ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL Figure 54. 10 kPa/kg Figure 55. 10 kPa/kg gas piston-cylinder piston insertion tool module sleeve nut tool © 2005 - 2007 DH Instruments, a Fluke Company Page 126...

  • Page 139: Lubricating The Piston-Cylinder Module

    Pistons and cylinders should be kept free from vacuum grease and any other contaminant. Vacuum grease or other contaminants on the piston or cylinder will adversely affect the piston-cylinder module’s performance. Page 127 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 140: Cleaning The Piston-Cylinder

    Of the two cleaning methods, the water/detergent method is more time consuming but it is also more thorough. Disassemble the piston-cylinder module following the instructions given in Section 6.6.3.2. © 2005 - 2007 DH Instruments, a Fluke Company Page 128...
  • Page 141 Using a separate, clean, lint free towel, wipe the surfaces again to remove any remaining moisture. Do not vigorously buff the surfaces. Reassemble the piston-cylinder assembly in reverse order. Page 129 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 142: Piston Position Detection Adjustment

    To automatically adjust the PG7601 piston position indication system, proceed as follows: Prepare the ADCS-601-AF system for local operation of individual components: Vent the ADCS-601-AF system by pressing the [VENT] button on the ADCS Run Screen. Wait for the operation to complete.

  • Page 143: Replace Piston Rotation Drive Belts

    PG7601 internal Piranni gauge should be adjusted occasionally to agree with the CDG to assure proper operation of the CDG isolation valve opening and closing routine. ADCS Tools supports automated adjustment of the Piranni gauge. Page 131 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 144: Fpg8601, Adjust Ppc3 Pressure Controllers

    TEST(+) port. Before running the adjustment routine, be sure any device connected to the TEST(+) port that will not be able to handle a pressure in the ADCS-601-AF range. If nothing is connected to the TEST(+) port is should be plugged with the plug provided.

  • Page 145: Control Cabinet, Interrupting Pressure Supply To The Test Gas Supply Port

    6.12 CONTROL CABINET, DRAIN DRIVE AIR TRAPS The ADCS-601-AF Control Cabinet contains two traps to clean the drive air that is supplied to the ADCS-601-AF system (see Figure 10). These should be emptied regularly. The traps can be emptied without removing pressure. To empty the traps proceed as follows.
  • Page 146 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page 134...

  • Page 147: Principles Of Adcs-601-Af Traceability Maintenance

    (see Section 2.2.2). In the air data range of 1 to 15 kPa (0.3 to 4.5 inHg) that is covered by the FPG8601 in the ADCS-601-AF system, the typical pressure measurement uncertainty of the FPG8601 (see the most recent revision of DHI Technical Note 2090TN05) is much lower than is required to maintain an adequate uncertainty ratio with modern Air Data Test Sets (ADTS).

  • Page 148: Fpg8601, Zero And Adjust Span Of Load Cell

    ADJUSTMENT ACDS Tools can be set to zero and adjust the span of the FPG8601 load cell automatically as part of regular ADCS-601-AF operation. This is the default setting and recommended procedure. ADCS Tools, [Maintenance], [FPG Cal Options] provides options concerning when the FPG8601 load cell should be zeroed and spanned automatically.

  • Page 149: Operator Initiated Load Cell Zero And Span Adjustment

    OPERATOR INITIATED LOAD CELL ZERO AND SPAN ADJUSTMENT The ADCS-601-AF operator can initiate an FPG8601 load cell zeroing and/or span adjustment process. To avoid intefering with ADCS-601-AF operation, this should be done when the FPG8601 is NOT the active pressure standard (see Section 4.1.3).

  • Page 150: Running Validation

    20 to 30 minutes using the default validation setup): Prepare the ADCS-601-AF: Vent the ADCS-601-AF system by pressing the [VENT] button on the ADCS Run Screen Toolbar. Wait for the operation to complete. Disconnect any device that is connected to the TEST(+) port at the port and plug the port using the plug quick connector stem provided.
  • Page 151 PG7601 pressure standard (see Section 7.2.3.1). <FAIL> indicates that the FPG8601 pressure standard may be out of tolerance or there is a problem with another component of the ADCS-601-AF system. Troublshooting should be performed to determine the cause of the failure and correct it (see Section 7.2.3.1).

  • Page 152: Figure 59. Adcs Tools Fpg Validation Setup Form

    [Re-Run Validation] re-runs the validation test immediately. [Exit] closes the FPG Validation Results Form. Figure 59. ADCS Tools FPG Validation Setup Form Figure 60. ADCS Tools FPG Validation Results Form © 2005 - 2007 DH Instruments, a Fluke Company Page 140...

  • Page 153: Viewing Fpg Validation Data

    In normal operation, the only adjustments to the load cell that are necessary to maintain in tolerance measurements is to zero and span it which can be performed automatically by the ADCS-601-AF system (see Sections 2.2.2, 7.2.2).

  • Page 154: Linearity Verification Procedure

    One is to perform a best fit, linear regression of the true mass load and load cell output data and compare the residuals to the linearity tolerance. A simplified method follows: © 2005 - 2007 DH Instruments, a Fluke Company Page 142...

  • Page 155: Fpg8601 And Pg7601, Zero Reference Vacuum Cdgs

    The CDGs are known to often have significant zero drift that is easily corrected by zeroing their output at a very low vacuum. The CDGs cannot be zeroed properly in the normal operating position but the ADCS-601-AF includes facilities to easily zero the CDGs on the system. This avoids requiring separate vacuum facilities and offers the convenience of not needing to disconnect the CDGs electrically.
  • Page 156 When the ADCS-601-AF system is powered, the CDGs are powered. In ADCS Tools press [Maintenance], [Run CDG Zero]. A message instructing you to set up the ADCS-601-AF hardware is presented. Set up the hardware following steps through . Setup the ADCS-601-AF vacuum manifold for CDG zeroing.
  • Page 157 Reassemble the KF40 cross for normal ADCS-601-AF operation following steps through above in reverse order. Put the ADCS-601-AF in absolute measurement mode (see Section 4.2.3) and verify that the vacuum reference pressure pulls down as expected. Page 145 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 158: Adjust On-Board P, T, H Sensors

    Corrected output, measured output and adder are in the current unit of measure of the sensor • Multiplier is dimensionless • Normally, it is sufficient to offset the sensor’s output relative to the reference using the adder only. © 2005 - 2007 DH Instruments, a Fluke Company Page 146...

  • Page 159: Recalibration

    RECALIBRATION 7.3.1 OVERVIEW To assure that the ADCS-601-AF operates within pressure measurement uncertainty limits, certain metrology maintenance functions are required. See Section 7.2 for instructions on these procedures. In addition to the metrology maintenance functions, to assure that the pressure values set and measured by the ADCS-601-AF remain within predicted measurement uncertainty levels over time, regular recalibration of certain components is required.

  • Page 160: Calibration Of Piston-Cylinder Module

    These values may change from calibration to calibration and the new values must be entered into the ADCS-601-AF system so that they are used in its pressure calculations. The characteristics of a piston-cylinder include many other values but these are constant over time.

  • Page 161: Pg7601, Calibration Of Mass Set

    Piston gauge mass sets are often calibrated in a facility other than that in which the ADCS-601-AF system is used so calibrating the mass set requires removing it from the PG7601 Platform and shipping it. If the mass set and the piston- cylinder module are to be calibrated by the same facility, they are usually shipped together, with the PG7601 Platform if necessary.

  • Page 162: Updating Mass Set Calibration Information

    The calibration report lists a value measured by the calibration facility for each mass. These values may change from calibration to calibration and the new values must be entered into the ADCS-601-AF system so that they are used in its pressure calculations. For additional information on PG7601’s AMH-38 mass set characteristics and how they are stored in the PG7601 platform, see the PG7000 Operation and Maintenance Manual.

  • Page 163: Calibration Of Piston-Cylinder Module Temperature Sensor

    It is possible to remove the PRT from the mounting post if necessary. To remove the PRT from the PG7601 mounting post, follow the instructions provided in Section 6.3.7. Page 151 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 164: Procedure

    Calculate the new PRT offset as follows: Using the data obtained in the comparison process described in Section 7.3.4.3, average the readings of the PG7601 PRT and average the readings of the reference temperature probe. © 2005 - 2007 DH Instruments, a Fluke Company Page 152...
  • Page 165 The offset value of the piston-cylinder mounting post platinum resistance thermometer may change from calibration to calibration. The new offset value determined above must be entered into the ADCS-601-AF system so that it is used in its calculations. For additional information on PG7601 characteristics and how they are stored in the PG7601 platform, see the PG7000 Operation and Maintenance Manual.

  • Page 166: Pg7601, Calibration Of Reference Vacuum Cdg

    To be calibrated, the CDG and its power supply and readout must be removed from the ADCS-601-AF system. See Section 7.3.5.2 for instructions on removing the PG7601 CDG assembly and readout. The CDG and its power supply/readout are completely autonomous elements whose calibration is independent of ADCS-601-AF.
  • Page 167 Prepare the ADCS-601-AF for removal of the CDG: Vent the ADCS-601-AF system by pressing the [VENT] button on the ADCS Run Screen (see Section 4.2.3). Wait for the operation to complete. Put the system into gauge mode by pressing the [MODE] button on the ADCS Run Screen.
  • Page 168 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page 156...

  • Page 169: Overview

    ADCS-601-AF operation. This troubleshooting guide is intended as an aid in identifying the cause of unexpected ADCS-601-AF behavior and determining whether the behavior is due to normal operation or an internal or external problem.
  • Page 170 Operation and the controller is beeping. Maintenance Manual Automated pressure generation is The test volume is too large. Reduce the test volume extremely slow or never floats the pistons. © 2005 - 2007 DH Instruments, a Fluke Company Page 158...

  • Page 171: A P P E N D I

    4.021732 E-03 inWa @ 60°F inch of water 4.018429 E-03 inHg @ 0°C inch of mercury 2.953 E-04 kilogram force per centimeter square 1.019716 E-05 user User User defined coefficient Page 159 © 2005 - 2007 DH Instruments, a Fluke Company...

  • Page 172: Glossary

    (pressure relative to vacuum). MS (Mass Set) A group of masses used on the PG7601 piston gauge. In ADCS-601-AF the mass set is a an AMH-38 mass set with a nominal total mass of 38 kg.

  • Page 173: Warranty Statement

    9. 12BAPPENDIX WARRANTY STATEMENT Except to the extent limited or otherwise provided herein, DH Instruments, a Fluke Company (DHI) warrants for one year from purchase, (5 years for ADCS-601-AF systems purchased under AFMETCAL Contract FY2333-04-M-0021, as labeled on the instrument rear panel) each new product sold by it or one of its authorized distributors, only against defects in workmanship and/or materials under normal service and use.
  • Page 174 ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL © 2005 - 2007 DH Instruments, a Fluke Company Page 162...

Table of Contents
