Fishman PREFIX PRO Manual page 7

A
C O U S T I C
SPECIFICATIONS
Nominal Input Level:
Input Overload:
Input Impedance:
Output Impedance:
Nominal Output Level:
THD:
Signal to Noise Ratio:
Current Drain:
Power Supply:
Notch Filter Range:
Bass Control Range:
Treble Control Range:
Mid Control Range:
Brilliance Control Range:
All specifications subject to change without notice.
G
U I T A R
-20 dBV
(20 Hz - 20 kHz) +2 dBV
20 M Ohms
Less than 3.5 k Ohms
-12 dBV
Less than .04 %, -20 dBV input
77 dB
(A weighted referred to nominal
-20 dBV input)
Less than 3.5 mA
9V Alkaline battery
(estimated 160 hours continuous use with
low battery indicator at 6.5V)
40Hz - 500 Hz (-15 dB)
± 12 dB at 60 Hz
± 3 dB at 350 Hz
± 12 dB at 10 kHz
± 3 dB at 2.4 kHz
± 12 dB at 1 kHz
± 3 dB Bandwidth 1.1 kHz
± 12 dB at 10 kHz
± 3 dB Bandwidth 7 kHz
S
Y S T E M
PREFIX
PREFIX
PRO
PRO
TM
7
