FILTER INSTALLATION
Insert the filter element
from the bottom of the
shower head.
Each layer is arranged according to the characteris-
tics of the filter media to maximize filtration efficiency.
Each of our cartridges has been tested to treat 1530 gallons of water, and according to EPA
!
estimates, the average amount of water used per shower is about 17 gallons. Please replace the
cartridge according to the number of members in your family and your personal showering habits.
Handheld Shower Head with Filter
Then connect to the hose
and shower head.
WHAT'S IN THE PACKAGE.
Handheld
Showe Head x1
15 Inch Slide Bar
& Shower Head
Filter x1
Only use Teflon tape on the threads of
the shower pipe if there is a leak. Do
Teflon Tape x1
Spare washers are used for water leaks
at connections due to missing washers.
Spare Gasket x1
High Density Stainless Steel Screen
-Filtering of large molecule impurities.
Amino Acids
- Scale inhibitor, Improves skin texture and repairs
damaged hair.
Activated Carbon
-Adsorption of organic pollutants, dechlorination, cleans
odor.
KDF
-Removes residual chlorine and chlorination by-products,
inhibiting the growth of bacteria and microorganisms.
Zeolite
-Adsorbs heavy metals and harmful substances and
reduces the turbidity of the water.
Anti-siphon device
-Prevents water from being sucked backward into the
home plumbing.
60 Inch Hose x1
Bracket
not use it on any other connections.
Use only one per connection.
L-valve x1
Bar Holder
Advertisement
Related Manuals for Veken SHF5V103
Summary of Contents for Veken SHF5V103
- Page 1 Handheld Shower Head with Filter WHAT'S IN THE PACKAGE. L-valve x1 Handheld 60 Inch Hose x1 Showe Head x1 15 Inch Slide Bar & Shower Head Bar Holder Filter x1 Bracket Only use Teflon tape on the threads of the shower pipe if there is a leak. Do not use it on any other connections.
- Page 2 SHOWER HEAD INSTALLATION To protect the surface from scratches, wrap a cloth around the product during installation. 1. Twist the old shower head counterclockwise to remove it. 2. Attach the L-valve to the shower pipe. Note the mounting Clean the threads of the shower pipe. direction as shown.
- Page 3 HOW TO USE? 1. Spot Cleaning Point Storm Rain Massage 2. Sector Cleaning Soft Rain Massage Mist Six Shower Settings 3. Pause A.Shower Function Switch Handle C. Power Wash Switch Button Switch modes by pushing the handle Push the button up and down to switch to rotate the panel.
- Page 4 PROBLEM CAUSE SOLUTION 1. If it is the first cause, just dry the wall and let the patch 1.Bar Holder does not stick 1. If it is the first problem, please make dry naturally before re-sticking it on the wall. tightly.
