Powermix™
Piezo / Magnetic Outboard Mixing Preamp
Other Features Include ...
•
3-band EQ and Phase switch
for the Powerbridge™ Pickup signal
•
TRS and split stereo inputs
•
Battery or AC power
NOTE: For even more flexibility
with the Powermix™, install the
5 M passive volume pot included
with your Powerbridge™.
This simple and compact
stompbox-style preamp
dedicated to combining Piezo
and magnetic signals.
With the Powermix™ you can
blend the Powerbridge™ with
your magnetic pickups while
keeping modifications to your
guitar at a minimum. There is a
TRS (Tip/Ring/Sleeve) input jack
for use with Stereo Instrument
Cables, as well as a direct Piezo
input.
Sixteen
Powermix™ Applications
is
TM
You can use a Stereo Instrument Cable to plug both Piezo and magnetic pickups
into the Powermix™ and send the combined signal to a single amplifier
- without any modification to your instrument.
Stereo
Instrument
Cable
Seventeen
