Fishman POWERBRIDGE SYSTEM Manual page 11

Powerblend™ Applications Powerblend™ Applications
Acoustic Guitar Amp
Electric Guitar Amp
Mono Instrument
Cable from
1/4" Piezo Out
Electric Guitar Amp
Mono Instrument
Cable from
Stereo
Mix Out
Instrument Cable
Stereo
(Piezo / Magnetic
to Stereo Input
Instrument Cable
Signal)
to Stereo Input
Mono Instrument
Cable from
Mag Thru
(Pure Magnetic
Signal)
Combined Powerbridge™ and magnetic signals can be sent through a
The mags can be sent to an electric guitar amp, with the Powerbridge™ mono cable to a single electric guitar amp.
(or acoustic)
sent to an acoustic guitar amp. The Powerblend's™
(or electric) Use the 1/4" Mix Out to combine Piezo and mag signals - the foot pedal
1/4" Piezo Output matches the Powerblend™ with any stage amp.
controls the Powerbridge™ Pickup volume.
Twenty Two Twenty Three
