HYDROCLEAN
INSTALLATION INSTRUCTIONS
VISIT OUR WEBSITE: WWW.NEXTBYDANCO.COM
to view an installation video, and get plumber's tips,
frequently asked questions and trouble shooting advice.
Refill
Tube
Clip
Flexible tubing may need
to be cut to fit all tanks
Limited Warranty
This Next by Danco product is warranted to be free from defective
materials and workmanship for the period of one (1) year after
initial installation unless otherwise specified in writing. Defective
units returned to Next by Danco will be replaced without charge.
This warranty applies only to the original purchase and installation
of Next by Danco products.
Subject to the "Exclusions" set forth below, Next by Danco
promises to the consumer to repair, or at the option of Next
by Danco to replace any part of this plumbing product which
proves to be defective in workmanship or materials under
normal use from the date of purchase. All costs of removal,
transportation and reinstallation to obtain warranty service shall
be paid by the consumer. During this Warranty, Next by Danco
will provide subject to the "Exclusions" section set forth below,
all replacement parts free of charge, necessary to correct such
defects.
EXCLUSIONS: THIS WARRANTY SHALL BE VOID IF THE PRODUCT
HAS BEEN MOVED FROM ITS INITIAL PLACE OF INSTALLATION;
IF IT IS HAS BEEN SUBJECTED TO FAULTY MAINTENANCE,
ABUSE, MISUSE, ACCIDENT, OR OTHER DAMAGES; IF IT WAS
NOT INSTALLED IN ACCORDANCE WITH NEXT BY DANCO'S
INSTRUCTIONS; OR IF IT HAS BEEN MODIFIED IN A MANNER
INCONSISTENT WITH THE PRODUCT AS SHIPPED BY NEXT BY
DANCO. NEXT BY DANCO SHALL NOT BE RESPONSIBLE OR
LIABLE FOR ANY DAMAGES CAUSED BY PRODUCTS THAT WERE
NOT MANUFACTURED NEXT BY DANCO OR DAMAGES CAUSED
BY IMPROPER INSTALLATION.
NEXT BY DANCO'S OPTION TO REPAIR, EXCHANGE, OR PROVIDE
A REFUND FOR THE PRODUCT UNDER THIS WARRANTY DOES
NOT COVER ANY LABOR OR OTHER COSTS OF REMOVAL OR
INSTALLATION. NEXT BY DANCO SHALL NOT BE RESPONSIBLE
FOR AND DISCLAIMS ANY LIABILITY FOR SUCH COSTS OR
FOR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES,
INCLUDING WITHOUT LIMITATION COSTS OF INSTALLATION,
WATER DAMAGE, PERSONAL INJURY, ATTRIBUTABLE TO
A PRODUCT DEFECT OR TO THE REPAIR, EXCHANGE, OR
REFUND OF A DEFECTIVE PRODUCT, ALL OF WHICH ARE
EXPRESSLY EXCLUDED FROM THIS WARRANTY. IMPLIED
WARRANTIES, INCLUDING THAT OF MERCHANTABILITY OR
FITNESS FOR PURPOSE INTENDED ARE EXPRESSLY LIMITED
TO THE DURATION OF THIS WARRANTY. (SOME STATES OR
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF IMPLIED WARRANTIES, SO THIS EXCLUSION OR LIMITATION
MAY NOT APPLY.)
DO NOT USE IN-TANK TOILET BOWL CLEANERS CONTAINING
BLEACH, CHLORINE, ALCOHOL OR OTHER ORGANIC SOLVENTS.
USE OF SUCH PRODUCTS WILL RESULT IN DAMAGE TO TANK
COMPONENTS AND MAY CAUSE FLOODING AND PROPERTY
DAMAGE. USE OF SUCH PRODUCTS WILL VOID THIS WARRANTY.
This warranty gives you specific legal rights. You may have other
statutory rights that vary from state to state or from province
to province, in which case this warranty does not affect such
statutory rights.
OPTIONAL/IF APPLICABLE
This warranty does not apply to local building code compliance.
Since local code requirements vary greatly throughout the
country, Distributors, Authorized Service Representatives, Dealers,
Installation Contractors, and users of plumbing products should
determine whether there are any code restrictions applicable in
any way to the product to insure local code compliance before
installation. Next by Danco makes no representation or warranty
regarding, and shall not be responsible for, any code compliance
HC 660 E/S 02/2015
Thumb Screw
Float Lock™
Refill Tube Port
Mini-Valve
®
Fill Valve Float
Upper Valve Body
Positive Locking
Mechanism
J-Tube Connection
Rubber Washer
Smart Nut
®
J-Tube Sliding
Elbow
1
OFF
Mounting Arms
2
Cut collar for plastic flush valve
3
®
There are no special skills required to install this product.
If water line or toilet appear to be leaking after installation,
you should call a plumber immediately.
NOTE: Save Instructions For Future Use
PLUMBER'S TIP:
To check for a leaky flapper, slide the
Float Lock to the off position after the tank
is full of water. Do not use the toilet for 1 hour.
After the hour, recheck the water level
inside the tank. If the water level has dropped,
there is a problem with the flapper's seal.
PLUMBER'S TIP:
Whenever the main water supply to the building
is turned off, debris can get into faucets,
aerators and toilet fill valves when the water is
turned back on. To prevent this problem,
engage HydroClean's patented Float Lock and
run the bath tub until the water is clear,
then disengage the Float Lock to fill the tank.
WARNING
DO NOT USE IN-TANK DROP-IN TOILET
BOWL CLEANERS. Use of such products will
RESULT IN DAMAGE to tank components and MAY
CAUSE FLOODING and PROPERTY DAMAGE and
VOID WARRANTY.
DO NOT over tighten nuts or tank/bowl may crack.
Flapper Installation
OR
4
ON
OR
If you have installed the HydroClean fill valve,
there's no need to turn off the water at the supply.
Simply, engage the Float Lock and flush the toilet.
2
DO NOT cut collar for brass flush valve
OR
Disengage the
Float Lock
