- Page 1 F500S RANGE FYNE ADVICE ESSENTIAL INFORMATION GUIDE...
- Page 3 TABLE OF CONTENTS Introduction Safety Accessories Kit Spike Fitting Positioning Connecting Speaker Cables Grilles Presence Control Running in Cabinet Care Warranty Specifications...
- Page 4 1 INTRODUCTION Thank you for choosing Fyne Audio loudspeakers, proudly designed by our experienced team of engineers in Scotland, and constructed to the highest standards. We believe they will give you many years of listening pleasure. Before installing these loudspeakers, please read this manual in full, both for safety reasons and to ensure you achieve the best performance possible.
- Page 5 4 SPIKE FITTING (F501S, F502S) Thread the 4 spikes and adjustment thumb wheels to the inserts in the plinths of each loudspeaker. The spikes can be adjusted to level the loudspeaker, once level lock in place with the thumb wheels (Fig. 1). On wooden or other delicate floors, use the cups provided to prevent damage to the surface.
- Page 6 F500S LCR: This loudspeaker is designed for either wall When wall mounting, mark the wall mounting positions mounting or free standing in either stereo, LCR or rear using the template provided. channel applications (Fig. 3). When free standing, attach the 4 self-adhesive feet to avoid damaging the surface. Refer to SAFETY WARNING SECTION 2.
- Page 7 6 CONNECTING SPEAKER CABLES Your dealer will be able to advise on the most suitable F500S LCR: This model is provided with a single set of speaker terminals and should be wired according to Fig. 4. choice of cables for your budget and system, to obtain the best performance.
- Page 8 7 GRILLES Although the magnetically attached grilles are designed for maximum transparency, we always recommend removal for the best possible sound quality. With the F501S and F502S models, the grille may be magnetically fixed to the rear of the loudspeaker for neatness and to avoid damage.
- Page 9 +4 dB 8 PRESENCE CONTROL +2 dB 0 dB The F5S, F500S, F501S and F502S models are provided with a ‘Presence’ control switch which only affects the lower treble -2 dB region of 2.5 - 5.0kHz, and influences articulation and vocal clarity, also having an effect on image depth (Fig. 9). -4 dB 100 Hz 1 kHz...
- Page 10 6. If you suspect a problem with a Fyne Audio Limited product, in the first instance, discuss it with your Fyne Audio Limited dealer. If you require further assistance, then we ask that you deal directly with your local Fyne Audio Limited distributor. If you cannot locate your distributor please contact Fyne Audio Limited Customer Services, via our website listed above or at the e-mail enquiries@fyneaudio.com...
- Page 11 12 SPECIFICATIONS Model F500S F501S F502S System type 2 way, downwards firing 2 way, downwards firing 2 ½ way, downwards firing 2 ½ way, downwards firing port, with Tractrix port, with Tractrix port with Tractrix port with Tractrix (BassTrax ) diffuser* (BassTrax ) diffuser* (BassTrax...
- Page 12 12 SPECIFICATIONS Model F500S LCR System type 2 ½ way, with auxiliary bass radiator (ABR) Recommended amplifier 30 - 150 power (Watt RMS) Continuous power handling (Watt RMS) Sensitivity (2.83 Volt @ 1m) 90dB Nominal impedance 8 Ohm 56Hz – 34kHz Frequency response (-6dB typical in room) Drive unit complement...
- Page 13 NOTES...
- Page 14 ENJOY...
- Page 16 Thank you for choosing Fyne Audio loudspeakers, proudly designed by our experienced team of engineers in Scotland, and constructed to the highest standards. WWW.FYNEAUDIO.COM FYNEAUDIO @FyneAudio 24 April 2025...
