10' OFFSET CANTILEVER UMBRELLA
Review all assembly and care information before using this product. Save this manual for future reference.
WARNING:
Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
JCU-6001/10
Purchase Date:
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell. Replacement
parts or products can be requested within the 1-year warranty period. Proof of purchase must be provided. This
includes the date of the purchase as well as photos of the product defect. Photos are used to determine the cause of
the defect and to provide future quality control. The request will be reviewed, and replacement pieces will be sent at
our discretion. For warranty information, visit
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
customerservice@sunnydazedecor.com, or via our contact us page at
Assemble components on a soft, clean surface to avoid damaging the finish.
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Save the packing slip.
SCAN THIS CODE
WITH YOUR
SMARTPHONE
TO VIEW OUR
ASSEMBLY VIDEO
/
/
Order/Customer Reference Number:
https://tiny.cc/SunnydazeWarranty
CHOKING HAZARD — This item contains small parts
that can be swallowed. Keep children and pets away
during assembly.
09/2024
https://tiny.cc/SunnydazeContact
Parts
Top Crossbar
Bottom Crossbar
Pole Support
Umbrella
Threaded Knob
Bolt
Washer
Included Tools
Spanner
WARNING
Qty.
1
1
1
1
2
4
4
Page 1 / 6
Advertisement
Table of Contents
Related Manuals for Sunnydaze Decor JLP-187
Summary of Contents for Sunnydaze Decor JLP-187
- Page 1 Order/Customer Reference Number: Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell. Replacement parts or products can be requested within the 1-year warranty period. Proof of purchase must be provided. This includes the date of the purchase as well as photos of the product defect.
-
Page 2: Before You Begin
BEFORE YOU BEGIN • This offset umbrella requires the use of four cantilever offset patio umbrella base weights or similar items, such as paving slabs or sand bags, for stability. Minimum total weight required: 120 lbs (54.4 kg) • Read and understand this manual before assembling and using this product. •... - Page 3 ASSEMBLY STEP 1 STEP 2 Attach the pole support to the crossbars using the washers and bolts, as shown. Place the top crossbar onto the bottom crossbar. STEP 3 STEP 4 Insert the umbrella into the assembled base. Screw the threaded knobs into the pole support.
-
Page 4: How To Open
HOW TO OPEN IMPORTANT: Weigh down the umbrella base before opening the canopy. If the base is not weighted down, the unit will tip over. We recommend using a 4-piece cantilever offset patio umbrella base weight set (sold separately). 1. Flip the handle upwards and gently lift the curved bar upwards to extend the canopy outward. - Page 5 HOW TO CLOSE Turn the crank until the canopy is fully collapsed. Base weight set not included. Use the built-in strap to secure the umbrella to the center pole. 1. Slide the arm sleeve upward. 2. Gently pull the curved pole downward until the umbrella is parallel with the center pole.
-
Page 6: Cleaning And Maintenance
Cleaning & Maintenance HAND-WASH ONLY O NOT USE BLEACH O NOT USE A PRESSURE WASHER BASIC CARE When opening, make sure the umbrella opens freely. If there is resistance while opening, DO NOT FORCE THE UMBRELLA OPEN as doing so may damage the umbrella. Check to see if the umbrella ribs are locked together; gently pull the ribs apart to assist the opening process. - Page 7 Order/Customer Reference Number: Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell. Replacement parts or products can be requested within the 1-year warranty period. Proof of purchase must be provided. This includes the date of the purchase as well as photos of the product defect.
