- Page 1 WALT Trak-It C6 DGN845D1 - DGN845B Maintenance...
- Page 2 Contents Safe Handling .......................... 3 General Safety Rules ......................3 Protective Equipment ....................... 3 Cautions for Fuel Cells......................3 Handle fuel cell carefully and check for damages............... 3 Danger of explosion:......................4 Dangers to persons: ......................4 Visual Inspection ........................5 Recommended Tools and Cleaners.....................
- Page 3 Safe Handling Remove Battery Remove Fuel Cell Remove Pins / Fasteners General Safety Rules When using the tool, be aware that the fastener could deflect and cause injury. Keep fingers away from trigger when not operating this tool and when moving from one operating position to another.
- Page 4 Read and follow the instructions printed on the fuel cell. Do not expose the fuel cell to the direct sunshine. Do not place the fuel cell in a vehicle or a trunk where the temperature could rise. It could explode. A used empty fuel cell still contains a combustible propellant gas, which could swell and explode a container into pieces.
- Page 5 Visual Inspection Visually inspect the unit and compare it to a new unit o Does anything appear broken / damaged Recommended Tools and Cleaners Description / Trade Name Grainger Part Number Nylon Bristle Brush 13P555 or 1VAF3 or 35EN03 Brushes WD 40 20JY62 Cleaning Solutions...
- Page 6 Rear Cap Removal Use a T25 driver to remove the 4 Screws (PT#3) and Washers (PT#4) holding the rear housing (PT#6) onto the Base of the tool Open Fuel Cell Door and Remove Plastic Cover (PT#6)
- Page 7 Rear Cap (PT#6) Inspection Inspect and Clean mesh Filter (PT#2) with cleaner or Compressed Air If excessively dirty: Remove Plastic Mesh Retaining Screen (PT#1)
- Page 8 Clean and Reassemble onto Rear Plastic Cap (PT#6)
- Page 9 Removal of Fan and Sparker Wiring • Remove Sparker Connector (RED) by pulling the cable “Up” with a non-marking tool • Remove Fan Connector (Yellow) by pressing down on the connect and pulling “Down” Remove Rear Metal Housing Assembly (PT#7)
- Page 10 Rear Housing Assembly Inspection and Cleaning Inspect O-Ring on Rear Housing Assembly (PT#7) Remove O-Ring from Rear Metal Housing (PT#7) Clean and Lubricate the O-Ring o If worn or damaged replace the O-Ring Clean the carbon buildup on the Rear Metal Housing (PT#7) with cleaner and a soft bristle brush Reassemble O-Ring onto the housing...
- Page 11 Rear Chamber Inspection and Cleaning Apply Cleaner and Clean the Rear Chamber (PT#9) with cleaner and a soft bristle brush o Wipe away and debris Main Cylinder Inspection and Cleaning Press Piston (PT#11) “IN” o Apply Cleaner and Clean the Cylinder with cleaner and a soft bristle brush o Wipe away and debris o Apply Lubricant...
- Page 12 Press Piston (PT#11) Back o Apply Lubricant Reassembly Reinstall Rear Housing (PT#7) Reinstall Fan and Sparker Wiring Check /Confirm Wiring Reinstall Rear Plastic Housing (PT#6) o Confirm that Rear Plastic Housing Metal Bushing are Present (PT#6) in Nests Reinstall 4 T25 Screws (PT#3) and Washers (PT#4) Function Test Insert Pins Insert Fuel...
- Page 13 Maintenance Light Reset Safe Handling Remove Battery Remove Fuel Cell Remove Pins / Fasteners Remove Magazine or Move Pusher to Fully Open Position Press Down Contact Trip Press down Trigger...
- Page 14 Sequence While Both Contact Trip and Trigger is pressed, Insert Battery Hold For All for 30 Second Maintenance Light Check Remove Battery Wait 10 Seconds Insert Battery and confirm Maintenance light is off...
