- Page 1 Wired wall-mounted remote control for brand switches – 2 channels HmIPW-BRC2 Installation and Operating Manual...
- Page 2 Table of contents Table of contents 1 Package contents....................3 2 Information about this manual................. 3 3 Hazard information....................3 4 General system information................5 5 Function and device overview................5 6 Start-up........................5 6.1 Installation instructions....................5 6.2 Installation........................7 6.3 Adapters for brand switch systems................7 6.4 Pairing with a control unit..................8 7 Operation.......................
- Page 3 Do not use any Read this manual carefully before begin- detergents containing solvents for ning operation with your Homematic IP cleaning purposes. Wired device. Keep the manual for later consultation. If you hand the device over...
- Page 4 Hazard information The device is intended for operation on the Homematic IP Wired Bus on- ly. The Homematic IP Wired Bus is a SELV power circuit. The mains voltage for the building installation and the Homematic IP Wired Bus must be routed separately. Com-...
- Page 5 Remote Control for brand switches has To commission the device, two buttons and can be used flexibly in you must first commission a the Homematic IP system to control de- Homematic IP Wired Access Point vices and functions. (HmIPW-DRAP). The buttons can be used to control oth-...
- Page 6 You risk Wired Bus cable or an eQ-3 personal liability for personal injury and Homematic IP Wired Bus cable of property damage. another length (available as an ac- *Specialist knowledge required for in-...
- Page 7 Bus to the bus port. Press the or- ange operating button to connect or disconnect the individual wires. click Figure 7 • Switch the Homematic IP Wired Bus on to activate pairing mode of the Figure 5 device. The bus ports are connected in par- allel.
- Page 8 Set up your Homematic IP Wired Access Point via the Homematic IP app in order to Homematic IP use Wired devices in the system. Further information on this can be found in the operating manual for the Wired Access Point.
- Page 9 Homematic IP Wired Access function, an action is only carried Point to the (existing) Homematic IP out with a double-click. Specify the Central Control Unit as described time span in which the second click in the operating manual.
- Page 10 Troubleshooting Flash codes Flash code Meaning Solution 1x orange and 1x green Test display You can continue once light (after switching on the test display has the Wired Bus) stopped. Short orange flashes Pairing mode active Enter the last four dig- (every 10 s) its of the device number (SGTIN) in your app, or...
- Page 11 Restoring factory settings 9 Restoring factory settings 11 Disposal The factory settings of the device This symbol means that the device can be restored. If the device is must not be disposed of as house- paired with a Central Control Unit, hold waste, general waste, or in a the configurations are automatically yellow bin or a yellow sack.
- Page 12 Technical specifications 12 Technical specifications Short description HmIPW-BRC2 Supply voltage 24 VDC, ±5 %, SELV Protection class Degree of protection IP20 Ambient temperature -5 - +40°C Weight 27 g Dimensions (W x H x D) 71 x 71 x 28 mm Current consumption 10 mA max.
