ZXR10 2900E Series
Easy-maintenance Secure Switch
Hardware Manual
Version: 2.05.10
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26771900
Fax: +86-755-26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZXR10 2900E Series and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXR10 2900E Series

Summary of Contents for Zte ZXR10 2900E Series

  • Page 1 ZXR10 2900E Series Easy-maintenance Secure Switch Hardware Manual Version: 2.05.10 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26771900 Fax: +86-755-26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners.
  • Page 3 Contents About This Manual ..................I Chapter 1 Safety Instruction..............1-1 1.1 Safety Instruction ....................1-1 1.2 Safety Signs ...................... 1-1 Chapter 2 System Overview ..............2-1 2.1 Product Introduction ................... 2-1 2.2 Functions......................2-2 2.3 Technical Features and Parameters..............2-3 Chapter 3 Hardware Descroption..............
  • Page 4 Tables ......................III...
  • Page 5 This manual is ZXR10 2900E (V2.05.10) Series Easy-Maintenance Secure Switch Hardware Manual. It is applicable for ZXR10 2900E (V2.05.10) series easy-maintenance secure switch (brieved as ZXR10 2900E series, also named as switch in common part). It includes: ZXR10 2910E-PS easy-maintenance secure switch...
  • Page 7 It is not recommended to use the debug commands when the user networks are in normal state. ZTE Corporation will assume no responsibility for consequences resulting from violation of general specifications for safety operations or of safety rules for design, production and use of the devices.
  • Page 8 ZXR10 2900E Series Hardware Manual Note: Indicates the description, hint, tip and so on for configuration operations. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 9 ZXR10 2918E-PS ZXR10 2928E-PS Product Features The ZXR10 2900E series switch is environment friendly, safe, highly reliable, and easy to maintain, which brings enjoyable experience to customers. Environment-friendly energy-saving design Due to dynamic fan speed adjustment, intelligent power supply management, and reasonable PCB layout, the power of the series switch is reduced while the system performance is improved.
  • Page 10 IP visual telephone, dual-frequency WiFi AP, visual monitor camera, multi-function STB, and RFID card reader. As a result, network complexity is reduced. The ZXR10 2900E series switch can control power by time segment. As a result, the power consumption of network devices is effectively managed and operation costs are greatly reduced.
  • Page 11 Rated range: 100 AC, 50 DC Power Supply: voltage V-240 V AC, Hz/60 Rated voltage range: -48 V DC range: 100 50 Hz/60 Hz V-240 V AC, DC RPS 50 Hz/60 Hz input: Rated voltage: SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 12 ZXR10 2900E Series Hardware Manual ZXR10 ZXR10 ZXR10 ZXR10 ZXR10 ZXR10 Item 2918E 2928E 2952E 2910E-PS 2918E-PS 2928E-PS -54 V <306 W, <317 W, <831W, PoE Con- PoE external PoE external external sump- <13 W <17.1 W <27.2 W power is 240...
  • Page 13 For the power module of the ZXR10 2900E, pay attention to the following points: The structure and interfaces of the power module on the shelf vary with the power input mode. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 14 ZXR10 2900E Series Hardware Manual During operations and maintenance, avoid performing any operation on the power module when the power module is supplied with power. For the AC power mode, the system only supports single-phase. Ethernet Switching Main Board Ethernet...
  • Page 15 ZXR10 2918E supports two power supply modes: -48 V DC power supply and 110 V/220 V AC power supply. When the -48 V DC power supply is used, use –48 V DC power cable. When the AC power supply is used, use AC power cables. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 16 ZXR10 2900E Series Hardware Manual Interfaces For ZXR10 2918E interface descriptions, refer to Table 3-3. Table 3-3 ZXR10 2918E Interface Descriptions Name Quantity Description 10/100Base-TX Ethernet port These Ethernet ports are fixed. You can configure either 10/100/1000Base-T Ethernet ports or SFP ports (100Base-FX/1000Base- Combo port FX) as combo ports.
  • Page 17 Data is transferred. flashing No Link 10/100B- On top of Green ase-TX port the port indicator is Link LINK Green indicator is Data is transferred. flashing Green indicator is Port speed is 100M. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 18 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function State Meaning Option Yellow indicator is Port speed is 10M. Green indicator is Port is in full-duplex state. Yellow indicator is Port is in half-duplex state. The STP state of port is disable.
  • Page 19 Green port 100Base- indicator is Data is transferred. FX/1000B- flashing ase-FX) Green indicator is Port speed is 1000M. Yellow indicator is Port speed is 10M/100M. Green indicator is Port is in full-duplex state. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 20 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function State Meaning Option Yellow indicator is Port is in half-duplex state. 3.1.2 ZXR10 2928E Device Appearance ZXR10 2928E is 1U (1U=44.45 mm) high. It provides AC and DC power supplies. The front panel of ZXR10 2928E AC model is shown in Figure 3-3.
  • Page 21 When Boot starts to load the version, if the version is unavailable, the states of indicators do not change. If the version is loaded normally, the SYS indicator flashes at a frequency of one time per second. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 22 ZXR10 2900E Series Hardware Manual The ZXR10 2928E system indicators are listed as Table 3-7. Table 3-7 ZXR10 2928E System Indicators Indicator Position State Meaning Power off On the right side green The device is starting. of CONSOLE Green indicator port The device is running.
  • Page 23 Equipment will send 5 ICMP packets to Green network management center, for each indicator is PING ICMP packet, use 1-5 port indicators to indicate the right reply is received. 3-11 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 24 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function State Meaning Option Equipment will send 5 ICMP packets to Yellow network management center, for each indicator is ICMP packet, use 1-5 port indicators to indicate the right reply is not received.
  • Page 25 When the AC power supply is used, use AC power cables. The power socket and switch of ZXR10 2952E are on the back panel. For the AC model back panel, see Figure 3-6. For the DC model back panel, see Figure 3-7. 3-13 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 26 ZXR10 2900E Series Hardware Manual Figure 3-6 ZXR10 2952E Back Panel (AC power) Figure 3-7 ZXR10 2952E Back Panel (DC power) Interfaces For ZXR10 2952E interface descriptions, refer to Table 3-9. Table 3-9 ZXR10 2952E Interface Descriptions Name Quantity Description 10/100Base-TX Ethernet port These Ethernet ports are fixed.
  • Page 27 There is a M_button on the front panel. The mode is selected according to mode button. The corresponding port state indicator will turn on, which makes it convenient to maintain our equipments. ZXR10 2952E port indicator descriptions are listed as Table 3-11. 3-15 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 28 ZXR10 2900E Series Hardware Manual Table 3-11 ZXR10 2952E Port Indicator Description M_button Indicator Position Function State Meaning Option No connection Green indicator is The connection is established. None Green indicator is Data is transferred. flashing No Link Green indicator is...
  • Page 29 Green NoMAC indicator is Port does not learn MAC. No connection Green Fixed SFP indicator is The connection is established. port(100B- below the None ase-FX/100 port Green 0Base-FX) indicator is Data is transferred. flashing 3-17 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 30 ZXR10 2900E Series Hardware Manual 3.1.4 ZXR10 2910E-PS Device Appearance ZXR10 2910E-PS is 1U (1U=44.45 mm) high. The front panel of 2910E-PS is shown in Figure 3-8. Figure 3-8 ZXR10 2910E-PS Front Panel Power Supply ZXR10 2910E-PS supports AC power supply. The AC power socket and switch are on the front panel.
  • Page 31 When Boot starts to load the version, if the version is unavailable, the states of indicators do not change. If the version is loaded normally, the SYS indicator flashes at a frequency of one time per second. ZXR10 2910E-PS system indicators are listed as Table 3-13. 3-19 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 32 ZXR10 2900E Series Hardware Manual Table 3-13 ZXR10 2910E-PS System Indicators Indicator Position State Meaning Power off On the right side green The device is starting. of CONSOLE Green indicator port The device is running. is flashing On the right side The device runs normally.
  • Page 33 CPU utilization ratio, each port indicates 12.5% Green Uses the indicator of port 1-8 to show MEM% indicator is the current memory utilization ratio, each port indicates 12.5% Green STORM indicator is Port is storm port. 3-21 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 34 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function State Meaning Option No connection Green indicator is The connection is established. None Green indicator is Data is transferred. flashing No Link Green indicator is Link Combo LINK port(10/10 Green 0/1000B-...
  • Page 35 ZXR10 2918E-PS supports AC power supply and RPS power supply. When 110 V/220 V AC power supply is applied, use AC power cable. When RPS power supply is applied, RPS power developed by ZTE (RPS550 or RPS1100) and the private RPS power cable must be used and AC power should be off.
  • Page 36 ZXR10 2900E Series Hardware Manual Parameter Value Input voltage 100 V to 240 V AC Output maximum voltage -54 V Output electrical current 10.2 A Output maximum power 550 W Figure 3-12 Front Panel of RPS550 The RPS1100 front panel is shown in Figure 3-13.
  • Page 37 Ethernet port has two indicators. The left indicator of port shows the status of the port below. The right indicator of port shows the status of port above. Each SFP port has one indicator indicating port status. Three system indicators. Indicators running statuses are described as follows: 3-25 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 38 ZXR10 2900E Series Hardware Manual 1. System indicator System indicators include power indicator (PWR), running indicator (SYS) and alarm indicator (ALM). After the system is powered up, the PWR indicator is on and the SYS indicator is When Boot starts to load the version, if the version is unavailable, the states of indicators do not change.
  • Page 39 Green indicator is The STP state of port is forward. STAT Yellow indicator is Other Port is power off. Green indicator is Port is power on. Yellow indicator is Port power supply is abnormal. 3-27 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 40 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function State Meaning Option Green Uses the indicator of port 1~10 to show CPU% indicator is the current CPU utilization ratio, each port indicates 10% Green Uses the indicator of port 1~10 to show...
  • Page 41 ZXR10 2918E-PS power indicator descriptions are listed as Table 3-19. Table 3-19 ZXR10 2918E-PS Power Indicator Descriptions Indicator Position State Meaning Power off On the left of AC PoE PWR Green indicator power socket Power works normally. is on 3-29 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 42 ZXR10 2900E Series Hardware Manual Indicator Position State Meaning Power off or power has no faults. On the left of AC FAULT Red indicator is Power has temperature alarm or has power socket faults. 3.1.6 ZXR10 2928E-PS Device Appearance ZXR10 2928E-PS is 1U (1U=44.45 mm) high.
  • Page 43 1 debugging network interface indicator, indicating the status of the debugging network interface. 3 system indicators. Indicators running statuses are described as follows: 1. System indicator 3-31 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 44 ZXR10 2900E Series Hardware Manual System indicators include power indicator (PWR), running indicator (SYS) and alarm indicator (ALM). After the system is powered up, the PWR indicator is on and the SYS indicator is When Boot starts to load the version, if the version is unavailable, the states of indicators do not change.
  • Page 45 Port is power on. Yellow indicator is Port power supply is abnormal. Green Uses the indicator of port 1-10 to show CPU% indicator is the current CPU utilization ratio, each port indicates 10% 3-33 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 46 ZXR10 2900E Series Hardware Manual M_button Indicator Position Function Status Description Option Green Uses the indicator of port 1-10 to show MEM% indicator is the current memory utilization ratio, each port indicates 10% Uses the indicator of port 1-10 to...
  • Page 47 Figure 3-18 Front Panel of RS-29EC-4GE-SFP On the panel of RS-29EC-4GE-SFP, four indicators are provided corresponding to the four gigabit Ethernet uplink optical interfaces. For the descriptions of the indicators, refer to Table 3-24. 3-35 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 48 ZXR10 2900E Series Hardware Manual Table 3-24 Descriptions of RS-29EC-4FE-SFP Indicators Indicator Mode Green Yellow Green indicator is on: Yellow indicator is on: Gigabit optical 1G Link 100M Link Uncon- interface SDP mode nected Green indicator is Yellow indicator is...
  • Page 49 100M optical interface Unconnected Green indicator is flashing: 100M indicator Active 3.1.7 Optical Module Overview The interface board of the ZXR10 2900E switch uses pluggable optical modules called Small Form-factor Pluggable (SFP), see Figure 3-21. 3-37 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 50 ZXR10 2900E Series Hardware Manual Figure 3-21 SFP Attributes of SFP For the attributes of an SFP optical module, refer to Table 3-27. Table 3-27 Attributes of SFP MMF/500 M SMF/10 KM SMF/40 KM SMF/80 KM SMF/120 Attribute Port Port...
  • Page 51 2. Connection of DC Power Cable DC -48 V power cable C-PWR-084 is shown in Figure 3-23. Figure 3-23 DC Power Cable C-PWR-084 Diagram Corresponding relationship between two ends of DC power cable is as shown in Table 3-29. 3-39 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 52 End A connects ZXR10 2918E-PS, End B connects RPS power device developed by ZTE. For device connection, end A connects to the RPS input end on the ZXR10 2918E-PS rear board, and end B connects to the output end of the ZTE RPS550 power supply, as shown in Figure 3-24.
  • Page 53 Pin of End C Black Blue For device connection, end A connects to the RPS input end on the ZXR10 2918E-PS rear board, and end B connects to the output end of the ZTE RPS1100 power supply, as shown in Figure 3-26.
  • Page 54 ZXR10 2900E Series Hardware Manual Figure 3-26 ZXR10 2918E-PS and RPS1100 Connection Diagram 3.2.2 Protective Cables Protective grounding cables prevent the switch from lightning and interference. For the appearance of a protective grounding cable, see Figure 3-27. Figure 3-27 Appearance of a Protective Grounding Cable...
  • Page 55 When there is no grounding strip but earth near the equipment room that allows a grounding body to be buried, hammer an angle iron/steel pipe longer than 0.5 m into 3-43 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 56 ZXR10 2900E Series Hardware Manual the earth, see Figure 3-29. Weld the yellow-green ground wire of the switch onto the angle iron/steel pipe, and process the joint against erosion. Figure 3-29 Grounding the Switch by Burying the Grounding Body into the Earth 1.
  • Page 57 RTN wire is well connected to the ground at the DC output of the DC power cabinet. Figure 3-31 Grounding through the PGND of a Power cabinet 1. AC/DC power cabinet 3. -48V 5. -48VRTN 2. -48V bar 4. RTN bar 6. PGND bar 3-45 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 58 ZXR10 2900E Series Hardware Manual 7. Grounding 9. Ground terminal 8. Ground wire 10. DC input 3.2.3 Serial Console Cable Serial console cable is the basic cable used in configuring and maintaining ZXR10 2900E. Serial configuration line is provided together with ZXR10 2900E, one end to be DB9 console port (connected to serial port of PC) and the other end to be RJ45 port (connected to Console port on main Board of ZXR10 2900E).
  • Page 59 3-35. Table 3-35 Straight-through Ethernet Cable Sequence Wire Color Code End A End B Wire Color Code Legend White orange White orange Orange Orange White green White green Blue Blue White blue White blue 3-47 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 60 ZXR10 2900E Series Hardware Manual Wire Color Code End A End B Wire Color Code Legend Green Green White brown White brown Brown Brown The corresponding relationship between crossover cable core wires and pin position is described in Table 3-36.
  • Page 61 The ZXR10 2900E series Ethernet switch belongs to type I laser equipment. If an optical interface of the ZXR10 2900E series switch is in working state, do not look at the interface directly. The beam emitted by the fiber has very great energy, and looking at it directly will damage your retina.
  • Page 62 ZXR10 2900E Series Hardware Manual Table 3-38 Fiber Type Table Mode Switch End Connector Type Opposite End Connector Type FC/PC Connector SC-PC Connector (Square Single-mode fiber SC/PC Connector Panhead) ST/PC Connector FC/PC Connector SC-PC Connector (Square Multi-Mode Fiber SC/PC Connector...
  • Page 63 1. To install ZXR10 2918E/2928E/2952E/2918E-PS onto a 19-inch cabinet, fix two flanges (both flanges and screws are provided together with the device) on two sides of the switch shell, see Figure 4-2 (taking ZXR10 2952E for example). SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 64 ZXR10 2900E Series Hardware Manual Figure 4-2 Installation of Flanges 2. Install a pair of symmetric holding plates inside the 19-inch cabinet to support switching, see Figure 4-3. Figure 4-3 Installation of Holding Plates 3. After fixing holding plates, push in switch along the holding plates and fix flanges onto...
  • Page 65 Figure 4-5. Figure 4-5 Installation of Flanges (ZXR10 2910E-PS) 2. Install a pair of symmetric holding plates inside the 19-inch cabinet to support switching, see Figure 4-6. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 66 ZXR10 2900E Series Hardware Manual Figure 4-6 Installation of Holding Plates (ZXR10 2910E-PS) 3. After fixing holding plates, push in switch along the holding plates and fix flanges onto the cabinet, see Figure 4-7 Figure 4-7 Fixing Device (ZXR10 2910E-PS) ZXR10 2928E-PS Installation 1.
  • Page 67 See Figure 4-9. Figure 4-9 Holding Plate Installation 3. After fixing holding plates, push in the switch along the holding plates and fix flanges onto the cabinet. See Figure 4-10 Figure 4-10 Fixing the Switch SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 68 ZXR10 2900E Series Hardware Manual 4.3 Cable Laying The ZXR10 2900E cables consist of group wire, power cable, serial console cable, network cable and fiber. 4.3.1 Installation Specifications Installation Specifications for Power Cables and Grounding Cables Layout Principles Power cables are straight and with smooth arcs at turning sections.
  • Page 69 Connect the switch AC power cable. b. Turn on the external power supply. 5. Power off ZXR10 2900E in the following steps: a. Turn off the external power supply. b. Disconnect the switch AC power cable. SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 70 ZXR10 2900E Series Hardware Manual 4.4 Lightning Protection of the Switch(Optional) 4.4.1 Installation of Lightning Arrester for AC Power Caution! Lightning arrester will not be delivered with the switch. You should purchase it if needed. If an outdoor AC power cord should be directly led to the switch, serially connect the...
  • Page 71 Tools Phillips screwdriver or Flat-blade screwdriver Multimeter Tilted wire cutter SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 72 ZXR10 2900E Series Hardware Manual Installation procedure 1. Tear the protection paper at one side of the double faced adhesive tape apart from the tape, and stick the tape on the surface of the arrester. Tear the protection paper at another side apart from the tape, and stick the arrester onto the chassis of the switch.
  • Page 73 The lightning arrester for the network port is not installed completely. If the switch has more than one network port to interconnect to other devices via cables outdoor, install lightning arresters for all these network ports for protection. 4-11 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 74 ZXR10 2900E Series Hardware Manual This page intentionally left blank. 4-12 SJ-20120409144109-001|2012-07-02(R1.0) ZTE Proprietary and Confidential...
  • Page 75 Figures Figure 3-1 ZXR10 2918E AC Model Front Panel............3-3 Figure 3-2 ZXR10 2918E DC Model Front Panel ............3-3 Figure 3-3 ZXR10 2928E AC Model Front Panel............3-8 Figure 3-4 ZXR10 2928E DC Model Front Panel ............3-8 Figure 3-5 ZXR10 2952E Front Panel ..............3-13 Figure 3-6 ZXR10 2952E Back Panel (AC power)...........
  • Page 76 ZXR10 2900E Series Hardware Manual Figure 3-31 Grounding through the PGND of a Power cabinet ........ 3-45 Figure 3-32 ZXR10 2900E Serial Console Cable Diagram ........3-46 Figure 3-33 Ethernet cable..................3-47 Figure 3-34 Fiber Cable Cross-sectional Area............3-49 Figure 4-1 Desktop Installation.................. 4-1 Figure 4-2 Installation of Flanges ................
  • Page 77 Tables Table 2-1 ZXR10 2900E Technical Features and Parameters ........2-3 Table 3-1 Technical Parameters of ZXR10 2910E-PS/2918E-PS Fans...... 3-2 Table 3-2 Technical Parameters of ZXR10 2928E-PSS Fans ........3-2 Table 3-3 ZXR10 2918E Interface Descriptions............3-4 Table 3-4 ZXR10 2918E System Indicators............... 3-5 Table 3-5 ZXR10 2918E Port Indicator Description ...........
  • Page 78 ZXR10 2900E Series Hardware Manual Table 3-31 RPS550 Core Wire Corresponding Table..........3-40 Table 3-32 RPS1100 Core Wire Corresponding Table ..........3-41 Table 3-33 Technical Parameters of Protective Grounding Cables ......3-42 Table 3-34 Serial Console Cable Line Order Table ..........3-46 Table 3-35 Straight-through Ethernet Cable Sequence..........
