Johnson Controls YORK MVV SD Series Installation Instructions Manual

Medium voltage variable speed drive

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Medium Voltage Variable Speed Drive

Installation

Medium Voltage 500 hp to 3,000 hp, 2,300 V, 3,300 V,

4,160 V, and 6,600 V, 60 Hz, 3,300 V and 6,600 V, 50 Hz

Variable Speed Drives for YK, YD, YK-EP, and YK-CP Chiller

Applications

Installation Guide

Issue Date: 2025-05-28

Form: 160.00-N6 (525)

Supersedes: 160.00-N6 (624)

Table of Contents

Need help?

Do you have a question about the YORK MVV SD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Johnson Controls YORK MVV SD Series

Page 1 4,160 V, and 6,600 V, 60 Hz, 3,300 V and 6,600 V, 50 Hz Variable Speed Drives for YK, YD, YK-EP, and YK-CP Chiller Applications Installation Guide Form: 160.00-N6 (525) Issue Date: 2025-05-28 Supersedes: 160.00-N6 (624) © 2025 Johnson Controls. All rights reserved.
Page 3: Table Of Contents
Oil pump wiring................................... 28 Initial commissioning................................29 Upstream protection................................29 Pre-energization check................................30 Confirmation of wiring................................ 30 Device/mechanism check..............................31 Electrical checks................................... 31 Initial energization................................32 Start-up and test.................................. 32 Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 5: General Safety Guidelines
Note: Highlights additional information useful to the technician in completing the work being performed correctly. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 6: Changeability Of This Document
All wiring must be in accordance with specifications published by Johnson Controls and must be performed only by a qualified electrician. Johnson Controls will not be responsible for damage or problems resulting from incorrect connections to the controls or application of incorrect control signals. Failure to follow this warning will void the manufacturer’s warranty and cause serious damage to property or personal injury.
Page 7: Unit Model Number Nomenclature
50 KA 50 KA 50 KA 50 KA Output voltage 2,300 3,300 3,300 4,160 4,160 Maximum output frequency 60 Hz 50 Hz 60 Hz 60 Hz 60 Hz Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 8: Mvvsd Requirements
3,300 2,903 kg 74 x 44 x 104 6,600 lb MVVSD06002K-92 3,300 3,300 (188 x 112 x 2,994 kg 264) 6,800 lb MVVSD07002K-92 3,300 3,300 3,085 kg Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 9 3,300 3,300 2,250 174 x 50 x 104 5,500 lb 5,761 kgs. (442 x 127 x 13,500 lb 2,495 kg 264) MVVSD25002K-94 3,300 3,300 2,500 6,123 kgs. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 10 4,160 1,500 (310 x 112 x 3,856 kg 1,134 kg 264) 9,400 lb MVVSD17502K-95 6,600 4,160 1,750 4,264 kg 10,000 lb MVVSD20002K-95 6,600 4,160 2,000 4,536 kg Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 11 2,250 164 x 50 x 104 5,080 kg 2,041 kg (417 x 127 x 12,000 lb 4,500 lb 264) MVVSD25002K-85 6,600 4,160 2,500 5,443 kg 2,041 kg Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 12: Field Connection Notes
Table 3: Product specific wiring diagram literature Product Form number YK Mod G 160.75-PW3 YK Mod H and YK Mod J 160.76-PW3 YD Mod D 160.79-PW10 YK-EP Mod B 160.87-PW8 YK-CP 160.96-PW3 Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 14: Grounding Details
Figure 1: Grounding details Callout Description Callout Description Leveling beams Power conversion and control Main power transformer Shipping split Equipment floor sills Building ground grid Steel floor beam Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 15: Unit Dimensional Details
Unit dimensional details Unit dimensional details Figure 2: Unit dimensions (74 in. x 44 in. x 104 in.) Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 19: Installation
Remove any transit packing and inspect the unit to ensure that all components have been delivered and that no damage has occurred during transit. If any damage is evident, note it on the carrier's freight bill and enter a claim. Report any major damage your local Johnson Controls representative. CAUTION Do not install or energize equipment that has been damaged.
Page 20: Safety Precautions
Do not store the unit in places that are exposed to outside weather conditions, for example, wind, rain, or snow. • Store in an upright position as indicated on the shipping carton. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 21 Installation Figure 6: Unit clearances, depth view, in. (cm) Figure 7: Unit clearances, width view, in. (cm) Note: See Table 2 for unit width and depth dimensions. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 22: Location
If the application is greater than 5,000 ft (1,524 m) above sea level, the drive must be reviewed as a special quote. For additional details about derating the unit, contact Johnson Controls marketing. Lifting and assembling the drive For unit weights, see the unit model reference chart provided in...
Page 23 45°. Ropes or cables must not pass through the holes in lifting angles or eyebolts. Use slings with safety hooks or shackles of adequate load rating. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 24: Mounting Requirements
Do not mount additional controls, for example relays, in the unit. Do not run power and control wiring not connected to the unit through the unit. If these precautions are not followed electrical noise could cause malfunctions or damage the unit and its controls. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 25: Control Wiring
In addition, the Modbus cable is comprised of three conductors and a shield. Standard 20 gauge shielded wire can be used. Note: Do not run control wiring in the same conduit with power wiring. Figure 9: Modbus connections Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 26: Power Wiring
3/8 in. - 16 hex nut Crimped lugs, customer supplied 3/8 in. lock washer 3/8 in. through point, at two places for each standoff for customer connection 3/8 in. washer Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 27: Grounding
There must never be a second source of power to the MVVSD. The only source of power must be the three- phase incoming wiring to the main isolation switch. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 28: Oil Pump Wiring
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Wire numbers ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ OptiView panel: TB6 VSOP cabinet Chiller-wire termination location Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 29: Initial Commissioning
All cable entry openings must be sealed to reduce the risk of entry by vermin and to allow for maximum cooling efficiency. • Follow all warnings and precautions, do not exceed equipment ratings. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 30: Pre-Energization Check
• Verify that all grounding connections are correctly connected. • Verify that there are no short circuits or inadvertent grounds and tighten any loose connector terminal screws. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 31: Device/Mechanism Check
All field wiring must be in accordance with the current edition of the NEC and all other applicable codes and specifications. Refer to the applicable Field Connections Wiring Diagram for the chiller model being connected to this panel. Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 32: Initial Energization
Before releasing the drive system for regular operation after installation, the system must be adjusted and tested by qualified YORK or Johnson Controls personnel. This start-up labor is included in the sale of each MVVSD, to ensure reliable and safe performance. It is important to make arrangements for such a check and that time is allowed for it.
Page 33: Unit Conversion
To convert a temperature range (that is, a range of 10°F) from Fahrenheit to Celsius, multiply by 5/9 or 0.5556. Example: 10.0°F range x 0.5556 = 5.6 °C range Medium Voltage Variable Speed Drive Installation © 2025 Johnson Controls. All rights reserved.
Page 34 Unit conversion © 2025 Johnson Controls. 5000 Renaissance Drive, New Freedom, York, PA 17349, USA. www.johnsoncontrols.com. Subject to change without notice. All rights reserved. © 2025 Johnson Controls. All rights reserved.
