Please file and use this supplement manual together with the service manual for Model No.KX-
TG2511ALM/KX-TG2511ALS/KX-TG2511ALT/KX-TG2512ALS/KX-TG2512ALT/KX-TG2513ALT/KX-
TGA250AZM/KX-TGA250AZS/KX-TGA250AZT, Order No.KM41004075CE.
TABLE OF CONTENTS
1 REPLACEMENT PARTS LIST--------------------------------- 2
1.1. REFERENCE CHART------------------------------------ 2
1.2. ORIGINAL AND NEW PARTS COMPARISON
LISTS --------------------------------------------------------- 2
Model No.
Digital Cordless Phone
M: Metallic Grey Version
S: Silver Version
T: Titanium Black Version
(for Australia)
PAGE
© Panasonic System Networks Co., Ltd. 2012
Unauthorized copying and distribution is a violation
of law.
ORDER NO. KM41203698SE
Telephone Equipment
KX-TG2511ALM
KX-TG2511ALS
KX-TG2511ALT
KX-TG2512ALS
KX-TG2512ALT
KX-TG2513ALT
KX-TGA250AZM
KX-TGA250AZS
KX-TGA250AZT
Advertisement
Related Manuals for Panasonic KX-TG2511ALM
Summary of Contents for Panasonic KX-TG2511ALM
- Page 1 TGA250AZM/KX-TGA250AZS/KX-TGA250AZT, Order No.KM41004075CE. TABLE OF CONTENTS PAGE 1 REPLACEMENT PARTS LIST--------------------------------- 2 1.1. REFERENCE CHART------------------------------------ 2 1.2. ORIGINAL AND NEW PARTS COMPARISON LISTS --------------------------------------------------------- 2 © Panasonic System Networks Co., Ltd. 2012 Unauthorized copying and distribution is a violation of law.
- Page 2 Main P.C.Board Parts(Handset) L804 ---------- G1C1N8Z00006 CHIP INDUCTOR R802 ERJ2GEJ101 ERJ2GEJ560X RESISTOR, 56Ω C182 F1G1H3R0A480 F1G1H2R0A480 CAPACITOR, 2pF C802 F1G1H2R0A480 F1G1H1R5A480 CAPACITOR, 1.5pF C804 F1G1H2R0A480 F1G1H1R5A480 CAPACITOR, 1.5pF C861 F1G1H3R0A480 F1G1H2R0A480 CAPACITOR, 2pF KX-TG2511ALM KX-TG2511ALS KX-TG2511ALT KX-TG2512ALS KX-TG2512ALT KX-TG2513ALT KX-TGA250AZM KX-TGA250AZS KX-TGA250AZT...
