Page 1 HP ProBook 4415s Notebook PC HP ProBook 4416s Notebook PC HP ProBook 4515s Notebook PC Maintenance and Service Guide Download from Www.Somanuals.com. All Manuals Search And Download.
Page 2 The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Page 3 MSG revision history Revision Publication date Description ● October 2009 Updated commodities in the following location: Product description on page ● Added screw covers to the screw removal images and procedures in the following location: Switch cover and keyboard on page 61 ●...
Page 4 MSG revision history Download from Www.Somanuals.com. All Manuals Search And Download.
Page 5 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
Page 6 Safety warning notice Download from Www.Somanuals.com. All Manuals Search And Download.
Page 7: Table Of Contents
Table of contents 1 Product description 2 External component identification Windows Vista and Windows XP ....................... 10 Display ..........................10 Top components ........................ 11 Pointing devices ....................11 Lights ......................... 12 Buttons, switches, and speakers ............... 13 Keys ........................14 Front components ......................
Page 8 Plastics Kit ............................42 Cable Kit ............................. 43 Mass storage devices ......................... 44 Miscellaneous parts ..........................45 Sequential part number listing ......................46 4 Removal and replacement procedures Preliminary replacement requirements ....................53 Tools required ........................53 Service considerations ....................... 53 Plastic parts .......................
Page 9 5 Computer Setup Computer Setup in Windows Vista and Windows XP ..............110 Starting Computer Setup ....................110 Using Computer Setup ....................110 Navigating and selecting in Computer Setup ..........110 Restoring factory settings in Computer Setup ..........111 Computer Setup menus ....................111 File menu ......................
Page 10 Phillips PM2.0×3.0 screw ......................... 144 Phillips PM2.5×6.0 screw ......................... 145 Phillips PM2.5×11.0 captive screw ....................146 Phillips PM3.0×4.0 screw ......................... 147 Phillips PM2.0×4.0 screw ......................... 148 Phillips PM2.5×3.0 screw ......................... 149 Phillips PM2.5×4.5 screw ......................... 153 Phillips PM2.5×3.0 broadhead screw ....................155 Phillips PM2.5×7.0 screw .........................
Page 11 Index ................................. 178 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 12 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 13: Product Description
15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s Product HP ProBook 4415s Notebook PC √ √ Name HP ProBook 4416s Notebook PC √ HP ProBook 4515s Notebook PC √ √ Processors AMD Turion™ II Ultra Dual-Core √ √ √ √...
Page 14 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s AMD Athlon QL-64 2.1GHz √ √ √ √ processor, 1-MB L2 cache AMD Athlon QL-66 2.2-GHz √ √ √ √ processor, 1-MB L2 cache AMD Sempron™ M100 2.0-GHz √...
Page 15 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s 15.6-in HD AntiGlare without √ √ webcam 15.6-in HD AntiGlare with webcam √ √ 15.6-in HD AntiGlare with webcam √ √ and WWAN 15.6-in HD BrightView without √...
Page 16 ● 250-GB, 5400-rpm ● 250-GB, 7200-rpm ● 320-GB, 5400-rpm ● 320-GB, 7200-rpm ● 500-GB, 5400-rpm ● 500-GB, 7200-rpm HP 3D DriveGuard √ √ √ √ Optical Fixed (removal of 1 screw required) √ √ √ √ drives Supports no optical drive option √...
Page 17 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s S3/S4/S5 wake on LAN (AC mode √ √ √ √ only) Wireless Integrated WLAN options by way of √ √ √ √ MiniPCI card 2 WLAN antennas built into display √...
Page 18 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s VGA (Dsub 15-pin) supporting 1600 √ √ √ √ × 1200 external resolution at 75- GHz (hot plug/unplug with auto- detect) High-Definition Multimedia Interface √ √ √...
Page 19 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s ● Red Flag Linux (in the People's √ √ √ √ Republic of China only) ● SuSE Linux √ √ √ √ ● FreeDOS √ √ √...
Page 20 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s ● Windows Vista Basic 32 with √ √ √ √ Office 2007 Ready (except Japan) ● Windows Vista Basic 32 with √ √ √ √ Office 2007 Ready – China Mobile ●...
Page 21 Category Description 14.0-in UMA 14.0-in 15.6-in UMA 15.6-in 4415s Discrete 4416s 4515s Discrete 4515s ● Windows Vista (Office Ready √ √ √ √ DVD) ● Windows Vista Home √ √ √ √ Premium ● Windows Vista (DRDVD) √ √ √ √...
Page 22: External Component Identification
External component identification Windows Vista and Windows XP Display NOTE: Your computer may look slightly different from the illustration in this section. Component Description Internal display switch Turns off the display if the display is closed while the power is on. Internal microphone Records sound.
Page 23: Top Components
Top components Pointing devices Component Description TouchPad* Moves the pointer and selects or activates items on the screen. Left TouchPad button* Functions like the left button on an external mouse. TouchPad scroll zone Scrolls up or down. Right TouchPad button* Functions like the right button on an external mouse.
Page 24: Lights
Lights NOTE: Your computer may look slightly different from the illustration in this section. Component Description Caps lock light On: Caps lock is on. ● Info Center/QuickLook light On: The computer is on. ● Blinking (5 times): ◦ When the computer is on, press button to launch Info Center.
Page 25: Buttons, Switches, And Speakers
Buttons, switches, and speakers NOTE: Your computer may look slightly different from the illustration in this section. Component Description Speakers (2) Produce sound. Internal display switch Turns off the display if the display is closed while the power is on. Info Center/Quick Look button Launches Info Center or QuickLook.
Page 26: Keys
Keys NOTE: Refer to the illustration that most closely matches your computer. Component Description Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key, the num lk key, or the key.
Page 27 Component Description Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key or the key. Windows logo key Displays the Windows Start menu. Windows applications key Displays a shortcut menu for items beneath the pointer. Integrated numeric keypad keys Can be used like the keys on an external numeric keypad.
Page 28: Front Components
Drive light Blinking turquoise: The hard drive or optical drive is being accessed. ● Amber: HP 3D DriveGuard has temporarily parked the hard drive. Wireless switch Turns the wireless feature on or off but does not establish a wireless connection.
Page 29: Right-Side Components
Right-side components Component Description USB ports (2) Connect optional USB devices. RJ-11 (modem) jack (select models only) Connects a modem cable. Optical drive (select models only) Reads optical discs and, on select models, also writes to optical discs. Optical drive light (select models only) Blinking: The optical drive is being accessed.
Page 30: Left-Side Components
Left-side components Component Description ExpressCard slot Supports optional ExpressCards. Security cable slot Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen. RJ-45 (network) jack Connects a network cable.
Page 31: Bottom Components
Bottom components Component Description Battery release latches (2) Release the battery from the battery bay. Battery bay Holds the battery. Wireless antennas Component Description WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless wide-area networks (WWAN). Windows Vista and Windows XP Download from Www.Somanuals.com.
Page 32: Additional Hardware Components
Component Description WLAN antennas (2)* Send and receive wireless signals to communicate with wireless local area networks (WLAN). *To see wireless regulatory notices, refer to the section of the Regulatory, Safety and Environmental Notices that applies to your country or region. These notices are located in Help and Support. NOTE: The antennas are not visible from the outside of the computer.
Page 33: Linux
Linux Display NOTE: Your computer may look slightly different from the illustration in this section. Component Description Internal display switch Turns off the display if the display is closed while the power is on. Internal microphone Records sound. Webcam light (select models only) On: The webcam is in use.
Page 34: Top Components
Top components Pointing devices Component Description TouchPad Moves the pointer and selects or activates items on the screen. Left TouchPad button Functions like the left button on an external mouse. TouchPad scroll zone Scrolls up or down. Right TouchPad button Functions like the right button on an external mouse.
Page 35: Lights
Lights NOTE: Your computer may look slightly different from the illustration in this section. Component Description Caps lock light On: Caps lock is on. ● Info Center/QuickLook light On: The computer is on. ● Blinking (5 times): ◦ When the computer is on, press button to launch Info Center.
Page 36: Buttons, Switch, And Speakers
Buttons, switch, and speakers NOTE: Your computer may look slightly different from the illustration in this section. Component Description Speakers (2) Produce sound. Internal display switch Turns off the display if the display is closed while the power is on. Info Center/QuickLook button Launches Info Center or QuickLook.
Page 37: Keys
Keys NOTE: Refer to the illustration that most closely matches your computer. Component Description Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key, the num lk key, or the key.
Page 38 Component Description Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key or the key. Function keys Execute frequently used system functions when pressed in combination with the key.
Page 39: Front Components
Front components Component Description Drive light Blinking turquoise: The hard drive or optical drive is being accessed. Wireless switch Turns the wireless feature on or off but does not establish a wireless connection. NOTE: You must set up or access a wireless network to establish a wireless connection.
Page 40: Right-Side Components
Right-side components Component Description USB ports (2) Connect optional USB devices. RJ-11 (modem) jack (select models only) Connects a modem cable. Optical drive (select models only) Reads optical discs and, on select models, also writes to optical discs. Optical drive light (select models only) Blinking: The optical drive is being accessed.
Page 41: Left-Side Components
Left-side components Component Description ExpressCard slot Supports optional ExpressCards. Security cable slot Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen. RJ-45 (network) jack Connects a network cable.
Page 42: Bottom Components
Bottom components Component Description Battery release latches (2) Release the battery from the battery bay. Battery bay Holds the battery. Chapter 2 External component identification Download from Www.Somanuals.com. All Manuals Search And Download.
Page 43: Wireless Antennas
Wireless antennas Component Description WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless wide-area networks (WWAN). WLAN antennas (2)* Send and receive wireless signals to communicate with wireless local area networks (WLAN). *To see wireless regulatory notices, refer to the section of the Regulatory, Safety and Environmental Notices that applies to your country or region.
Page 44: Additional Hardware Components
Additional hardware components Component Description Power cord* Connects an AC adapter to an AC outlet. Battery* Powers the computer when the computer is not plugged into external power. AC adapter Converts AC power to DC power. *Batteries and power cords vary in appearance by country or region. Chapter 2 External component identification Download from Www.Somanuals.com.
Page 45: Illustrated Parts Catalog
Illustrated parts catalog Service tag The service tag, affixed to the bottom of the computer, provides information that may be needed when troubleshooting system problems. The service tag provides the following information: (1) Product name: This is the product name affixed to the front of the computer. (2) Serial number (s/n): This is an alphanumeric identifier that is unique to each product.
Page 46: Computer Major Components
Computer major components Item Description Spare part number Display assembly (includes 2 WLAN antenna transceivers and cables) For use only with black computers with 15.6-in HD LED displays ● AntiGlare display assembly for use in computers not equipped with a webcam 536790-001 ●...
Page 47 Item Description Spare part number ● AntiGlare display assembly for use on computers equipped with a webcam and WWAN 536794-001 module ● BrightView display assembly for use on computers equipped with a webcam and WWAN 536795-001 module For use only with red computers with 15.6-in HD displays ●...
Page 48 Item Description Spare part number For use in red computers with 15.6-in displays 572728-001 For use in black computers with 14.0-in displays 535867-001 For use in red computers with 14.0-in displays 572727-001 Speakers For use in computers with 15.6-in displays 536598-001 For use in computers with 14.0-in displays 536420-001...
Page 49 Item Description Spare part number For use only in models with the following system boards: 585218-001, 585219-001, 537921-001 585220-001, 585221-001 (12) Processor (includes replacement thermal material) (not illustrated) AMD Turion II Ultra Dual-Core processors (for use only with the following system boards: 585218-001, 585219-001, 585220-001, 585221-001) ●...
Page 50 Item Description Spare part number ● For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, 504664-002 Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican...
Page 51 Item Description Spare part number 1-GB 535809-001 2-GB 535810-001 (17) WWAN module For use in all countries and regions except China 483377-002 For use in China 571888-001 Including GPS, UNDP (United Nations Development Program; not available with Linux) 531993-001 (18) Subscriber identification module (SIM) 536599-001 (19)
Page 52: Display Assembly Components
Display assembly components Item Description Spare part number Display bezel For use in computers with 15.6-in displays with a webcam 536421-001 For use in computers with 15.6-in displays without a webcam 536424-001 For use in computers with 14.0-in displays with a webcam 536423-001 For use in computers with 14.0-in displays without a webcam 536422-001...
Page 53 Item Description Spare part number For use in computers with 14.0-in displays 535871-001 Webcam module 535797-001 Display Cable Kit For use in computers with 15.6-in HD displays 536433-001 For use in computers with 14.0-in displays 536430-001 (4a) Microphone cable (4b) WLAN antenna receivers and cables (4c) WWAN antenna receivers and cables...
Page 54: Plastics Kit
Plastics Kit Item Description Spare part number Plastics Kit: 535780-001 ExpressCard slot bezel Optical drive bezel Chapter 3 Illustrated parts catalog Download from Www.Somanuals.com. All Manuals Search And Download.
Page 55: Cable Kit
Cable Kit Item Description Spare part number Cable Kit For use only with computers with 14.0-in displays 536538-001 For use only with computers with 15.6-in displays 536539-001 TouchPad cable RJ-45 (network) cable Bluetooth cable Power button board and cable USB cable Power cable RJ-11 (modem) jack cable Cable Kit...
Page 56: Mass Storage Devices
Mass storage devices Item Description Spare part number Hard drives (include bracket) 500-GB, 7200-rpm 575125-001 500-GB, 5400-rpm 535814-001 320-GB, 7200-rpm 575124-001 320-GB, 5400-rpm (for use only in models with the following system boards: 535803-001, 535813-001 574505-001, 574506-001) 250-GB, 7200-rpm 536783-001 250-GB, 5400-rpm (for use only in models with the following system boards: 535803-001, 535812-001 574505-001, 574506-001)
Page 57: Miscellaneous Parts
Miscellaneous parts Description Spare part number AC adapters 65-W AC adapter 463958-001 90-W AC adapter (for use in all countries and regions except India) 463955-001 90-W non-PFC AC adapter (for use only in India) 463956-001 90-W PFC AC adapter (for use only in India) 535593-001 Power cords: For use in the United States...
Page 58: Sequential Part Number Listing
Sequential part number listing Spare part Description number 246959-001 Power cord for use in the United States 246959-011 Power cord for use in Australia and New Zealand 246959-021 Power cord for use in Europe, the Middle East, and Africa 246959-031 Power cord for use in the United Kingdom 246959-061 Power cord for use in Italy...
Page 59 Spare part Description number 504664-001 Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States 504664-002 Broadcom 4322 802.11a/b/g/n WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde,...
Page 60 Spare part Description number 535804-001 Heat sink for use in computers with UMA graphics subsystems 535805-001 Heat sink for use in computers with discrete graphics subsystems 536418-001 6-cell, 47-Wh Li-ion battery for use in computers with 15.6-in displays 535753-001 8-cell, 63-Wh Li-ion battery for use in computers with 15.6-in displays 535809-001 1-GB memory module (PC2-6400,800-MHz, DDR2) 535810-001...
Page 61 Spare part Description number 536410-AD1 Keyboard for use in Korea on computers with 14.0-in 536420-001 Speakers for use in computers with 14.0-in displays 536421-001 Display bezel for use on computers with 15.6-in displays with a webcam 536422-001 Display bezel for use on computers with 14.0-in displays without a webcam 536423-001 Display bezel for use on computers with 14.0-in displays with a webcam 536424-001...
Page 62 Spare part Description number 536537-A41 Keyboard for use in Europe on computers with 15.6-in displays 536537-AB1 Keyboard for use in Taiwan on computers with 15.6-in displays 536537-AD1 Keyboard for use in South Korea on computers with 15.6-in displays 536537-B31 Keyboard for International use on computers with 15.6-in displays 536537-B71 Keyboard for use in Europe on computers with 15.6-in displays 536537-BA1...
Page 63 Spare part Description number 572727-001 Palm rest for use in red computers with 14.0-in displays (includes TouchPad) 572728-001 Palm rest for use in red computers with 15.6-in displays (includes TouchPad) 572747-001 AMD Athlon QL-66, 2.2-GHz processor with 1-GB L2 cache (for use only with the following system boards: 574505-001, 574506-001, 585802-001, 585803-001) 572748-001 AMD Turion RM-76, 2.3-GHz processor with 1-GB L2 cache (for use only with the following system boards:...
Page 64 Spare part Description number 585218-001 System board for use in computers with a WWAN module and UMA graphics subsystem memory that use AMD Mxxx processors 585219-001 System board for use in computers without a WWAN module and UMA graphics subsystem memory that use AMD Mxxx processors 585220-001 System board for use in computers with a WWAN module and discrete graphics subsystem memory that use...
Page 65: Removal And Replacement Procedures
Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: ● Flat-bladed screwdriver ● Phillips P0 and P1 screwdrivers ● Torx T8 screwdriver Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.
Page 66: Cables And Connectors
Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.
Page 67: Grounding Guidelines
Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.
Page 68: Packaging And Transporting Guidelines
Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
Page 69: Equipment Guidelines
Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.
Page 70: Component Replacement Procedures
Component replacement procedures This section provides removal and replacement procedures. There are as many as 121 screws, in 12 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement.
Page 71: Computer Feet
Computer feet The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 535793-001. There are 8 rubber feet that attach to the base enclosure in the locations illustrated below. Component replacement procedures Download from Www.Somanuals.com.
Page 72: Battery
Battery Description Spare part number 8-cell, 63-Wh Li-on battery for use in computers with 15.6-in displays 535753-001 6-cell, 47-Wh Li-on battery for use in computers with 15.6-in displays 536418-001 6-cell, 47-Wh Li-on battery for use in computers with 14.0-in displays 572032-001 Before disassembling the computer, follow these steps: Shut down the computer.
Page 73: Switch Cover And Keyboard
Switch cover and keyboard Description Spare part number Switch covers For use in black computers with 15.6-in displays 535861-001 For use in red computers with 15.6-in displays 572726-001 For use in black computers with 14.0-in displays 535860-001 For use in red computers with 14.0-in displays 572725-001 Keyboards for use in computers with 15.6-in displays 536537-xxx...
Page 74 To remove the switch cover on 15.6-in models, remove the following screws: (1) Two screw covers and two PM2.5×3.0 screws (2) Five PM2.5×3.0 broadhead screws (15.6-in models) (3) Two PM2.0×3.0 screws – or – To remove the switch cover on 14.0-in models, remove the following screws: (1) Two screw covers and two PM2.5×3.0 screws (2) Two PM2.5×3.0 broadhead screws (3) Two PM2.0×3.0 screws...
Page 75 Slide the switch cover back (1), and then lift it off the computer (2). On computers with 15.6-in displays, remove the two Phillips PM2.5×3.0 screws that secure the keyboard to the computer. – or – On computers with 14.0-in displays, remove the three Phillips PM2.5×3.0 screws that secure the keyboard to the computer.
Page 76 Slide the keyboard back toward the display (1), and then rotate it forward (2) to gain access to the keyboard cable connector. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and disconnect the keyboard cable (2) from the system board. Remove the keyboard.
Page 77: Memory Module
Memory module Description Spare part number 2-GB (PC2-6400, 800-MHz, DDR2) 535810-001 1-GB (PC2-6400,800-MHz, DDR2) 535809-001 Before removing the memory module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
Page 78: Optical Drive
Optical drive NOTE: All optical drive spare part kits include an optical drive bezel. Description Spare part number DVD±RW Double-Layer Drive with LightScribe 535816-001 Blu-ray ROM DVD+/-RW SuperMulti DL Drive 535817-001 DVD-ROM Drive 535815-001 Before removing the optical drive, follow these steps: Shut down the computer.
Page 79 Remove the optical drive (3) from the computer. NOTE: 15.6-in model shown below NOTE: 14.0-in model shown below If it is necessary to replace the optical drive bracket, position the optical drive with the rear toward you. Remove the two Phillips PM2.0×3.0 screws (1) that secure the optical drive bracket to the optical drive.
Page 80 Remove the optical drive bracket (2). Reverse this procedure to reassemble and install the optical drive. Chapter 4 Removal and replacement procedures Download from Www.Somanuals.com. All Manuals Search And Download.
Page 81: Speakers
Speakers Description Spare part number For use in computers with 15.6-in displays 536598-001 For use in computers with 14.0-in displays 536420-001 Before removing the speaker, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
Page 82: Wwan Module
WWAN module Description Spare part number WWAN module for use in all countries and regions except China 483377-002 WWAN module for use in China 571888-001 WWAN module, including GPS, UNDP (United Nations Development Program; not available with 531993-001 Linux) CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region.
Page 83: Palm Rest
Remove the WWAN module (3) by pulling the module away from the slot at an angle. NOTE: WWAN modules are designed with a notch (4) to prevent incorrect insertion. Reverse this procedure to install the WWAN module. Palm rest Description Spare part number Palm rest for use in black computers with 15.6-in displays (includes TouchPad) 535868-001...
Page 84 On 15.6-in models: Remove the two Phillips PM2.5×3.0 broadhead screws (1) that secure the palm rest to the computer. Slide the palm rest back toward the display (2), and then lift and rotate the front edge (3) to gain access to the TouchPad cable. –...
Page 85 Release the ZIF connector (1) to which the TouchPad cable is connected, and then disconnect the TouchPad cable (2) from the system board. Remove the palm rest. Reverse this procedure to install the palm rest. Component replacement procedures Download from Www.Somanuals.com. All Manuals Search And Download.
Page 86: Hard Drive
Hard drive NOTE: The hard drive spare part kit includes a hard drive bracket. Description Spare part number 500-GB, 7200-rpm hard drive (for use only in models with the following system boards: 535803-001, 575125-001 574505-001, 574506-001) 500-GB, 5400-rpm hard drive 535814-001 320-GB, 7200-rpm hard drive 575124-001...
Page 87 Remove the hard drive (4) from the hard drive bay. If it is necessary to replace the hard drive bracket, remove the two Phillips PM3.0×4.0 hard drive bracket screws (1) from each side of the hard drive. Lift the bracket (2) straight up to remove it from the hard drive. Reverse this procedure to reassemble and install the hard drive.
Page 88: Wlan Module
WLAN module Description Spare part number Broadcom 4322 802.11a/b/g/n WLAN modules: ● For use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam, 504664-001 Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States ● For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, 504664-002 Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados,...
Page 89 Before removing the WLAN module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 90: Display Assembly On Computers With 15.6-In Displays
Display assembly on computers with 15.6-in displays NOTE: For information about removing the display from 14.0-in models, see Display assembly on computers with 14.0-in displays on page NOTE: The display assembly spare part kit includes 2 WLAN antenna transceivers and cables. Description Spare part number For use only with black computers with 15.6-in HD displays...
Page 91 Remove the display cables: Position the computer right-side up with the front toward you. Open the computer as far as possible. Disconnect the display panel/webcam cable assembly (1) from the system board. Remove the microphone module cable from the routing path (2), and then disconnect the cable (3) from the system board.
Page 92 If it is necessary to replace the display bezel, display enclosure, or display hinges, remove the eight rubber screw covers (1) and the eight Phillips PM2.0×6.0 screws (2) that secure the display bezel to the display assembly. The rubber screw covers are available in the Rubber Kit, spare part number 535793-001.
Page 93 If it is necessary to replace the webcam module from the display enclosure, gently pull the webcam module away from the double-sided tape on the display enclosure (1), disconnect the webcam cable from the module (2), and then remove the webcam. The webcam module is available using spare part number 535797-001.
Page 94 Remove the display hinges (2). The left and right display hinges are available in the Display Hinge Kit, spare part number 535872-001 for computers with 15.6-in displays. If it is necessary to replace the display/webcam cable: NOTE: The display cable and webcam cable are bound together as one cable assembly. On the back of the display panel, peel back the tape that secures the display cable to the display panel (1), and then disconnect the cable from the connector on the back of the display panel (2).
Page 95 Reverse this procedure to reassemble and install the display assembly. Component replacement procedures Download from Www.Somanuals.com. All Manuals Search And Download.
Page 96: Top Cover
Top cover NOTE: The top cover removal procedures differ for 15.6-in computers from those of 14.0-in computers. NOTE: You must remove the top cover before you can remove the display assembly on computers with 14.0-in displays. You do not have to remove the top cover to remove the display assembly on computers with 15.6-in displays.
Page 97 Disconnect the power button board cable from the system board by releasing the ZIF connector (1), and then disconnecting the cable (2). Remove the 19 Phillips PM2.5×6.0 screws that secure the top cover to the computer. Remove the two Phillips PM2.0×4.0 screws (1) and the three Phillips PM2.0×2.0 screws (2) that secure the top cover to the computer.
Page 98 Lift the front edge (1) of the top cover until it disengages from the base enclosure, release the top cover from the sides and rear of the base enclosure, and then remove the top cover (2). Remove the top cover. NOTE: Steps 6 through 10 illustrate how to remove the top cover from computers with 14.0-in displays.
Page 99 Remove the 21 PM2.5×6.0 screws that secure the top cover to the computer. NOTE: Two of these screws (one of each side) also secure the display panel to the computer. Remove the Phillips PM2.0×4.5 screw that secures the top cover to the computer. Lift the top cover until is disengages from the base enclosure (1).
Page 100: Power Button Board
Power button board Description Spare part number Power button board for use in computers with 15.6-in displays (includes cable) 574513-001 Power button board for use in computers with 14.0-in displays (includes cable) 574514-001 Before removing the power button board, follow these steps: Shut down the computer.
Page 101 Lift the board straight up and off the top cover. NOTE: Computer with 15.6-in display shown. Reverse this procedure to install the power button board. Component replacement procedures Download from Www.Somanuals.com. All Manuals Search And Download.
Page 102: Rtc Battery
RTC battery Description Spare part number RTC battery 449137-001 Before removing the RTC battery, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
Page 103: Display Assembly On Computers With 14.0-In Displays
Display assembly on computers with 14.0-in displays NOTE: For information about removing the display from 15.6-in models, see Display assembly on computers with 15.6-in displays on page NOTE: The display assembly spare part kit includes two WLAN antenna transceivers and cables. Description Spare part number For use only with black computers with 14.0-in HD displays...
Page 104 NOTE: When replacing the display assembly, only replace the four bottom screws in the display brackets. The top screw on the bracket on each side is replaced when you install the top cover. Lift the display assembly up and off the computer (2). If it is necessary to replace the display bezel, display enclosure, or display hinges, remove the eight rubber screw covers (1) and the eight Phillips PM2.5×6.0 screws (2) that secure the display bezel to the display assembly.
Page 105 Lift the bezel at the seam in the hinges until it disengages from the display enclosure (5). Remove the bezel from the display enclosure. The display bezel is available using spare part numbers 536423-001 on computers with 14.0-in displays and a webcam and 536422-001 on computers with 14.0-in displays and no webcam. If it is necessary to replace the webcam module from the display enclosure, gently pull the webcam module away from the double-sided tape on the display enclosure (1) and disconnect the webcam cable from the module (2).
Page 106 Lift the bottom of the panel (2) to remove it from the enclosure. Remove the six Phillips PM2.0×3.0 screws (1) that secure the display hinges to the display panel. Remove the display hinges (2). The left and right display hinges are available in the Display Hinge Kit, spare part number 535871-001 for computers with 14.0-in displays.
Page 107 If it is necessary to replace the webcam cable from the display enclosure, gently pull the webcam cable (1) from the clips and routing channels (2) built into the top cover. The webcam cable is included in the Display Cable Kit, spare part numbers 536430-001 for computers with 14.0-in displays.
Page 108: Bluetooth Module
Bluetooth module NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is included in the Cable Kit, spare part number 536539-001 for computers with 15.6-in displays, 536538-001 for computers with 14.0-in displays. See Cable Kit on page 43 for more Cable Kit spare part number information.
Page 109: Modem Module
Remove the Bluetooth module (3) from the base enclosure. Reverse this procedure to install the Bluetooth module. Modem module Description Spare part number For use in all countries and regions except Australia and New Zealand 510100-001 For use only in Australia and New Zealand 510100-011 Before removing the modem module, follow these steps: Shut down the computer.
Page 110: Usb Connector Assembly
Remove the modem module: Position the computer right-side up with the front toward you. Remove the two Phillips PM2.5×3.0 screws (1) that secure the modem module to the system board. Lift the modem module (2) straight up to disconnect it from the system board. Remove the tape (3) that secures the cable to the modem module, and then disconnect the modem module cable (4).
Page 111 Hard drive (see Hard drive on page Display assembly (see Display assembly on computers with 15.6-in displays on page 78 Display assembly on computers with 14.0-in displays on page Top cover (see Top cover on page Remove the USB connector assembly: Position the computer right-side up with the right side toward you.
Page 112: Heat Sink And Fan
Heat sink and fan NOTE: The heat sink spare part kit includes replacement thermal material. Description Spare part number Heat sink for use in computers with UMA graphics subsystems 535804-001 Heat sink for use in computers with discrete graphics subsystems 535805-001 535766-001 Before removing the heat sink, follow these steps:...
Page 113 Remove the heat sink (9). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the system board (1), (2), and (3), and the heat sink components (4), (5), and (6) each time the heat sink is removed. Replacement thermal material is included with all heat sink, system board, and processor spare part kits.
Page 114 Remove the heat sink (7). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the system board (1) and (2) and the heat sink components (3) and (4) each time the heat sink is removed. Replacement thermal material is included with all heat sink, system board, and processor spare part kits.
Page 115 If it is necessary to remove the fan from the heat sink, remove the three Phillips PM2.0×3.0 screws (1) that secure the fan to the heat sink, and then remove the fan from the heat sink (2). Reverse this procedure to install the heat sink. Component replacement procedures 103 Download from Www.Somanuals.com.
Page 116: Processor
Processor NOTE: The processor spare part kit includes replacement thermal material. Description Spare part number AMD Turion II Ultra Dual-Core processors (for use only with the following system boards: 585218-001, 585219-001, 585220-001, 585221-001) M500 (2.2-GHz with 1-MB L2 cache) 576253-001 M520 (2.3-GHz with 1-MB L2 cache) 583055-001 M600 (2.4-GHz with 2-MB L2 cache)
Page 117 Remove the battery (see Battery on page 60). Remove the following components: Switch cover and keyboard (see Switch cover and keyboard on page Optical drive (see Optical drive on page Speakers (see Speakers on page Palm rest (see Palm rest on page Top cover (see Top cover on page Remove the processor:...
Page 118: System Board
System board NOTE: The system board spare part kit includes replacement thermal material. Description Spare part number System board for use in computers with a WWAN module that use AMD Mxxx processors UMA graphics subsystem memory 585218-001 Discrete graphics subsystem memory 585220-001 System board for use in computers without a WWAN module that use AMD Mxxx processors UMA graphics subsystem memory...
Page 119 When replacing the system board, be sure that the following components are removed from the defective system board and installed on the replacement system board: ● Memory module (see Memory module on page ● WLAN module (see WLAN module on page ●...
Page 120: Sim
Remove the system board from the base enclosure (2). (15.6-in models only) If it is necessary to remove the optical drive connector board from the system board, pull the optical drive connector board straight off the system board. The optical drive connector board is available using spare part number 535862-001.
Page 121 Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer. Remove the battery (see Battery on page 60). Remove the following components: Switch cover and keyboard (see Switch cover and keyboard on page Optical drive (see Optical drive on page...
Page 122: Computer Setup
Computer Setup Computer Setup in Windows Vista and Windows XP Starting Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.
Page 123: Restoring Factory Settings In Computer Setup
NOTE: You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the keyboard to navigate and make selections in Computer Setup. Press to enter BIOS Setup. Select the File, Security, Diagnostics, or System Configuration menu. To exit Computer Setup menus, choose one of the following methods: ●...
Page 124: File Menu
NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select To do this ● System Information View identification information for the computer and the batteries in the system. ●...
Page 125: Security Menu
Enable/disable reset of HP ProtectTools security keys. Change Password Enter, change, or delete a BIOS administrator password. HP SpareKey Enrollment Enroll or reset HP SpareKey, which is a set of security questions and answers used if you forget your password. DriveLock Passwords ●...
Page 126: Diagnostics Menu
Diagnostics menu Select To do this System Diagnostics Menu ● System Information—Displays the following information: ◦ Identification information for the computer and the batteries in the system. ◦ Specification information for the processor, cache and memory size, system ROM, video revision, and keyboard controller version.
Page 127: System Configuration Menu
◦ IDE (Integrated Drive Electronics) NOTE: Availability of the options above varies by computer model. ● Enable/disable HP QuickLook 2 (enabled by default). ● Enable/disable Virtualization Technology (select models only; disabled by default). ● Enable/disable Dual-Core CPU (enabled by default).
Page 128 Select To do this ● Built-In Device Options Enable/disable the wireless button state (enabled by default). ● Enable/disable embedded WWAN device radio (enabled by default). ● Enable/disable embedded Bluetooth® device radio (enabled by default). ● Enable/disable the Network Interface Controller (LAN) (enabled by default).
Page 129: Computer Setup In Linux
Computer Setup in Linux Starting Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.
Page 130: Using Computer Setup
Using Computer Setup Navigating and selecting in Computer Setup The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and System Configuration menus. Open Computer Setup by turning on or restarting the computer, and then pressing while the "F10 = ROM Based Setup"...
Page 131: Computer Setup Menus
Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select To do this ●...
Page 132: Security Menu
Security menu NOTE: Some of the menu items listed in this section may not be supported by your computer. Select To do this Setup Password Enter, change, or delete a setup password. Power-On Password Enter, change, or delete a power-on password. Password Options ●...
Page 133: System Configuration Menu
System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select To do this Language Change the Computer Setup language. ● Boot options Set an f9, f10, and delay when starting up. ●...
Page 134 Select To do this ● Built-in device options Enable/disable embedded WLAN Device Radio. ● Enable/disable embedded Bluetooth Device Radio. ● Enable/disable Network Interface Controller (NIC) ● Enable/disable LAN/WLAN Switching. ● Enable/disable Wake on LAN. ● Enable/disable the integrated camera (webcam) Port options ●...
Page 135: Specifications
Specifications Computer specifications Metric U.S. Dimensions Depth (14.0-in models) 23.24 cm 9.15 in Depth (15.6-in models) 24.96 cm 9.83 in Width (14.0-in models) 33.60 cm 13.2 in Width (15.6-in models) 37.18 cm 14.6 in Height (front to rear) (14.0-in models) 3.10 to 3.58 cm 1.24 to 1.41 in Height (front to rear) (15.6-in models)
Page 136: 14.0-In Wxga Display Specifications
Metric U.S. Nonoperating 200 g, 2 ms, half-sine Random vibration Operating 0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep rate Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures.
Page 137: In Wxga Display Specifications
15.6-in WXGA display specifications Metric U.S. Dimensions Height 20.7 cm 8.1 in Width 33.1 cm 13.0 in Diagonal 39.1 cm 15.6 in Number of colors Up to 16.8 million Contrast ratio 300:1 (typical) Brightness 200 nits (typical) Pixel resolution Pitch 0.259 ×...
Page 138: Hard Drive Specifications
Hard drive specifications 500-GB* 320-GB* 250-GB* 160-GB* Dimensions Height 9.5 mm 9.5 mm 9.5 mm 9.5 mm Width 70 mm 70 mm 70 mm 70 mm Weight 101 g 101 g 101 g 101 g Interface type SATA SATA SATA SATA Transfer rate 100 MB/sec...
Page 139: Dvd±Rw Double-Layer Combo Drive Specifications
DVD±RW Double-Layer Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD- CD-R and CD-RW ROM, CD-ROM XA, MIXED MODE CD, CD-I, DVD+R, DVD+RW, DVD-R, DVD- CD-I Bridge (Photo-CD, Video CD), Multisession RW, DVD-RAM CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD- RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM...
Page 140: Blu-Ray Rom Dvd+/-Rw Supermulti Dl Drive
Blu-ray ROM DVD+/-RW SuperMulti DL Drive Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-R and CD-RW DVD+R, DVD+R (9), CD-ROM, CD-ROM XA, DVD+RW, DVD-R, DVD-R (9), DVD-RW, MIXED MODE CD, CD-I, CD-I Bridge DVD-RAM (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD- R, CD-RW), CD-R, CD-RW, DVD- ROM (DVD-5, DVD-9, DVD-10,...
Page 141: Dvd-Rom Drive
DVD-ROM Drive Applicable disc DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18, CD-ROM (Mode 1 and 2), CD Digital Audio, CD-XA ready (Mode 2, Form 1 and Form 2), CD-I (Mode 2, Form 1 and Form 2), CD-R, CD-RW, Photo CD (single and multisession), CD-Bridge Access time Random <...
Page 142: System Dma Specifications, Windows Vista And Xp
Microsoft ACPI-Compliant System ISA15 ATA Channel 1 ISA150 - ISA190 Microsoft ACPI-Compliant System ISA23 HP Mobile Data Protection Sensor ISA81 - ISA99 Microsoft ACPI-Compliant System PCI16 Intel ICH9 Family USB Universal Host Controller – 2937 PCI16 Mobile Intel 4 Series Express Chipset Family PCI17 Broadcom 802.11b/g WLAN...
Page 143: System Interrupt Specifications, Windows Xp
Microsoft ACPI-Compliant System ISA12 Synaptics PS/2 TouchPad ISA13 Numeric data processor ISA23 HP Mobile Data Protection Sensor PCI16 Intel ICH9 Family USB Universal Host Controller – 2937 PCI16 Mobile Intel 4 Series Express Chipset Family PCI17 Broadcom 4322AG 802.11a/b/g/draft-n Wi-Fi Adapter...
Page 144: System I/O Address Specifications, Windows Vista
System timer 04E - 04F Motherboard resources 050 - 053 System timer 060 - 060 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QLB 061 - 061 Motherboard resources 062 - 062 Microsoft ACPI-Compliant Embedded Controller 063 - 063...
Page 145 I/O address (hex) System function (shipping configuration) 0B2 - 0B3 Motherboard resources 0B4 - 0B5 Programmable interrupt controller 0B8 - 0B9 Programmable interrupt controller 0BC - 0BD Programmable interrupt controller 0C0 - 0DF Direct memory access controller 0F0 - 0F0 Numeric data processor 170 - 177 ATA Channel 1...
Page 146: System I/O Address Specifications, Windows Xp
System timer 04E - 04F Motherboard resources 050 - 053 System timer 060 - 060 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QLB 061 - 061 Motherboard resources 062 - 062 Microsoft ACPI-Compliant Embedded Controller 063 - 063...
Page 147 I/O address (hex) System function (shipping configuration) 070 - 070 Motherboard resources 070 - 077 System CMOS/real time clock 080 - 080 Motherboard resources 081 - 091 Direct memory access controller 092 - 092 Motherboard resources 093 - 09F Direct memory access controller 0A0 - 0A1 Programmable interrupt controller 0A4 - 0A5...
Page 148: System Memory Map Specifications, Windows Vista
I/O address (hex) System function (shipping configuration) 7020 - 703F Intel ICH9 Family USB Universal Host Controller – 2936 7040 - 705F Intel ICH9 Family USB Universal Host Controller – 2935 7060 - 707F Intel ICH9 Family USB Universal Host Controller – 2934 7080 - 709F Intel ICH9 Family USB Universal Host Controller –...
Page 149: System Memory Map Specifications, Windows Xp
Memory address System function 98904000-989043FF Intel ICH9 Family USB2 Enhanced Host Controller – 293A 98904400-989047FF Intel ICH9 Family USB2 Enhanced Host Controller – 293C E0000000-EFFFFFFF Motherboard resources F0000000-FEDFFFFF High precision event timer FEC00000-FEC00FFF Motherboard resources FED00000-FED003FF Motherboard resources FED10000-FED13FFF Motherboard resources FED18000-FED18FFF Motherboard resources FED1C000-FED1FFFF...
Page 150 Memory address System function 58904000-589047FF Intel ICM9M-E/M SATA AHCI Controller 58904800-58904BFF Intel ICH9 Family USB2 Enhanced Host Controller – 293A 58904C00-58904FFF Intel ICH9 Family USB2 Enhanced Host Controller – 293C E0000000-EFFFFFFF Motherboard resources F0000000-FEDFFFFF PCI Bus FEC00000-FEC00FFF Motherboard resources FED00000-FED003FF High Precision Event Timer FED10000-FED13FFF Motherboard resources...
Page 151: Screw Listing
Screw listing This chapter provides specification and reference information for the screws used in the computer. All screws listed in this section are available in the Screw Kit, spare part number 535870-001. Torx T8M2.5×6.0 screw Color Quantity Length Thread Head diameter Silver 6.0 mm 2.5 mm...
Page 152: Torx T8M2.5×4.0 Screw
Torx T8M2.5×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 2.5 mm 5.0 mm Where used: 2 screws that secure the top cover to computers equipped with 15-in displays 140 Chapter 7 Screw listing Download from Www.Somanuals.com. All Manuals Search And Download.
Page 153: Phillips Pm2.0×2.0 Screw
Phillips PM2.0×2.0 screw Color Quantity Length Thread Head diameter Black 2.0 mm 2.0 mm 5.0 mm Where used: 3 screws that secure the top cover to the computer Phillips PM2.0×2.0 screw 141 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 154: Phillips Pm2.0×3.0 Screw
Phillips PM2.0×3.0 screw Color Quantity Length Thread Head diameter Silver 3.0 mm 2.0 mm 5.0 mm Where used: 2 screws that secure the optical drive bracket to the optical drive Where used: 8 screws that secure the display hinges to the 15-in display assembly 142 Chapter 7 Screw listing Download from Www.Somanuals.com.
Page 155 Where used: 6 screws that secure the display hinges to the 14-in display assembly Where used: 3 screws that secure the fan to the heat sink Phillips PM2.0×3.0 screw 143 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 156: Phillips Pm2.0×3.0 Screw
Phillips PM2.0×3.0 screw Color Quantity Length Thread Head diameter Black 3.0 mm 2.0 mm 5.0 mm Where used: 2 screws that secure the switch cover to computers with 14-in displays 144 Chapter 7 Screw listing Download from Www.Somanuals.com. All Manuals Search And Download.
Page 157: Phillips Pm2.5×6.0 Screw
Phillips PM2.5×6.0 screw Color Quantity Length Thread Head diameter Black 15 (15-in models) or 30 6.0 mm 2.5 mm 5.0 mm (14-in models) Where used: (1) Six screws that secure the 15-in display to the computer (2) One screw that secures the optical drive to the computer Phillips PM2.5×6.0 screw 145 Download from Www.Somanuals.com.
Page 158: Phillips Pm2.5×11.0 Captive Screw
Where used: 8 screws that secure the display bezel to the display enclosure Where used: 21 screws that secure the top cover to the base enclosure on computers with 14-in displays Phillips PM2.5×11.0 captive screw Color Quantity Length Thread Head diameter Black 11.0 mm 2.5 mm...
Page 159: Phillips Pm3.0×4.0 Screw
Phillips PM3.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 3.0 mm 5.0 mm Where used: 4 screws that secure the hard drive bracket to the hard drive Phillips PM3.0×4.0 screw 147 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 160: Phillips Pm2.0×4.0 Screw
Phillips PM2.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 2.0 mm 5.0 mm Where used: 2 screws that secure the hard drive to the computer Where used: 2 screws that secure the top cover to the computer 148 Chapter 7 Screw listing Download from Www.Somanuals.com.
Page 161: Phillips Pm2.5×3.0 Screw
Phillips PM2.5×3.0 screw Color Quantity Length Thread Head diameter Black 17 (15-in models) or 18 3.0 mm 2.5 mm 5.0 mm (14-in models) Where used: 2 screws that secure the WLAN module to the system board Phillips PM2.5×3.0 screw 149 Download from Www.Somanuals.com.
Page 162 Where used: 2 screws that secure the WWAN module to the system board Where used: 2 screws that secure the modem module to the system board Where used: 2 screws that secure the switch cover to the computer Where used: 2 screws that secure the keyboard to computers with 15-in displays 150 Chapter 7 Screw listing Download from Www.Somanuals.com.
Page 163 Where used: 3 screws that secure the keyboard to computers with 14-in displays Where used: 4 screws that secure the speakers to the computer Where used: One screw that secures the USB connector assembly to the computer Phillips PM2.5×3.0 screw 151 Download from Www.Somanuals.com.
Page 164 Where used: 2 screws that secure the SIM to the computer 152 Chapter 7 Screw listing Download from Www.Somanuals.com. All Manuals Search And Download.
Page 165: Phillips Pm2.5×4.5 Screw
Phillips PM2.5×4.5 screw Color Quantity Length Thread Head diameter Black 4 (15-in models) or 4.5 mm 2.5 mm 5.0 mm 7 (14-in models) Where used: 4 screws that secure the display assembly to computers with 14-in displays Where used: 4 screws that secure the display panel to the 15-in display enclosure Phillips PM2.5×4.5 screw 153 Download from Www.Somanuals.com.
Page 166 Where used: 2 screws that secure the display bezel to the 14-in display enclosure Where used: One screw in the right rear that secures the top cover to computers with 14-in displays 154 Chapter 7 Screw listing Download from Www.Somanuals.com. All Manuals Search And Download.
Page 167: Phillips Pm2.5×3.0 Broadhead Screw
Phillips PM2.5×3.0 broadhead screw Color Quantity Length Thread Head diameter Black 9 (15-in models) or 3.0 mm 2.5 mm 7.0 mm 5 (14-in models) Where used: 2 screws that secure the system board to computers with 15-in displays Where used: 3 screws that secure the system board to computers with 14-in displays Phillips PM2.5×3.0 broadhead screw 155 Download from Www.Somanuals.com.
Page 168 Where used: 5 screws that secure the switch cover to computers with 15-in displays Where used: 2 screws that secure the switch cover and power button board to the computer 156 Chapter 7 Screw listing Download from Www.Somanuals.com. All Manuals Search And Download.
Page 169: Phillips Pm2.5×7.0 Screw
Phillips PM2.5×7.0 screw Color Quantity Length Thread Head diameter Black 7.0 mm 2.5 mm 5.0 mm Where used: One screw that secures the USB connector assembly to the computer Phillips PM2.5×7.0 screw 157 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 170: Phillips Pm2.5×9.0 Captive Screw
Phillips PM2.5×9.0 captive screw Color Quantity Length Thread Head diameter Silver 7 (discrete) or 5 (UMA) 9.0 mm 2.5 mm 5.0 mm Where used: 7 screws that secure the heat sink to the system board for computers with discrete memory 158 Chapter 7 Screw listing Download from Www.Somanuals.com.
Page 171 Where used: 5 screws that secure the heat sink to the system board for computers with UMA memory Phillips PM2.5×9.0 captive screw 159 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 172: Backup And Recovery
NOTE: For detailed instructions, perform a search for these topics in Help and Support. NOTE: In case of system instability, HP recommends that you print the recovery procedures and save them for later use. Backing up your information Recovery after a system failure is as complete as your most current backup. You should create your initial backup immediately after software setup.
Page 173: Performing A Recovery
To create a screen shot: Display the screen you want to save. Copy the screen image: To copy only the active window, press alt+fn+prt sc. To copy the entire screen, press fn+prt sc. Open a word-processing document, and then select Edit > Paste. The screen image is added to the document.
Page 174: Using The Windows Recovery Tools
If possible, back up all personal files. If possible, check for the presence of the Windows partition and the HP Recovery partition. To find the partitions, select Start > Computer. NOTE:...
Page 175: Using A Windows Vista Operating System Dvd (Purchased Separately)
(stored on discs or on an external drive) is easily accessible. To order a Windows Vista operating system DVD, go to http://www.hp.com/support, select your country or region, and follow the on-screen instructions. You can also order the DVD by calling technical support. For contact information, refer to the Worldwide Telephone Numbers booklet included with the computer.
Page 176: Backup And Recovery In Windows Xp
NOTE: For detailed instructions, perform a search for these topics in Help and Support. NOTE: In case of system instability, HP recommends that you print the recovery procedures and save them for later use. Backing up your information Recovery after a system failure is as complete as your most current backup. You should create your initial backup immediately after software setup.
Page 177: Performing A Recovery
The recovery process reinstalls the original operating system, software, and drivers. Software, drivers, and updates not installed by HP must be manually reinstalled. To recover your operating system and programs, follow these steps: If possible, back up all personal files.
Page 178: Connector Pin Assignments
Connector pin assignments Audio-in (microphone) Signal Audio signal in Audio signal in Ground Audio-out (headphone) Signal Audio out, left channel Audio out, right channel Ground 166 Chapter 9 Connector pin assignments Download from Www.Somanuals.com. All Manuals Search And Download.
Page 179: External Monitor
External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor 167 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 180: Modem)
RJ-11 (modem) Signal Unused Ring Unused Unused Unused 168 Chapter 9 Connector pin assignments Download from Www.Somanuals.com. All Manuals Search And Download.
Page 181: Network)
RJ-45 (network) Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused Universal Serial Bus Signal +5 VDC Data - Data + Ground RJ-45 (network) 169 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 182: 10 Power Cord Set Requirements
10 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.
Page 183: Requirements For Specific Countries And Regions
Requirements for specific countries and regions Country/region Accredited agency Applicable note number Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland FIMKO France Germany Italy Japan METI The Netherlands KEMA Norway NEMKO The People's Republic of China South Korea Sweden SEMKO Switzerland Taiwan...
Page 184: 11 Recycling
When you remove these components, handle them carefully. NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display assembly that might require special handling at end-of-life. Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, contact your local authorities, or see the Electronic Industries Alliance (EIA) Web site at http://www.eiae.org.
Page 185 Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.
Page 186 Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside-down. Remove all screws that secure the display panel frame to the display panel.
Page 187 Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.
Page 188 Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside-down. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. Remove the backlight frame from the display panel.
Page 189 Remove the backlight from the backlight frame. Disconnect the display panel cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.
Page 190 Index Blu-ray ROM DVD+/-RW components AC adapter SuperMulti DL Drive additional hardware 20, 32 identifying 20, 32 spare part number 39, 48, bottom 19, 30 spare part numbers 45, 46, display 10, 21 specifications 128 front 16, 27 antenna, disconnecting 70, 77 Bluetooth cable, illustrated 43 left-side 18, 29 applications key, Windows 14,...
Page 191 Ethernet, product description 4 HP QuickLook 2 115 removal 78, iii Execution Disable 115 HP SpareKey enrollment 113 spare part numbers 34, 35, ExpressCard slot bezel, 50, 51, 78, iii illustrated 42 I/O address specifications display bezel ExpressCard slot, identifying 18,...
Page 192 lights precautions 54 power button board battery 17, 28 product description 4 illustrated 43 caps lock 12, 23 removal 66 removal 88 drive 16, 27 spare part number 39, 44, spare part number 39, 51, Info 12 Info Center/QuickLook 23 specifications 127, 128, 129 power button, identifying 13, 24 optical drive 17, 28...
Page 193 124, 125 TouchPad, identifying 11, 22 DVD-ROM Drive 129 Security menu transporting guidelines 56 DVD±RW Double-Layer Drive allow reset of HP ProtectTools with LightScribe 127 security keys 113 hard drive 126 Unified Extensible Firmware always prompt for HP SpareKey...
Page 194 USB legacy support 110, 115, 117, 121 USB port identifying 17, 18, 28, 29 pin assignments 169 vents, identifying 18, 29 Virtualization Technology 115 webcam identifying 10, 21 removing 81, 93 spare part number 41, 47, 81, 93 webcam light, identifying 10, 21 Windows applications key, identifying 14, 15 Windows Backup utility 164, 165...
Page 195 Download from Www.Somanuals.com. All Manuals Search And Download.
Page 196 Free Manuals Download Website h p://myh66.com h p://usermanuals.us h p://www.somanuals.com h p://www.4manuals.cc h p://www.manual-lib.com h p://www.404manual.com h p://www.luxmanual.com h p://aubethermostatmanual.com Golf course search by state h p://golﬁngnear.com Email search by domain h p://emailbydomain.com Auto manuals search h p://auto.somanuals.com TV manuals search h p://tv.somanuals.com...

This manual is also suitable for:

Probook 4415s Probook 4515s

HP ProBook 4416s Maintenance And Service Manual

Quick Links

Need help?

Questions and answers

Related Manuals for HP ProBook 4416s

Summary of Contents for HP ProBook 4416s

This manual is also suitable for:
