- Page 1 USER GUIDE ELLIPSE AURA™ (for aftermarket installed systems)
-
Page 2: Read Me First
Read Me First!! To experience the benefits of Aura, you must first upload Images into the preamp. • Install the Aura Gallery 2.0 CD on your PC. • Connect the Aura product to the computer with the supplied USB cable and follow the onscreen instructions to upload Images. - Page 3 Image Chart Once you upload Images into your Ellipse Aura, fill in this chart for quick reference. Image # Instrument Name Microphone Mic Distance READ ME! This product is meant to be installed only by a qualified professional guitar technician. Instructions for professional...
- Page 4 Fundamentals To experience the benefits of Aura, install the Aura Gallery CD on your computer then upload Images into the Ellipse Aura preamp.
-
Page 5: Quick Start
Quick Start After you upload Images into the preamp, set the controls as illustrated:... - Page 6 1. Plug In • Connect the Ellipse Aura to your amplifier or PA with a ¼-inch instrument cable. 2. Select an Image • Raise the Volume and use the Image switch to browse through the four Images until you find one you prefer.
- Page 7 Power Plug in the guitar, and the Ellipse Aura switches on. To conserve battery life, remove the instrument cable from the guitar when the system is not used. When you plug in, the Battery LED flashes once to indicate power up.
-
Page 8: Battery Replacement
Battery Replacement When the Battery LED lights steadily, it is time to change the battery. To replace the battery, remove the fabric bag inside the guitar. We recommend a lithium type for extended battery life. You can expect up to hours from a lithium battery and 33 hours from an alkaline battery. - Page 9 Controls The controls are arranged in two distinct levels. Once your fingers are familiar with the layout, you will be able to easily adjust the controls, even when you can’t see them.
- Page 10 1. Blend Use the Blend slider to adjust the balance between the pickup and the Image. You’ll attain a more microphone-like sound by favoring the Image. Note that it is often practical to blend in a higher percentage of the pickup in live situations, especially when you desire a more focused amplified tone.
- Page 11 Measure button again. If you plan to record with the Ellipse Aura, we recommend you turn off the Anti-Feedback to fill out the natural low-end response of the guitar.
- Page 12 5. Image Switch Select one of the four Images you’ve uploaded from the Aura Gallery (see page 3). Note that to experience the benefits of Aura, you must first upload Images into the preamp. 6. Voicing Switch This switch selects how the pickup is voiced. Move the Voicing Switch to the left for bass boost and to the right for a flat response.
-
Page 13: Performance Tips
You will benefit from complete isolation for your guitar with no microphone bleed, so when you record live, no other sounds can leak into your guitar track. The best recordings we’ve heard with Ellipse Aura have some pickup mixed in for better definition. - Page 14 • Set the Phase switch for best bass response. • Anti-Feedback optional. • Voicing switch to the left (bass boost). • Blend slider 0–7% Image. High Volume (bands, loud stage sound) When you play with a band, your goal is to fit into the mix and cut through without feedback when it’s time to cut loose.
-
Page 15: Input Trim
Input T rim Input Trim Adjust this set-and-forget control so you can play strongly without distortion and play quietly without hiss. To set the Input Trim: 1. Move the Image switch left to #1. 2. Hold down the Measure switch as you plug in the guitar. 3. -
Page 16: Electrical Specifications
Electrical Specifications Power consumption: 1mA Typical V lithium battery life: hours Typical V alkaline battery life: 33 hours Maximum output level (onset of clipping): +1dBV Nominal output impedance: 1k Ohm Input trim gain range: -dB to +dB Peak meter response: 3dB before clipping Voicing switch, bass boost: +3dB @ 0Hz... - Page 17 Fishman, Fishman Transducers and Ellipse Aura are trademarks or tradenames of Fishman Transducers Inc. 13-300-12 Rev B 2-07...
