INSTALLATION AND OPERATING INSTRUCTIONS
APPLIANCE MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
!
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Phone:
(214) 421-7366
Fax:
(214) 565-0976
Toll Free: (800) 527-2100
Website: www.apwwyott.com
E-mail:
info@apwwyott.com
All manuals and user guides at all-guides.com
Counter Top Equipment
INTENDED FOR OTHER THAN HOUSEHOLD USE
WARMERS / COOKERS / HOLDERS
Portable Display Warmers
Counter Top Warmers - Full Size & Fractional
Hot Plates
RETAIN THIS MANUAL FOR FUTURE REFERENCE
(800) 733-2203
24 Hour Service Hotline
R
ANSI/NSF4
1
!
!
For Canadian and CE
approval see individual
specification sheet.
P/N 57213 9/05
APW WYOTT
729 Third Avenue
Dallas, TX 75226
Advertisement
Related Manuals for APW Wyott W-4
Summary of Contents for APW Wyott W-4
- Page 1 For Canadian and CE approval see individual specification sheet. ANSI/NSF4 P/N 57213 9/05 Phone: (214) 421-7366 Fax: (214) 565-0976 APW WYOTT Toll Free: (800) 527-2100 (800) 733-2203 Website: www.apwwyott.com 729 Third Avenue 24 Hour Service Hotline E-mail: info@apwwyott.com Dallas, TX 75226...
- Page 2 , Classic Rounds RCW-7 & RCW-11 , Classic Round Cooker/Warmers Electrical Specs, Installation, Operation, Daily Cleaning W-1, W-2, W-3, W-4, W-3V, W-43V Deluxe Warmers Electrical Specs, Installation, Operation, Daily Cleaning Warmers / Cookers / Holders / Cookers / Warmers / Servers...
- Page 3 Installation and start-up should be performed by a qualified installer who thoroughly read, understands and follows these instruction. If you have questions concerning the installation, operation, maintenance or service of this product, contact APW Wyott Foodservice Equipment Company’s “ Technical Service Department”. SAFETY PRECAUTIONS Before installing and operating this equipment be sure everyone involved in its operation are fully trained and are aware of all precautions.
- Page 4 Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in APW Wyott equipment. It is essential to use APW Wyott Replacement Parts when repairing APW Wyott equipment. Failure to use APW Wyott Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn.
- Page 5 If the above checks out, and you still have problems, call an APW authorized service agency. 4. MERCHANDISERS, TOPPING DISPENSERS Model: W-4 Package, Ladle Dispensers Electrical Specifications: 120 Volt, 3.3 Amp . 230 Volt, 1.6 Amp. Installation: Follow General Installation Instructions on page 4.
- Page 6 All manuals and user guides at all-guides.com Installation: Locate by outlet. CAUTION: Do not plug unit in until designated. Remove Soup of the Day Cards from inside well pan. *Follow General Instructions. Operation: Add 1 ½ quarts (1.4 litre) of hot water 120°-140°F (50°-60°C) to well pan. Now, plug in unit and preheat product into well.
- Page 7 Add hot water (120°-140°) to well pan: W-1 use: 3 cups (0.7 litre) W-2, use: 6 cups (1 ½ qts.) (1.4 litre) W-3 & W-3V, use: 4 qts. (1 gallon) (4 litre) W-4, use: 2 cups (0.5 litre) Turn infinite control to "HI" position and preheat for approximately 10 minutes.
- Page 8 Follow General Cleaning Instructions on page 4. 11. WARRANTY PROCEDURE If warranty service is needed on your APW Wyott equipment, follow these steps: Secure the model and serial number from the rating label on your appliance. Consult the enclosed directory, find the service agency nearest you, and call the number listed or the 24-hour toll free service hot line, 1-800-733-2203.
- Page 9 APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
- Page 10 Y ou may take this unit to the APW Wyott Authorized Service Distributor . List of same is included with each product. If the problem is covered under warranty , the unit will be repaired at no cost to you. If the Authorized Agency cannot repair same within a reasonable time while you wait, it will be returned to you prepaid, via UPS.
- Page 11 All manuals and user guides at all-guides.com Notes:...
- Page 12 All manuals and user guides at all-guides.com Phone: (214) 421-7366 Fax: (214) 565-0976 APW WYOTT Toll Free: (800) 527-2100 729 Third Avenue Website: www.apwwyott.com E-mail: info@apwwyott.com Dallas, TX 75226...
